🔧 Rogue - Rear Brake Pad Replacement

You’ll be removing the rear wheels, unbolting the rear brake calipers, and swapping the old pads for new ones on your Rogue. You’ll also clean and lubricate the hardware so the brakes work smoothly and quietly.

Difficulty Level: Beginner | Estimated Time: 1.5–2.5 hours

---

⚠️ Safety & Precautions

• 🛑 Always work on a cool brake system. Hot rotors and calipers can burn you.
• 🧱 Park on a flat surface, shift to P, set the parking brake, and chock the front wheels so the car can’t roll.
• 🔧 Support the Rogue with jack stands under the rear pinch welds or frame points. Never rely only on a floor jack.
• 😷 Wear safety glasses and a dust mask; brake dust is harmful to breathe.
• 💧 Use only brake cleaner on brake parts—never oil or general-purpose lubricants on rotor or pad surfaces.
• ⚡ No battery disconnect or scan tool is required on this Rogue; the parking brake is cable-operated, not electronic.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Lug wrench or 21mm socket
• 3/8" drive ratchet
• 1/2" drive ratchet
• 3/8" drive torque wrench (5–80 ft-lbs range)
• 1/2" drive torque wrench (30–150 ft-lbs range)
• 14mm socket
• 17mm socket
• Flat-head screwdriver (medium size)
• Needle-nose pliers
• C-clamp or disc brake caliper piston tool
• Wire brush
• Bungee cord or wire hanger
• Shop rags
• Brake cleaner spray
• Small nylon brush
• Disposable gloves
• Safety glasses
• Dust mask or respirator

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear brake pad set (left and right) - Qty: 1 set (replace in pairs)
• Rear brake pad hardware kit (anti-rattle clips/shims) - Qty: 1 set
• High-temperature brake grease - Qty: 1 small tube
• Brake cleaner - Qty: 1–2 cans
• Rear brake rotors - Qty: 2 (optional, if worn or damaged)
• Caliper bracket bolts - Qty: 4 (optional, replace if heavily rusted or damaged)

---

📋 Before You Begin

• 🅿️ Park the Rogue on level ground, shift to P, and set the parking brake. Place wheel chocks at the front wheels.
• 📦 Loosen the rear wheel lug nuts 1/2 turn with a 21mm socket or lug wrench before lifting the vehicle.
• 🏗️ Plan to lift the rear at the center rear jacking point (under the rear subframe crossmember) using the floor jack, then support both sides with jack stands at the rear pinch welds.
• 🧴 Lay out all new parts and tools so you can compare old vs new pads and hardware easily.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the Rogue

• Use the 21mm socket and ratchet to loosen each rear wheel lug nut about 1/2 turn while the Rogue is still on the ground.
• Position the floor jack under the rear center jacking point (rear subframe crossmember) and raise the rear of the Rogue until both rear wheels are off the ground.
• Place jack stands under the rear pinch welds or designated support points and lower the Rogue onto the stands using the floor jack. Keep the jack in place lightly touching as an extra safety backup.
• Remove the rear wheels completely using the 21mm socket and set them aside.

Step 2: Inspect the brake area

• Use brake cleaner and a shop rag to lightly clean dust from the caliper, bracket, and rotor. Do not soak rubber parts.
• Spin the rotor by hand to check for scraping noises or rough spots that might suggest rotor issues.
• Look carefully at how the old pads and clips sit.

Step 3: Remove the rear caliper (one side at a time)

• On the first rear corner, locate the two caliper slide bolts on the back of the caliper.
• Use a 14mm socket and 3/8" ratchet to remove the upper and lower caliper slide bolts.
• Gently pry the caliper away from the bracket using a flat-head screwdriver if needed.
• Support the caliper with a bungee cord or wire hanger from the suspension spring so it does not hang by the brake hose.

Step 4: Remove the old brake pads and hardware

• Slide the old inner and outer pads out of the caliper bracket by hand.
• Use needle-nose pliers or your fingers to remove the old stainless hardware clips from the caliper bracket.
• Inspect the caliper slide pins (the parts the 14mm bolts go into). They should move smoothly in and out by hand; if stuck, note it for cleaning and lubrication.

Step 5: Retract the caliper piston

• Place an old brake pad against the caliper piston face.
• Use a C-clamp or caliper piston tool to slowly push the piston back into the caliper until it is flush with the caliper body.
• Go slowly to avoid pushing fluid too fast. Watch the brake fluid reservoir under the hood to make sure it does not overflow; if it rises too high, remove some with a clean syringe or turkey baster.
• Make sure piston boot is not twisted when compressed.

Step 6: Clean the bracket and slide pins

• Use the wire brush and brake cleaner to clean the areas of the caliper bracket where the hardware clips sit. Remove rust and debris until smooth.
• Pull each caliper slide pin out one at a time by hand (note their position). Wipe them clean with a shop rag.
• Apply a thin coat of high-temperature brake grease to each pin and reinsert, making sure they slide freely.
• Do not get grease on rotor or pad friction surfaces.

Step 7: Install new hardware clips

• Position the new stainless hardware clips from your kit into the caliper bracket where the old ones were.
• Press them in place by hand; they should sit fully seated and not loose. Use a flat-head screwdriver gently if needed.
• Apply a very thin layer of brake grease on the pad contact points of the clips (the spots where the pad ears will slide).

Step 8: Install new brake pads

• Match the new pads to the old ones so you know which is inner and which is outer. The inner pad often has a wear indicator tab.
• Slide the new outer pad into the outer side of the caliper bracket, making sure the pad “ears” sit in the hardware clips.
• Slide the new inner pad into the inner side of the bracket similarly.
• If the pads have anti-squeal shims, ensure they are correctly attached and facing the caliper piston or body, not the rotor.

Step 9: Reinstall the caliper over the new pads

• Position the caliper over the new pads and bracket. You may need to press the slide pins back slightly by hand to align the caliper.
• Install the upper and lower caliper slide bolts by hand to avoid cross-threading.
• Use a 14mm socket and 3/8" torque wrench to tighten the caliper slide bolts to 34 Nm (25 ft-lbs).

Step 10: Optional – Remove caliper bracket and rotor (if replacing rotors)

• If you are replacing rotors, remove the caliper again and then the caliper bracket bolts using a 17mm socket and 1/2" ratchet.
• Pull the caliper bracket off and set it aside.
• Remove the rotor. If stuck, tap around the rotor hat with a rubber mallet to loosen it.
• Clean the new rotor with brake cleaner, then install it on the hub.
• Reinstall the caliper bracket and tighten the bracket bolts with a 17mm socket and 1/2" torque wrench to 108 Nm (80 ft-lbs).
• Reinstall pads and caliper as in Steps 7–9.

Step 11: Repeat on the other side

• Repeat Steps 3–9 (and Step 10 if doing rotors) on the other rear wheel.
• Always replace rear pads and rotors on both sides together.

Step 12: Reinstall wheels and lower the Rogue

• Mount each rear wheel on the hub and hand-thread all lug nuts.
• Use the 21mm socket and ratchet to snug the lug nuts in a crisscross pattern while the Rogue is still on stands.
• Raise the Rogue slightly with the floor jack, remove the jack stands, then lower the Rogue fully to the ground.
• Use the 21mm socket and 1/2" torque wrench to torque the lug nuts to 113 Nm (83 ft-lbs) in a crisscross pattern.

Step 13: Settle the brakes and check fluid

• Sit in the driver’s seat and firmly press the brake pedal 10–15 times until it feels solid. This moves the pistons out to contact the new pads.
• Check the brake fluid level in the reservoir under the hood. Top up with the correct spec brake fluid if needed (do not overfill).

---

✅ After Repair

• 🧪 Start the engine and press the brake pedal again; it should feel firm, not spongy.
• 🚗 Do a short, gentle test drive in a quiet area. Check for noises, pulling to one side, or warning lights.
• 🔁 Bed-in the new pads: make 5–10 moderate stops from about 30–40 km/h down to 10 km/h, allowing brakes to cool slightly between stops.
• 👀 After the drive, check for any leaks, loose hardware, or hot/burning smells around the rear wheels.

---

💰 DIY vs Shop Cost

Shop Cost: $250–$400 (parts + labor) for rear pads, more if rotors are replaced.

DIY Cost: $60–$150 (parts only), depending on pad and rotor quality.

You Save: $190–$250+ by doing it yourself!

Shop labor rates vary but typically run $100–$150/hour. This repair takes a shop approximately 1.0–1.5 hours.

---
