🔧 Camry - Rear Brake Pad Replacement

You’ll remove the rear wheels, swing the rear brake calipers out of the way, swap the old pads for new ones, then put everything back together with the correct torque. This restores safe stopping power and prevents rotor damage when pads get thin.

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours

Assumption: your Camry has rear disc brakes with a cable parking brake.

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and support the car with jack stands—never rely on a jack.
• ⚠️ Make sure the parking brake is fully released before starting.
• ⚠️ Brake dust is harmful—wear a mask and use brake cleaner, not compressed air.
• ⚠️ Don’t press the brake pedal with a caliper removed (the piston can pop out).
• ⚠️ Hybrid note: keep the car OFF (not in READY) while working.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• 21mm socket
• 14mm socket
• 17mm socket
• 3/8" drive ratchet
• 1/2" drive breaker bar
• Torque wrench (10-200 Nm range)
• Large C-clamp
• Flathead screwdriver
• Needle-nose pliers
• Bungee cord
• Wire brush
• Brake cleaner spray
• Shop towels
• Nitrile gloves
• Safety glasses
• Dust mask

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear brake pad set - Qty: 1
• Rear brake pad hardware/clip kit - Qty: 1
• Brake caliper grease (silicone) - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• Park on a flat surface, put the shifter in Park, and turn the car OFF (not READY).
• Release the parking brake fully.
• Place wheel chocks in front of both front tires.
• Crack the rear lug nuts loose 1/4 turn using a 21mm socket and breaker bar before lifting.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and support the rear

• Lift the rear using a floor jack (rated 2-ton minimum) at the rear center jack point.
• Set the car down onto jack stands (rated 2-ton minimum) at the rear side support points.
• Give the car a gentle shake to confirm it’s stable.

Step 2: Remove the rear wheels

• Remove lug nuts with a 21mm socket and 3/8" drive ratchet.
• Remove both rear wheels.

Step 3: Locate the rear caliper and hardware

• The caliper is the clamp that squeezes the rotor; the pads sit inside it.
• Look at the back of the caliper and find the two smaller slide-pin bolts (typically 14mm heads).

Step 4: Remove the caliper slide-pin bolts

• Remove the lower (and then upper) slide-pin bolt using a 14mm socket and ratchet.
• If the pin wants to spin, hold it carefully with needle-nose pliers while loosening.

Step 5: Swing the caliper up and support it

• Lift/swing the caliper away from the pads. Use a flathead screwdriver gently if it’s tight.
• Hang the caliper from the suspension spring using a bungee cord.
• Never let the caliper hang by the hose.

Step 6: Remove the old pads and hardware clips

• Slide the inner and outer pads out by hand.
• Remove the stainless hardware clips from the caliper bracket (use a flathead screwdriver if needed).
• Clean the bracket pad “tracks” with a wire brush and brake cleaner spray, then wipe with shop towels.

Step 7: Compress the caliper piston

• The piston is the round push-point inside the caliper that presses the pads.
• Place an old pad against the piston face, then compress slowly using a large C-clamp.
• Go slowly and keep it straight so the piston doesn’t cock sideways.

Step 8: Service the slide pins (important)

• Pull the slide pins out one at a time (they’re the smooth pins the caliper glides on).
• Wipe old grease off with shop towels.
• Apply a thin, even coat of brake caliper grease (silicone) and reinstall each pin.

Step 9: Install new hardware clips and new pads

• Snap the new hardware clips into the caliper bracket by hand.
• Apply a very thin film of brake caliper grease (silicone) where the pad “ears” touch the clips (metal-to-metal contact points only).
• Install the new inner and outer pads into the bracket.

Step 10: Reinstall the caliper

• Swing the caliper back over the new pads.
• Install the slide-pin bolts by hand first to avoid cross-threading.
• Tighten slide-pin bolts with a 14mm socket and torque wrench: Torque to 25 Nm (19 ft-lbs).

Step 11: If you removed the caliper bracket (only if needed)

• If you had to remove the bracket, reinstall and tighten bracket bolts using a 17mm socket and torque wrench: Torque to 79 Nm (58 ft-lbs).

Step 12: Reinstall wheels and torque lug nuts

• Reinstall wheels and hand-tighten lug nuts.
• Lower the car off the jack stands using the floor jack (rated 2-ton minimum).
• Torque lug nuts in a star pattern with a 21mm socket and torque wrench: Torque to 103 Nm (76 ft-lbs).

---

✅ After Repair

• Press the brake pedal slowly 10-15 times until it feels firm (this seats the pads against the rotors).
• Check brake fluid level visually and make sure the cap is secure.
• Do a low-speed test in a safe area: gentle stops first, then normal stops.
• Pad bedding (recommended): make 6-8 moderate stops from ~50 km/h to ~15 km/h with cool-down driving between stops.

---

💰 DIY vs Shop Cost

Shop Cost: ₹6,000-₹12,000 (parts + labor)

DIY Cost: ₹2,000-₹5,000 (parts only)

You Save: ₹4,000-₹7,000 by doing it yourself!

Shop labor rates vary but typically run ₹800-₹1,500/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
