🔧 Sportage - Rear Brake Pad Replacement

Replacing the rear brake pads on your Sportage means removing the rear caliper, swapping the pads and hardware, and compressing the caliper piston so everything fits back over the rotor. The key “gotcha” is the parking brake system: some Sportage trims use an electronic parking brake (EPB) that must be put into service mode before you push the piston back.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and support the rear with jack stands before removing wheels.
• ⚠️ Do not press the brake pedal while a caliper is off the rotor (it can pop the piston out).
• ⚠️ If your Sportage has an EPB (electronic parking brake), you must retract it into service mode before compressing the piston.
• ⚠️ Brake dust is harmful—use brake cleaner, not compressed air.
• ⚠️ Keep grease off pad friction material and the rotor surface.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum) - pair
• Wheel chocks
• 21mm socket
• 3/8" drive ratchet
• 1/2" drive breaker bar
• Torque wrench (20–200 N·m range)
• 14mm socket
• 17mm socket
• Needle-nose pliers
• Flat trim/pry tool
• Bungee cord or mechanic’s wire
• C-clamp or brake caliper piston compressor (specialty)
• Brake cleaner spray
• Wire brush
• Shop towels
• Nitrile gloves
• Safety glasses
• Kia-compatible scan tool with EPB service function (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear brake pad set - Qty: 1
• Rear brake pad hardware/clip kit - Qty: 1
• Brake caliper grease (silicone-based) - Qty: 1

---

📋 Before You Begin

• Park on a level surface, put the transmission in P, and chock the front wheels.
• Make sure the parking brake is released before lifting the rear.
• Check the brake fluid reservoir level; compressing pistons can raise fluid level—remove a little with a clean syringe if it’s near “MAX.”
• If your Sportage has an EPB button (not a hand lever/foot pedal), plan to use a Kia-compatible scan tool to enter pad replacement mode (this retracts the EPB motors).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Confirm parking brake type (EPB vs non-EPB)

• If you have a parking brake button, treat it as EPB and follow the EPB notes in Step 6.
• If you have a hand lever or foot pedal, you can skip EPB service mode steps.

Step 2: Lift the rear and remove the wheels

• Use a 21mm socket and breaker bar to loosen the rear lug nuts 1/2 turn while on the ground.
• Use a floor jack to lift the rear at the proper jack point, then set the vehicle onto jack stands.
• Remove the lug nuts with the 21mm socket and pull both rear wheels off.

Step 3: Locate the rear caliper and inspect

• Turn the steering wheel is not needed; you’re working at the rear.
• Look at the caliper, brake hose, and rotor for leaks or heavy scoring before disassembly.

Step 4: Remove the caliper (leave the bracket on for now)

• Use a 14mm socket and ratchet to remove the two caliper slide-pin bolts.
• Lift the caliper off the bracket.
• Hang the caliper with a bungee cord or mechanic’s wire—do not let it hang by the brake hose.
• Tip: Take a photo of pad/clip layout first.

Step 5: Remove the old pads and hardware clips

• Slide the pads out by hand; if stuck, use a flat trim/pry tool gently.
• Remove the stainless hardware clips from the bracket with needle-nose pliers.
• Clean the bracket pad “tracks” with a wire brush, then spray with brake cleaner and wipe with shop towels.

Step 6: Retract the piston (this is where EPB matters)

• If equipped with EPB: Use a Kia-compatible scan tool with EPB service function (specialty) and command EPB Pad Replacement / Maintenance Mode before compressing the piston.
• If NOT equipped with EPB: Proceed to compress the piston normally.
• Place the old inner pad against the piston face, then use a C-clamp or brake caliper piston compressor (specialty) to push the piston in slowly until fully seated. (A piston compressor is a tool that pushes the piston straight back into the caliper.)
• Watch the brake fluid reservoir while compressing; stop if it’s about to overflow.

Step 7: Service the slide pins

• Pull the slide pins out of the bracket by hand.
• Wipe them clean with shop towels.
• Apply a thin coat of brake caliper grease and reinstall the pins, making sure the rubber boots seat fully.

Step 8: Install new hardware clips and pads

• Install the new stainless hardware clips onto the bracket by hand (use needle-nose pliers if needed).
• Apply a very thin film of brake caliper grease where the pad “ears” touch the clips (not on the pad friction material).
• Slide the new pads into place.

Step 9: Reinstall the caliper

• Position the caliper over the new pads and bracket.
• Install the slide-pin bolts using a 14mm socket.
• Torque to 25 N·m (18 ft-lbs)

Step 10: If removed, reinstall/torque the caliper bracket bolts

• If you removed the bracket (some pad jobs don’t require it), reinstall the bracket bolts using a 17mm socket.
• Torque to 85 N·m (63 ft-lbs)

Step 11: Reinstall wheels

• Reinstall both wheels and hand-thread the lug nuts.
• Lower the vehicle to the ground with the floor jack.
• Torque lug nuts in a star pattern using a torque wrench and 21mm socket.
• Torque to 90–110 N·m (66–81 ft-lbs)

---

✅ After Repair

• With the vehicle on the ground, pump the brake pedal slowly 8–12 times until it feels firm.
• Check brake fluid level and top off only if needed.
• If equipped with EPB, use the scan tool to exit maintenance mode, then apply/release EPB a few times to confirm normal operation.
• Do a careful test drive: low-speed stops first, then normal stops. Listen for grinding or pulling.
• Pad break-in (bedding): do 6–10 moderate stops from ~30–35 mph with cool-down time between stops.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $40-$120 (parts only)

You Save: $130-$410 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-2.0 hours.

---
