🔧 Rear Brake Pads - Pad Replacement

Rear brake pad replacement on your RAV4 means removing the rear caliper, swapping the pads, and fully compressing the caliper piston before reassembly. Because this is a hybrid, keep the vehicle out of READY mode during the job so the brake system does not activate unexpectedly.

Difficulty Level: Beginner | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• Work on a level surface and chock the front wheels before lifting the rear.
• Keep the key fob far from the vehicle so the system does not wake up.
• Do not press the brake pedal with a caliper removed.
• Use jack stands. Never rely on a floor jack alone.
• Brake dust may be present. Wear safety glasses and gloves.
• No battery disconnect is normally required for rear pad replacement.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands
• Wheel chocks
• 21mm socket
• 14mm socket
• Ratchet
• Torque wrench
• Brake caliper compression tool (specialty)
• Bungee cord or hook
• Flat blade screwdriver
• Wire brush
• Brake cleaner
• Safety glasses
• Nitrile gloves
• Micrometer or brake pad gauge

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear brake pad set - Qty: 1
• Brake hardware kit - Qty: 1
• Brake grease - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Put the transmission in Park.
• Turn the ignition off and keep the key fob away from the vehicle.
• Loosen the rear wheel nuts before lifting the vehicle.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen and lift the rear of the vehicle

• Use a 21mm socket to loosen the rear wheel nuts slightly before lifting.
• Raise the rear with a floor jack (rated 3-ton minimum) at the proper lift point.
• Support the vehicle with jack stands.
• Remove the wheel nuts and wheel.

Step 2: Inspect the brake assembly

• Check the rotor surface, caliper boots, and pad wear with a micrometer or brake pad gauge.
• If the rotor is deeply grooved, heavily rusted, or below spec, replace it too.
• Clean parts make faster work.

Step 3: Remove the caliper

• Use a 14mm socket and ratchet to remove the caliper slide pin bolts.
• Lift the caliper off the bracket and hang it with a bungee cord or hook.
• Do not let the caliper hang by the brake hose.

Step 4: Remove the old pads and hardware

• Slide the old pads out of the bracket.
• Remove the pad clips and shims if your kit includes new ones.
• Use a flat blade screwdriver to gently help free stuck pads if needed.

Step 5: Clean and service the bracket

• Use a wire brush to clean rust and buildup from the pad contact points.
• Spray the area with brake cleaner and let it dry.
• Apply a thin coat of brake grease to the pad contact points and slide surfaces.

Step 6: Compress the caliper piston

• Use a brake caliper compression tool (specialty) to push the piston fully back into the caliper.
• Compress it slowly and evenly so the boot does not twist.
• Make sure the brake fluid reservoir does not overflow.

Step 7: Install the new pads

• Install the new hardware clips if included.
• Place the new inner and outer pads into the bracket.
• Make sure the pads sit fully against the clips.

Step 8: Reinstall the caliper

• Lower the caliper over the new pads.
• Install the slide pin bolts by hand first, then tighten with a 14mm socket.
• Torque to 33 Nm (24 ft-lbs).

Step 9: Reinstall the wheel

• Put the wheel back on and install the wheel nuts by hand.
• Lower the vehicle to the ground.
• Use a 21mm socket to tighten the wheel nuts in a star pattern.
• Torque to 103 Nm (76 ft-lbs).

Step 10: Restore brake pedal feel

• Before moving the vehicle, pump the brake pedal slowly until it feels firm.
• This seats the caliper piston against the new pads.
• Never skip this step.

---

✅ After Repair

• Start the vehicle and confirm the brake warning lights are off.
• Check brake pedal feel before driving.
• Test the brakes at low speed in a safe area.
• Listen for rubbing, clicking, or grinding.
• For the first 200 miles, avoid hard stops unless needed for safety.

---

💰 DIY vs Shop Cost

Shop Cost: $280-$450 (parts + labor)

DIY Cost: $70-$140 (parts only)

You Save: $210-$310 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.0 hours.

---
