🔧 Rogue - Rear Brake Pad Replacement

You’ll be removing the rear wheels, unbolting the rear brake calipers, swapping the pads, and reassembling everything with proper lubrication and torque. This restores safe braking and prevents grinding or rotor damage.

Difficulty Level: Beginner | Estimated Time: 1.5–2.5 hours

---

⚠️ Safety & Precautions

• Work on a flat, solid surface and keep the transmission in Park with the parking brake engaged until you are ready to lift.
• Always support the Rogue with jack stands; never rely only on a floor jack.
• Loosen wheel nuts only when the vehicle is on the ground; fully remove them after it's on stands.
• Do not press the brake pedal with a caliper removed; this can push pistons out.
• Brake dust can be harmful; avoid blowing it with air and use brake cleaner instead.
• Hybrid system: you are working on conventional hydraulic brakes only, no high-voltage components are exposed for this job.
• Keep all grease off the pad friction surfaces and rotor faces.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum, Qty: 2–4)
• Wheel chocks
• Breaker bar 1/2"
• Lug nut socket 21mm
• Socket wrench 3/8"
• Socket wrench 1/2"
• Metric socket set 10–19mm
• Combination wrench set metric 10–19mm
• Torque wrench 3/8" drive (up to 30 ft-lbs)
• Torque wrench 1/2" drive (up to 120 ft-lbs)
• C-clamp 6" or disc brake piston compressor (specialty)
• Flat-head screwdriver medium
• Wire brush small
• Bungee cord or mechanics wire
• Shop rags
• Safety glasses
• Mechanic gloves
• Drip pan or tray

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear brake pad set - Qty: 1 set (serves both rear wheels, replace in pairs)
• Rear brake pad hardware kit (shims/clips) - Qty: 1 set
• High-temperature brake grease - Qty: 1 tube
• Brake cleaner spray - Qty: 1–2 cans
• Anti-seize compound - Qty: 1 small tube
• Replacement caliper slide pin boots (optional) - Qty: 1 set
• Rear brake rotors - Qty: 2 (optional but recommended if worn or scored)

---

📋 Before You Begin

• Park the Rogue on level ground, shift to Park, and apply the parking brake.
• Place wheel chocks in front of the front wheels.
• Loosen rear wheel lug nuts 1/2 turn with the 21mm socket while the vehicle is still on the ground.
• Raise the rear at the center rear jacking point (under the rear subframe) using the floor jack, then place jack stands under the rear side pinch welds or designated support points.
• Once on stands, gently rock the Rogue to confirm it is stable before removing wheels.
• No battery disconnect or scan tool procedure is required for rear pad replacement on this model.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the rear wheels

• Use the floor jack to finish lifting the rear if not already raised, then set the Rogue securely on jack stands.
• Use the 21mm lug nut socket and breaker bar to fully remove the rear wheel nuts.
• Remove both rear wheels and set them aside.
• If a wheel is stuck, tap tire sidewall with your palm.

Step 2: Inspect the rear brake assembly

• Identify the caliper (the part that squeezes the pads), the caliper bracket (the metal frame it bolts to), and the rotor (the disc).
• Check for any damaged rubber boots on the slider pins or leaks around the caliper piston.
• Take a clear phone photo so reassembly is easier.

Step 3: Remove the lower caliper bolt and swing the caliper up

• On the rear of the caliper, locate the two small slider bolts (top and bottom).
• Use a metric socket (usually 14mm) and 3/8" socket wrench to loosen and remove the lower caliper slider bolt.
• Leave the upper slider bolt in place; rotate the caliper upward around this bolt to open it like a hinge.
• Use a bungee cord or mechanics wire to support the caliper from the suspension spring so it does not hang by the hose.

Step 4: Remove old pads and hardware

• Slide the inner and outer brake pads out of the caliper bracket by hand.
• Remove the metal pad support clips (hardware) from the caliper bracket using a flat-head screwdriver if they are tight.
• Use the wire brush to clean the pad contact areas on the caliper bracket where the clips sit.
• Spray brake cleaner on the bracket and rotor, catching runoff in a drip pan.
• Do not breathe brake cleaner mist; step back while spraying.

Step 5: Compress the caliper piston

• Before compressing, open the hood and locate the brake fluid reservoir; remove the cap and set it loosely on top to allow pressure to escape.
• Place an old brake pad against the caliper piston face inside the caliper.
• Use a C-clamp or disc brake piston compressor tool between the back of the caliper and the old pad to slowly push the piston fully back into the caliper.
• Watch the fluid level in the reservoir; if it gets close to the top, remove some fluid with a clean rag or syringe to prevent overflow.
• Compress slowly to avoid damaging seals.

Step 6: Prepare and install new hardware

• Install the new pad support clips from the hardware kit onto the caliper bracket; press them down firmly with your fingers until fully seated.
• Apply a very thin film of high-temperature brake grease to the metal surfaces where the pads will slide on the clips.
• Use only a tiny amount; too much attracts dirt.

Step 7: Service the caliper slide pins (recommended)

• Pull the caliper off its upper slider bolt and support it again with the bungee cord.
• Use the appropriate socket (usually 14mm–17mm) and 3/8" socket wrench to remove the upper slider bolt from the bracket.
• Slide both caliper pins out of the caliper bracket by hand.
• Wipe old grease and dirt from the pins with shop rags and brake cleaner.
• Inspect the rubber boots; replace them if torn or cracked.
• Apply a thin, even coat of high-temperature brake grease to each pin and reinstall them into the bracket until they move smoothly.

Step 8: Install new brake pads

• Identify the inner pad (often has a spring clip or wear sensor tab) and the outer pad.
• Slide the new pads into the bracket, making sure the friction material faces the rotor and the backing plate sits in the hardware clips.
• Make sure pads move freely in the bracket but have no excessive play.

Step 9: Reinstall the caliper over new pads

• Position the caliper over the new pads and onto the caliper bracket.
• Align the slider pin holes with the caliper ears.
• Install the lower caliper slider bolt by hand to avoid cross-threading.
• Use the metric socket (same as removal) and 3/8" torque wrench to tighten both upper and lower slider bolts to 34 N·m (25 ft-lbs).
• Hold the slide pin with a wrench if it spins.

Step 10: Repeat on the other side

• Repeat Steps 3–9 for the other rear wheel.
• Always replace pads on both sides of the axle to keep braking even.

Step 11: Reinstall wheels

• Place each rear wheel back onto the hub and hand-thread all lug nuts.
• Use the 21mm socket and 1/2" socket wrench to snug the lug nuts in a star pattern while the Rogue is still on jack stands (do not fully torque yet).
• Use the floor jack to raise the rear slightly, remove the jack stands, then lower the Rogue fully to the ground.
• Use the 21mm socket and 1/2" torque wrench to tighten the lug nuts in a star pattern to 113 N·m (83 ft-lbs).
• Star pattern helps keep the rotor centered.

Step 12: Final checks and pedal pump

• Reinstall and tighten the brake fluid reservoir cap under the hood.
• Sit in the driver’s seat and slowly press the brake pedal several times until it becomes firm; this seats the pads against the rotors.
• Check around both rear calipers and hoses for any signs of leaks or loose components.

---

✅ After Repair

• With the engine ON, press the brake pedal firmly and hold it for 20–30 seconds; ensure it feels solid and does not sink.
• Test the parking brake on a gentle slope to confirm it holds properly (parking brake works on a separate drum but overall check is good practice).
• Perform a short, low-speed test drive: 30–40 km/h (20–25 mph), brake gently several times to ensure there are no noises, pulling, or vibration.
• Bed-in the new pads: make 5–10 smooth stops from about 50–60 km/h (30–35 mph) down to 10 km/h (5–10 mph) using medium pedal pressure, allowing some time to cool between stops.
• Avoid hard emergency-style braking for the first 300–500 km (200–300 miles) unless necessary.

---

💰 DIY vs Shop Cost

Shop Cost: $280–$450 (parts + labor)

DIY Cost: $70–$160 (parts only)

You Save: $210–$290 by doing it yourself!

Shop labor rates vary but typically run $100–$150/hour. This repair takes a shop approximately 1.0–1.5 hours.

---
