🔧 Insight - Rear Brake Pads & Rotor Replacement

On your Insight, the rear brake pads clamp onto the rear rotors to slow the car down. When pads get thin or rotors get grooved/rusted, you’ll replace the pads and rotors as a set to restore smooth, safe braking.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• ⚠️ Support the car with jack stands—never rely on a floor jack alone.
• ⚠️ Your Insight uses an Electronic Parking Brake (EPB); you must put it in service/maintenance mode before pushing the rear caliper pistons in.
• ⚠️ Do not press the brake pedal while a caliper is removed.
• ⚠️ Brake dust is harmful—use brake cleaner, not compressed air.
• ⚠️ Keep brake fluid off paint; it damages paint quickly.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• 19mm socket
• Breaker bar (1/2")
• Torque wrench (20–150 ft-lbs range)
• Ratchet (3/8")
• 12mm socket
• 17mm socket
• Flat-blade screwdriver
• Needle-nose pliers
• Bungee cord
• Brake caliper compression tool (specialty)
• Impact screwdriver with #3 Phillips bit
• Wire brush
• Rubber mallet
• Brake cleaner spray
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear brake pad set - Qty: 1
• Rear brake rotors - Replace in pairs - Qty: 2
• Rear pad hardware kit (clips/shims) - Qty: 1
• Brake caliper slide pin grease (silicone) - Qty: 1
• Brake parts cleaner - Qty: 2 cans
• Brake fluid (DOT 3) - Qty: 1 quart

---

📋 Before You Begin

• Park on a flat surface, shift to P, and chock the front wheels with wheel chocks.
• Loosen rear lug nuts 1/2 turn using a 19mm socket and breaker bar before lifting.
• Plan to do one side at a time so you can look at the other side for reference.
• Put the EPB into service/maintenance mode before compressing the calipers.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Put the EPB into service/maintenance mode

• Turn ignition to ON (engine off is fine), and keep your foot OFF the brake.
• Use and hold the EPB switch in the “release” direction, then follow the on-screen/cluster prompts if they appear.
• If your Insight does not show a clear service mode prompt: use a scan tool function for EPB Maintenance Mode. (A scan tool is a plug-in device that commands modules to move motors and run tests.)
• If unsure, stop here and tell me what message you see.

Step 2: Lift the rear and remove the wheel

• Lift the rear at the proper jacking point using a floor jack.
• Set the car securely onto jack stands.
• Remove the lug nuts with a 19mm socket and take the wheel off.

Step 3: Remove the rear caliper

• Locate the rear caliper and remove the lower and upper caliper slide bolts using a 12mm socket.
• Lift the caliper off the bracket and hang it from the suspension using a bungee cord (do not let it hang by the hose).
• Caliper bracket = the metal frame the pads sit in.

Step 4: Remove the old pads and hardware

• Remove the inner and outer pads by hand (use a flat-blade screwdriver gently if stuck).
• Remove the pad clips/hardware from the bracket using a flat-blade screwdriver.
• Clean the bracket pad “lands” (where clips sit) using a wire brush and brake cleaner spray.

Step 5: Remove the caliper bracket

• Remove the caliper bracket bolts using a 17mm socket and breaker bar.
• Set the bracket aside on a clean surface.

Step 6: Remove the rotor

• If your rotor is held by Phillips screws, remove them using an impact screwdriver with #3 Phillips bit.
• Pull the rotor off. If stuck, tap the rotor hat with a rubber mallet and apply brake cleaner spray to reduce dust.

Step 7: Install the new rotor

• Clean the new rotor braking surfaces with brake cleaner spray and shop towels to remove shipping oil.
• Install the rotor onto the hub. Reinstall any rotor screws using the impact screwdriver with #3 Phillips bit (snug only).

Step 8: Reinstall the caliper bracket and new hardware

• Reinstall the caliper bracket bolts using a 17mm socket.
• Torque to 80 Nm (59 ft-lbs).
• Install the new pad clips into the bracket (press them in by hand; use a flat-blade screwdriver to seat fully if needed).

Step 9: Service the slide pins and install new pads

• Pull the slide pins out of the bracket boots (use needle-nose pliers gently if needed).
• Wipe old grease off with shop towels, then apply a thin coat of brake caliper slide pin grease (silicone).
• Reinsert pins and make sure they glide smoothly.
• Install the new pads into the bracket by hand (match inner/outer pad shapes).

Step 10: Compress the rear caliper piston

• Confirm EPB is still in service/maintenance mode.
• Compress the caliper piston straight inward using a brake caliper compression tool (specialty).
• Watch the brake fluid level while compressing; if it rises near the top, remove some fluid from the reservoir using shop towels to catch spills.

Step 11: Reinstall the caliper

• Place the caliper over the new pads and bracket.
• Install the caliper slide bolts using a 12mm socket.
• Torque to 34 Nm (25 ft-lbs).

Step 12: Reinstall the wheel

• Install the wheel and hand-thread the lug nuts.
• Lower the car off the jack stands using the floor jack.
• Tighten lug nuts in a star pattern using a torque wrench: Torque to 108 Nm (80 ft-lbs).

Step 13: Repeat on the other rear side

• Repeat Steps 2–12 on the opposite rear wheel.

---

✅ After Repair

• Exit EPB service/maintenance mode (follow the cluster prompt, or use your scan tool to end maintenance mode).
• Before moving the car, pump the brake pedal 8–12 times until it feels firm.
• Check brake fluid level and top off with DOT 3 if needed.
• Do a low-speed test in a safe area: confirm normal braking and that the EPB applies/releases normally.
• Pad break-in: make 6–10 smooth stops from ~30 mph to ~5 mph, with cool-down time between stops.

---

💰 DIY vs Shop Cost

Shop Cost: ₹12,000-₹25,000 (parts + labor)

DIY Cost: ₹6,000-₹16,000 (parts only)

You Save: ₹6,000-₹9,000 by doing it yourself!

Shop labor rates vary but typically run ₹1,500-₹3,000/hour. This repair takes a shop approximately 2-3 hours.

---
