🔧 Grand Cherokee WK - Rear Brake Pad Replacement

You'll be removing the rear wheels, taking the brake calipers off, swapping the pads, and then reassembling everything with the correct torque. This restores braking performance and prevents rotor damage from worn-out pads.

Difficulty Level: Intermediate | Estimated Time: 2–3 hours

---

⚠️ Safety & Precautions

• 🛑 Always support the vehicle with jack stands, never rely on a floor jack alone.
• 🧤 Wear safety glasses and mechanic gloves—brake dust and sharp edges can injure you.
• 🔥 Brakes get extremely hot—only work on them when they are completely cool.
• ⚙️ Your Grand Cherokee uses a separate parking brake inside the rear rotor, so normal pad replacement does not require parking brake adjustment.
• 🔋 Battery disconnect is not required for this job.
• 🌫 Avoid breathing brake dust—do not blow it with compressed air; use brake cleaner instead.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🧰 Floor jack (rated 3-ton minimum)
• 🧰 Jack stands (rated 3-ton minimum, Qty: 2)
• 🧰 Wheel chocks
• 🧰 Lug wrench (21mm) or 21mm socket
• 🧰 Ratchet (3/8" drive)
• 🧰 Breaker bar (1/2" drive)
• 🧰 Torque wrench (3/8" or 1/2" drive, up to 150 ft-lbs)
• 🧰 13mm socket
• 🧰 18mm socket
• 🧰 Flat-head screwdriver (medium size)
• 🧰 C-clamp (6" or larger) or disc brake piston tool
• 🧰 Wire brush (small)
• 🧰 Bungee cord or mechanic’s wire
• 🧰 Brake cleaner spray
• 🧰 Shop rags
• 🧰 Disposable drip tray or cardboard
• 🧰 Safety glasses
• 🧰 Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🔩 Rear brake pad set - Qty: 1 set (serves both rear wheels, replace in pairs)
• 🔩 Rear brake pad hardware kit (anti-rattle clips / abutment clips) - Qty: 1 set
• 🔩 High-temperature brake grease - Qty: 1 small tube
• 🔩 Brake cleaner - Qty: 1–2 cans
• 🔩 Caliper slide pin lube (synthetic brake grease) - Qty: 1 small tube
• 🔩 Rear caliper bracket bolts (optional, one-time-use if specified) - Qty: 4

---

📋 Before You Begin

• 🚗 Park the Grand Cherokee on a flat, solid surface. Put the transmission in PARK and set the parking brake.
• 🧱 Place wheel chocks in front of and behind a front wheel to prevent movement.
• 📦 Lay down cardboard or a drip tray under the rear brake area to catch dust and cleaner.
• 📦 Loosen the rear wheel lug nuts slightly with the 21mm socket before lifting the vehicle (do not remove them yet).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and support the rear of the vehicle

• Use the floor jack on the rear jacking point or under the rear axle tube as specified in your owner’s manual.
• Raise the rear of the Grand Cherokee until both rear wheels are off the ground.
• Place jack stands under the appropriate frame or axle points and gently lower the vehicle onto them with the floor jack.
• Shake the vehicle slightly to be sure it’s stable.

Step 2: Remove the rear wheels

• Use the 21mm socket and ratchet or lug wrench to remove the loosened lug nuts from one rear wheel.
• Remove the wheel and set it aside; repeat for the other rear wheel if you are doing both sides together.

Step 3: Inspect the brake assembly

• Look at the rear caliper (the part that squeezes the rotor) and the brake pads on both sides of the rotor.
• Note how the pads sit in the caliper bracket and how any clips are installed. Take a clear phone photo as reference.

Step 4: Remove the caliper guide pin bolts

• Locate the two small bolts on the rear of the caliper that hold it to the bracket (top and bottom).
• Use a 13mm socket and ratchet to loosen and remove both guide pin bolts.
• Once removed, gently slide the caliper off the rotor and pads.
• Support the caliper with a bungee cord or mechanic’s wire from the suspension so it does not hang by the brake hose.

Step 5: Remove the old brake pads and hardware

• Slide the old brake pads out of the caliper bracket by hand; use a flat-head screwdriver gently if they’re stuck.
• Remove the metal clips (hardware) from the caliper bracket using the flat-head screwdriver.
• Place old pads aside so you can compare thickness and shape with the new ones.

Step 6: Inspect and clean the caliper bracket and rotor

• Use a wire brush to clean rust and debris from the caliper bracket where the clips sit.
• Spray brake cleaner on the bracket and rotor face; wipe with shop rags.
• Do not get grease or oil on the rotor surface.

Step 7: Check and lubricate the caliper slide pins

• The slide pins are the pins the 13mm bolts threaded into. Carefully pull each pin out of the bracket by hand.
• Wipe off old grease with shop rags.
• Apply a thin, even coat of caliper slide pin lube to each pin, then push them back into the bracket until fully seated.
• Make sure they move smoothly in and out. Sticking pins cause uneven pad wear.

Step 8: Install new hardware clips

• Clip the new metal hardware pieces from your kit into the caliper bracket by hand.
• Make sure they are fully seated and match your reference photo.
• Apply a very light smear of high-temperature brake grease on the areas of the clips where the pad backing will slide (not on the friction material).

Step 9: Compress the caliper piston

• Place one of the old brake pads against the caliper piston.
• Use a C-clamp to press the pad and slowly push the piston back into the caliper housing.
• Turn the C-clamp slowly and watch the piston go in evenly; stop when it is flush with the caliper body.
• If it’s very hard to push, stop and re-check alignment.

Step 10: Install the new brake pads

• Compare the new pads to the old pads to match inner and outer pad positions (one may have a wear indicator tab).
• Slide the new pads into the hardware clips in the caliper bracket by hand.
• Make sure the friction material faces the rotor and the pads move smoothly in the clips.

Step 11: Reinstall the caliper over the new pads

• Remove the bungee cord or wire from the caliper while holding it.
• Position the caliper over the new pads and rotor.
• Line up the caliper with the slide pin holes in the bracket.
• Install the caliper guide pin bolts by hand first to avoid cross-threading.
• Use the 13mm socket and ratchet to snug both guide pin bolts.
• Then use a torque wrench with 13mm socket to tighten the caliper guide pin bolts to 32 Nm (24 ft-lbs).

Step 12: (If needed) Remove caliper bracket and rotor – quick check

• If you are only replacing pads and the rotor looks smooth and within thickness spec, you can skip to Step 13.
• If the rotor is badly grooved or worn, you would remove the caliper bracket using an 18mm socket and breaker bar, then pull the rotor off for replacement. Bracket bolts would be re-torqued to 136 Nm (100 ft-lbs).
• Pad-only job: you do not need to remove the bracket.

Step 13: Repeat on the other side

• Repeat Steps 4–11 on the other rear wheel so both sides have new pads and hardware.
• Always replace brake pads in pairs (left and right at the same axle).

Step 14: Reinstall the wheels

• Place the wheel back on the hub and hand-thread all lug nuts.
• Use the 21mm socket and ratchet to snug the lug nuts in a star pattern while the vehicle is still on jack stands (do not fully torque yet).

Step 15: Lower the vehicle and torque the lug nuts

• Use the floor jack to lift the vehicle slightly off the jack stands, remove the stands, then lower the vehicle to the ground.
• Use a torque wrench with 21mm socket to tighten the lug nuts in a star pattern to 176 Nm (130 ft-lbs).

Step 16: Pump the brake pedal

• Before driving, sit in the driver’s seat and press the brake pedal slowly several times.
• The pedal will firm up as the new pads seat against the rotors.
• Never drive before the pedal feels firm and consistent.

---

✅ After Repair

• 🧪 Start the engine and press the brake pedal a few more times to confirm a firm pedal.
• 🚗 Perform a short, low-speed test drive (20–40 km/h) in a safe area, checking for noises, pulling, or vibration under braking.
• 🛠 After the test drive, visually inspect the rear brakes to make sure everything is seated correctly and there are no leaks.
• ⏱ Bed-in (break-in) the new pads: make 5–8 smooth stops from about 50–60 km/h down to 10–15 km/h, allowing some cool-down time between stops. Avoid hard panic stops at first.

---

💰 DIY vs Shop Cost

Shop Cost: $250–$450 (parts + labor) for rear pads on a Grand Cherokee WK

DIY Cost: $70–$160 (parts only)

You Save: $180–$290 by doing it yourself!

Shop labor rates vary but typically run $100–$150/hour. This repair takes a shop approximately 1.0–1.5 hours.

---
