🔧 A4 - Rear Brake Pad Replacement

You’ll remove the rear wheels, retract the rear calipers, swap in new brake pads, and then re-enable the parking brake system. On your A4, the rear brakes commonly use an electronic parking brake (EPB), so putting the EPB into “service mode” is the key step to avoid damage.

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and support the car with jack stands—never rely on a jack alone.
• ⚠️ If equipped with electronic parking brake (EPB), retract it with a scan tool before pushing the piston in, or you can damage the caliper motor.
• ⚠️ Brake dust is harmful—wear a dust mask and avoid blowing dust with compressed air.
• ⚠️ Don’t let the brake caliper hang by the hose—support it with a hook.
• ⚠️ Keep brake fluid off paint; it can damage the finish.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 17mm wheel bolt socket
• Breaker bar (1/2" drive)
• Torque wrench (10-200 Nm range)
• Ratchet (3/8" drive)
• Ratchet (1/2" drive)
• 7mm hex bit socket
• 13mm socket
• 15mm wrench
• 21mm socket
• Flat trim tool
• Brake caliper piston compressor tool
• Hook bungee (mechanic hanger)
• Wire brush
• Brake cleaner spray
• Scan tool with EPB service mode function (specialty)
• Nitrile gloves
• Safety glasses
• Dust mask

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear brake pad set - Qty: 1
• Brake pad anti-squeal lubricant - Qty: 1
• Rear caliper carrier bolts - Qty: 4
• Rear caliper guide pin bolt set - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• Park on level ground, put the shifter in P, and chock the front wheels with wheel chocks.
• Open the hood and locate the brake fluid reservoir; keep the cap sitting loosely on top (don’t fully remove yet). This helps prevent pressure buildup when compressing pistons.
• If your A4 has EPB, connect your scan tool with EPB service mode and prepare to retract the rear parking brake motors before you touch the calipers.
• Tip: Take a photo of each side first.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Retract the electronic parking brake (service mode)

• Use the scan tool with EPB service mode function (specialty) to command the rear parking brake into service mode (this retracts the motor so the piston can move).
• If your scan tool shows prompts, follow them until it confirms the EPB is fully retracted.
• Tip: Don’t skip this—prevents EPB motor damage.

Step 2: Loosen rear wheel bolts

• Use a 17mm wheel bolt socket with a breaker bar (1/2" drive) to loosen the rear wheel bolts 1/2 turn while the car is still on the ground.

Step 3: Lift and support the rear

• Use the floor jack (rated 3-ton minimum) to lift the rear of the car at the proper jacking point.
• Place jack stands (rated 3-ton minimum) under safe support points and lower the car onto them.
• Keep wheel chocks in place.

Step 4: Remove the rear wheels

• Remove the wheel bolts using the 17mm wheel bolt socket and ratchet (1/2" drive).
• Set the wheels aside.

Step 5: Remove the rear caliper (the clamp that holds the pads)

• Turn the steering slightly by rotating the wheel hub by hand if needed to access bolts.
• Locate the two caliper guide pin bolts on the back of the caliper.
• Remove the guide pin bolts using a 7mm hex bit socket (or, on some setups, use a 13mm socket while holding the flats with a 15mm wrench).
• Lift the caliper off the bracket and support it with a hook bungee (mechanic hanger) so the hose isn’t strained.

Step 6: Remove old pads and prep the hardware

• Slide the old pads out of the carrier by hand (use a flat trim tool gently if they’re stuck).
• Clean the pad contact points on the carrier using brake cleaner spray and a wire brush.
• Tip: Clean metal-to-metal pad slides for quiet brakes.

Step 7: Compress the rear caliper piston

• Check the brake fluid level at the reservoir before compressing the piston; if it’s near MAX, be ready to remove a small amount (don’t overflow).
• Use the brake caliper piston compressor tool to slowly push the piston straight back into the caliper until it bottoms.
• Wipe any fluid drips immediately and avoid spilling on paint.

Step 8: Install the new rear pads

• Apply a thin film of brake pad anti-squeal lubricant to the pad backing plates where they contact the caliper (do not get any on the pad friction surface).
• Install the new pads into the carrier in the same orientation as removed.

Step 9: Reinstall the caliper and torque fasteners

• Place the caliper over the new pads.
• Install the guide pin bolts using the 7mm hex bit socket (or 13mm socket with 15mm wrench counter-hold, if equipped).
• Torque to 35 Nm (26 ft-lbs) for rear caliper guide pin bolts.
• If you removed the caliper carrier bracket, install new carrier bolts using a 21mm socket.
• Torque to 90 Nm (66 ft-lbs) + 90° for rear caliper carrier bolts.
• Tip: Tighten smoothly—don’t jerk the torque wrench.

Step 10: Reinstall wheels and torque wheel bolts

• Reinstall the wheels and hand-thread all bolts first.
• Lower the car off the jack stands using the floor jack.
• Use a torque wrench (10-200 Nm range) with 17mm wheel bolt socket.
• Torque to 120 Nm (89 ft-lbs) for wheel bolts.

Step 11: Exit EPB service mode

• Use the scan tool with EPB service mode function (specialty) to close/finish service mode and re-apply the EPB motors.
• If the scan tool offers it, run the EPB basic setting/initialization.

---

✅ After Repair

• With the engine OFF, press the brake pedal 10-15 times until it feels firm (this seats the pads against the rotors).
• Check brake fluid level and top off only if needed (do not overfill).
• Start the car and confirm no brake warning lights; if a warning remains, use the scan tool to check and clear stored faults.
• Perform a careful test drive: slow stops first, then normal stops.
• Pad bedding: make 6-10 medium stops from ~40 to 10 mph, allowing short cool-down between stops.

---

💰 DIY vs Shop Cost

Shop Cost: ₹8,000-₹18,000 (parts + labor)

DIY Cost: ₹3,500-₹9,500 (parts only)

You Save: ₹4,500-₹8,500 by doing it yourself!

Shop labor rates vary in Panipat but commonly run ₹800-₹2,000/hour. This repair takes a shop approximately 1.5-3 hours.

---

🎯 Ready to get started?

HowToo makes it easy: same-day/2-day shipping on every part, plus all the tools and specialty tools you need! Check out the parts and tools sections below to add everything to your cart.

Assumption: your A4 uses EPB; torque specs shown are the common factory-style values for this platform—verify against your service information if your brake hardware differs.
