🔧 Insight - Rear Brake Pad Replacement

You’ll be removing the rear wheels, taking the rear calipers off, swapping the pads (and hardware), then putting everything back with the correct torque. On your Insight, the rear calipers work with the electronic parking brake (EPB), so you must put the EPB into a “service/maintenance mode” before pushing the piston back.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• 🛑 Support the car with jack stands; never rely on a jack alone.
• 🛑 Keep hands clear when removing the caliper; don’t let it hang by the brake hose.
• 🛑 Turn Brake Hold OFF and use EPB maintenance mode before compressing the piston, or you can damage the EPB mechanism.
• 🛑 Avoid breathing brake dust; use brake cleaner and wear a mask.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (pair, rated 2-ton minimum)
• Wheel chocks
• 19mm socket
• 3/8" drive ratchet
• 1/2" drive breaker bar
• Torque wrench (10-200 Nm range)
• 12mm socket
• 14mm wrench
• Flat-blade screwdriver
• Brake caliper piston compression tool (specialty)
• Bungee cord
• Wire brush
• Brake parts cleaner
• Catch pan
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear brake pad set - Qty: 1
• Rear brake pad hardware kit (abutment clips) - Qty: 1
• Brake caliper grease (silicone) - Qty: 1
• Brake cleaner - Qty: 1
• Rear brake rotors - Qty: 2 Optional if worn or grooved

---

📋 Before You Begin

• 🅿️ Park on level ground, point the front wheels straight, and place wheel chocks at the front tires.
• 🅿️ Turn Brake Hold OFF (button near the shifter area).
• 🅿️ Make sure the EPB is released (parking brake light off).
• 🔋 Keep the key fob away from the car during the job so the system can’t wake up unexpectedly.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the rear wheel lug nuts

• Use a 19mm socket and breaker bar to loosen (do not remove) the rear lug nuts while the car is still on the ground.

Step 2: Lift and support the rear of the car

• Use a floor jack to lift the rear at the proper jacking point.
• Set the car down onto jack stands.
• Remove the wheels using a 19mm socket and place them under the car as an extra safety backup.

Step 3: Put the electronic parking brake into maintenance/service mode

• There are two common ways to do this:
• Use a scan tool with EPB service function (specialty) to command Rear EPB Maintenance Mode. Safest, least guessing.
• If you don’t have a scan tool: use the factory EPB switch sequence for your Insight to enter maintenance mode before piston compression.
• If you tell me whether you have a scan tool, I’ll give you the exact method you should follow.

Step 4: Remove the rear caliper

• Turn the steering wheel is not needed for the rear, but rotate the hub by hand to access bolts if needed.
• Remove the lower and upper caliper slide pin bolts using a 12mm socket and 3/8" ratchet.
• If the slide pin spins, hold the pin with a 14mm wrench while turning the bolt with the 12mm socket.
• Lift the caliper off and hang it with a bungee cord (do not stress the brake hose).

Step 5: Remove old pads and hardware

• Pull the inner and outer pads out by hand; use a flat-blade screwdriver gently if they’re stuck.
• Remove the pad abutment clips from the bracket.
• Clean the pad “shelves” (where clips sit) with a wire brush, then spray with brake parts cleaner into a catch pan.

Step 6: Compress the rear caliper piston

• Remove the brake fluid reservoir cap (under the hood) to let fluid move easier while compressing.
• Use a brake caliper piston compression tool (specialty) to slowly push the piston straight back into the caliper.
• Go slowly and watch the brake fluid level; stop if it gets near “MAX” to avoid overflow.
• If it won’t compress, stop—EPB mode may not be set.

Step 7: Install new hardware and pads

• Install new abutment clips onto the bracket by hand.
• Apply a thin film of brake caliper grease (silicone) where the pad ears touch the clips (metal-to-metal contact points only).
• Install the new inner and outer pads into the bracket.

Step 8: Reinstall the caliper

• Lower the caliper back over the new pads.
• Start the slide pin bolts by hand to avoid cross-threading, then tighten using a 12mm socket and torque wrench.
• Torque to 26 Nm (19 ft-lbs) for the rear caliper slide pin bolts.

Step 9: Reinstall wheels

• Install the wheels and hand-thread the lug nuts.
• Lower the car off the jack stands using the floor jack.
• Tighten lug nuts in a star pattern using a torque wrench.
• Torque to 108 Nm (80 ft-lbs) for the lug nuts.

Step 10: Exit EPB maintenance mode

• If you used a scan tool, command EPB back to normal mode.
• If you used the switch sequence method, follow the factory sequence to exit maintenance mode.

---

✅ After Repair

• 🦶 With the car ON but in Park, pump the brake pedal 10–15 times until it feels firm.
• 🧴 Check brake fluid level and top up only if needed (don’t overfill).
• 🅿️ Apply and release the EPB a few times to confirm normal operation (no warnings).
• 🧪 Do a slow test drive in a safe area: confirm normal stopping, no pulling, no grinding.
• 🔥 Pad bedding: do 6–8 moderate stops from ~50 km/h to ~10 km/h, with cool-down rolling between. Don’t hold the pedal after hard stops.

---

💰 DIY vs Shop Cost

Shop Cost: ₹6,000-₹12,000 (parts + labor)

DIY Cost: ₹2,500-₹6,500 (parts only)

You Save: ₹3,500-₹5,500 by doing it yourself!

Shop labor rates around Panipat often vary; many shops charge roughly ₹800-₹1,500/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
