🔧 CR-V - Rear Brake Pad Replacement

You’ll be removing the rear wheels, taking off the brake calipers, swapping the pads, and then reassembling and torquing everything correctly. This restores safe stopping performance and prevents damage to the rotors.

Difficulty Level: Beginner-Intermediate | Estimated Time: 2–3 hours

---

⚠️ Safety & Precautions

• 🛑 Always work on a cool brake system; hot brakes can burn you.
• 🧱 Park on a flat surface, shift to P, and firmly set the parking brake for the front wheels while you jack the rear (then release it before removing the rear calipers).
• 🧊 Chock (block) the front wheels so the CR-V cannot roll.
• 🧰 Support the vehicle with jack stands; never trust only a floor jack.
• 😷 Wear safety glasses and a dust mask; brake dust is harmful to breathe.
• 💧 Avoid getting brake fluid or cleaner on painted surfaces; it can damage paint.
• 🔌 Battery disconnection is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🧰 Floor jack (rated 3-ton minimum)
• 🧰 Jack stands (rated 3-ton minimum)
• 🧰 Wheel chocks
• 🧰 Lug nut wrench or 19mm socket with breaker bar
• 🧰 3/8" drive ratchet
• 🧰 1/2" drive ratchet
• 🧰 12mm socket
• 🧰 14mm socket
• 🧰 17mm socket
• 🧰 Torque wrench (3/8" or 1/2" drive, 10–100 ft-lbs range)
• 🧰 C-clamp (6" or larger) or brake caliper piston tool (specialty)
• 🧰 Flathead screwdriver (medium size)
• 🧰 Wire brush (small, for metal parts)
• 🧰 Bungee cord or wire hanger
• 🧰 Shop rags
• 🧰 Disposable gloves
• 🧰 Safety glasses
• 🧰 Dust mask or respirator
• 🧰 Drip pan

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🧩 Rear brake pad set (left and right) - Qty: 1 set (replace in pairs)
• 🧩 Rear brake pad hardware kit (anti-rattle clips/shims) - Qty: 1 set
• 🧩 Brake lubricant (high-temp silicone or ceramic) - Qty: 1 small tube
• 🧩 Brake cleaner spray - Qty: 1–2 cans
• 🧩 Anti-seize compound - Qty: small tube (optional but recommended)
• 🧩 Rear brake rotors - Qty: 2 (optional, if worn or damaged)

---

📋 Before You Begin

• Park the CR-V on level ground, shift to P, set the parking brake, and chock the front wheels.
• Loosen rear wheel lug nuts slightly (about one turn) before lifting the vehicle.
• Plan to release the parking brake before removing the rear calipers; the parking brake shoes are inside the rear rotor hat.
• Open the hood and locate the brake fluid reservoir; make sure it is not overfilled. You may need to remove a little fluid with a clean syringe as the caliper pistons are pushed back.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and support the rear of the CR-V

• Use the lug nut wrench or 19mm socket to loosen both rear wheel lug nuts about one turn while the CR-V is on the ground.
• Position the floor jack under the rear center jacking point (rear subframe crossmember) and raise the rear of the CR-V.
• Place jack stands under the rear pinch welds or designated support points and lower the CR-V onto them.
• Once supported, fully release the parking brake so the rear brakes are not holding the rotors.
• Gently shake the CR-V to confirm it is stable.

Step 2: Remove the rear wheels

• Use the lug nut wrench or 19mm socket to remove the rear wheel lug nuts completely.
• Remove both rear wheels and set them aside.

Step 3: Inspect the rear brake assembly

• Look at the caliper (the clamp-shaped part), the bracket behind it, the rotor (the disc), and the existing pads.
• Spray a light amount of brake cleaner on the assembly, using a drip pan and shop rags to catch runoff.
• Do not breathe brake dust; use your mask.

Step 4: Remove the rear caliper slide pin bolts

• Locate the two caliper slide pin bolts on the back of the caliper (top and bottom).
• Use a 12mm socket and 3/8" ratchet to loosen and remove both slide pin bolts.
• Carefully lift the caliper off the bracket; it may pivot up first, then pull away.
• Hang the caliper from the suspension spring using a bungee cord or wire hanger so it does not hang by the rubber hose.

Step 5: Remove the old brake pads and hardware

• Slide the inner and outer brake pads out of the caliper bracket by hand.
• Use a flathead screwdriver to gently pry out the metal pad clips (hardware) from the bracket.
• Inspect the rotor surface for heavy grooves, cracks, or deep rust; if severe, plan to replace the rotors now.

Step 6: Optional – Remove the caliper bracket and rotor (if replacing rotors)

• If you are reusing the old rotors, skip to Step 7.
• Use a 14mm or 17mm socket with 1/2" ratchet to remove the two caliper bracket bolts from the back of the knuckle.
• Pull the bracket off and set it aside.
• If the rotor is stuck, remove any rotor retaining screws (if present) using a suitable bit, then tap the rotor hat area with a rubber mallet to free it, pulling it off the hub.
• Clean the hub face with a wire brush to remove rust, then apply a very thin layer of anti-seize compound to the hub surface.
• Install the new rotor onto the hub and loosely secure it with a lug nut by hand to keep it seated.
• Reinstall the caliper bracket using the 14mm or 17mm socket and tighten the bolts to 88 Nm (65 ft-lbs) with a torque wrench.

Step 7: Clean and prepare the caliper bracket

• Use a wire brush to clean the pad contact areas on the caliper bracket where the metal clips sit.
• Spray brake cleaner on the bracket to remove dust and debris.
• Install the new metal pad clips from the hardware kit onto the bracket by pressing them into place by hand until they seat fully.
• Apply a thin layer of brake lubricant to the surfaces of the clips where the pad ears will slide (do not get any on the rotor or friction surface of the pads).

Step 8: Service the slide pins

• Gently pull the caliper slide pins out of the bracket (note their orientation).
• Wipe them clean with shop rags and inspect the rubber boots for tears.
• Apply a thin, even coat of brake lubricant to each pin and reinstall them, ensuring they slide smoothly in and out.
• Sticky pins cause uneven pad wear and noise.

Step 9: Compress the caliper piston

• Inspect the caliper piston and dust boot for damage or leaks; if you see fluid, the caliper may need replacement.
• Place an old brake pad against the piston face.
• Use a C-clamp or brake caliper piston tool to slowly push the piston back into the caliper bore until it is fully seated.
• Watch the brake fluid reservoir under the hood; if the level approaches the max line, remove some fluid with a clean tool to prevent overflow.

Step 10: Install the new brake pads

• Apply a very thin layer of brake lubricant to the pad ears (the small metal tabs that sit in the clips) and to the pad backing plates where they contact the caliper or shims.
• Slide the new inner and outer pads into the caliper bracket, making sure any wear indicator tab matches the same location as the old pads (typically on the inside pad).
• Ensure the pads move freely in the clips without binding.

Step 11: Reinstall the caliper over the new pads

• Rotate or position the caliper back over the new pads and bracket.
• Align the caliper slide pin holes with the bracket, then install the slide pin bolts by hand.
• Use a 12mm socket and 3/8" ratchet to snug the slide pin bolts.
• Use a torque wrench with 12mm socket to tighten the slide pin bolts to 22 Nm (16 ft-lbs).

Step 12: Repeat on the other side

• Repeat Steps 3–11 on the other rear wheel.
• Always replace rear pads on both sides together.

Step 13: Reinstall the wheels and lower the CR-V

• Install the rear wheels on the hubs and thread the lug nuts by hand.
• Use the lug nut wrench or 19mm socket to snug the lug nuts in a star pattern.
• Use the floor jack to raise the CR-V slightly, remove the jack stands, then lower the CR-V to the ground.
• Use a torque wrench with 19mm socket to torque the lug nuts in a star pattern to 108 Nm (80 ft-lbs).

Step 14: Pump the brake pedal and check fluid level

• With the CR-V still in P and engine off, slowly pump the brake pedal several times until it feels firm. This moves the pistons back out to contact the pads.
• Check the brake fluid level in the reservoir and adjust to the MAX mark if needed.
• Inspect around the calipers and brake lines for any fluid leaks.

---

✅ After Repair

• Start the engine and press the brake pedal; it should feel firm and consistent.
• Apply and release the parking brake several times to ensure proper operation.
• Perform a short, low-speed test drive: gently brake from 20–30 km/h a few times to confirm there are no strange noises, pulling, or vibrations.
• Bed in the new pads: make 8–10 moderate stops from 40–50 km/h down to 10 km/h, allowing a bit of cooling time between stops. Avoid hard panic stops for the first 300–500 km.
• After the test drive, recheck lug nut torque and look again for any fluid leaks.

---

💰 DIY vs Shop Cost

Shop Cost: $250–$400 (parts + labor)

DIY Cost: $60–$150 (parts only, depending on pad and rotor choice)

You Save: $190–$250 by doing it yourself!

Shop labor rates vary but typically run $100–$150/hour. This repair takes a shop approximately 1–1.5 hours.

---
