🔧 Land Cruiser - Rear Brake Pad Replacement

Replacing your rear brake pads restores safe stopping power and prevents rotor damage when pads get thin. On your Land Cruiser, the rear pads sit inside the rear brake calipers; you’ll remove the caliper, swap pads/hardware, compress the pistons, then reassemble.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• 🧱 Support the truck on jack stands; never rely on a jack alone.
• 🛞 Chock the front wheels and release the parking brake before starting (rear pads won’t come off easily if it’s applied).
• 🧤 Brake dust is harmful—wear gloves and safety glasses, and use brake cleaner (don’t blow dust with air).
• 🧷 Do not let the caliper hang by the brake hose; support it with a hanger.
• 🔧 If brake fluid rises near “MAX” while compressing pistons, remove a little with a turkey baster to avoid overflow.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (30-200 ft-lbs range)
• 14mm socket
• 17mm socket
• Ratchet (3/8" or 1/2")
• Flathead screwdriver
• Needle-nose pliers
• Brake piston spreader tool (specialty)
• Bungee cord or mechanics wire
• Brake cleaner spray
• High-temp silicone brake grease
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear brake pad set - Qty: 1
• Rear brake pad hardware kit - Qty: 1
• Brake anti-squeal compound - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to P, and chock the front wheels.
• Release the parking brake (on your Land Cruiser it’s a mechanical system; make sure it’s fully released).
• Open the hood and locate the brake fluid reservoir; you’ll monitor the level when compressing pistons.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen lug nuts and lift the rear

• Use a 21mm socket and breaker bar to loosen the rear lug nuts about 1 turn (don’t remove yet).
• Lift the rear with a floor jack and place the frame on jack stands.
• Remove the wheels using the 21mm socket.

Step 2: Identify your rear caliper style (so you use the correct removal steps)

• Look at the back side of the caliper.
• If you see two bolts on the back (upper/lower), follow Step 3A.
• If you see two pins going through the pads from the outside face, follow Step 3B.
• If unsure, tell me what you see.

Step 3A: Remove caliper (bolt-on style)

• Turn the steering/angle as needed for access, then use a 14mm socket to remove the caliper slide bolts.
• Lift the caliper off the pads/rotor and support it with a bungee cord or mechanics wire.

Step 3B: Remove pads (pin-retained style)

• Use a flathead screwdriver and needle-nose pliers to remove the anti-rattle spring/retainer.
• Use needle-nose pliers to pull the pad retaining pins out.
• Slide the pads out, then support the caliper with a bungee cord or mechanics wire if it needs to shift for clearance.

Step 4: Remove old pads and hardware

• Pull the old pads out by hand. If stuck, gently pry with a flathead screwdriver.
• Remove old shims/clips (hardware) from the caliper bracket area.
• Spray contact areas with brake cleaner spray and let dry.

Step 5: Compress the caliper pistons

• Place an old pad against the pistons, then use a brake piston spreader tool (specialty) to push the pistons back slowly and evenly.
• A brake piston spreader is a tool that pushes pistons back without damaging them.
• Watch the brake fluid reservoir while compressing; stop if it’s about to overflow.

Step 6: Install new hardware and pads

• Install the new pad clips/hardware from the hardware kit (they snap into the bracket/contact points).
• Apply a thin film of high-temp silicone brake grease to pad “ears” where they slide on the hardware.
• Apply brake anti-squeal compound to the back of the pads/shims (avoid pad friction material).
• Install the new pads in the same orientation as the old ones.

Step 7A: Reinstall caliper (bolt-on style)

• Set the caliper over the new pads and rotor.
• Install the caliper slide bolts using a 14mm socket, then tighten with a torque wrench.
• Torque to 34 Nm (25 ft-lbs).

Step 7B: Reinstall pins/spring (pin-retained style)

• Slide the pads fully into place.
• Reinstall the retaining pins using needle-nose pliers.
• Reinstall the anti-rattle spring/retainer using a flathead screwdriver and needle-nose pliers.

Step 8: Reinstall wheels

• Reinstall the wheels and hand-thread lug nuts.
• Lower the truck off the jack stands using the floor jack.
• Tighten lug nuts in a star pattern using a torque wrench: Torque to 131 Nm (97 ft-lbs).

---

✅ After Repair

• With the engine OFF, pump the brake pedal 10–15 times until it feels firm (this seats the pistons against the new pads).
• Check brake fluid level and top off only if needed.
• Do a slow test drive and confirm no pulling, grinding, or warning lights.
• Pad break-in: make 8–10 gentle stops from 30–35 mph, allowing cooling time between stops.

---

💰 DIY vs Shop Cost

Shop Cost: $300-$650 (parts + labor)

DIY Cost: $80-$220 (parts only)

You Save: $220-$430 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
