🔧 Outlander - Rear Brake Pads & Rotor Replacement

You’ll remove the rear wheels, swap the brake pads and rotors, then reassemble and seat the brakes. Rear brakes often wear slower than fronts, but rotors can rust/warp and pads can get thin or noisy.

Difficulty Level: Intermediate | Estimated Time: 2.0-3.5 hours

Assumption: This covers both rear caliper types (manual screw-in piston or electronic parking brake).

---

⚠️ Safety & Precautions

• ⚠️ Support your A4—use jack stands; never rely on a jack.
• ⚠️ Brake dust is harmful—wear a mask and use brake cleaner, not compressed air.
• ⚠️ Do not press the brake pedal with a caliper removed.
• ⚠️ If equipped with an electronic parking brake (EPB), you must put it in service mode before pushing pistons back.
• ⚠️ Brake fluid can overflow when pistons retract—watch the reservoir level.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Lug nut socket (21mm)
• Breaker bar (1/2")
• Torque wrench (1/2")
• Torque wrench (3/8")
• Ratchet (3/8")
• Socket set (10mm-19mm)
• Hex bit socket set (5mm-8mm)
• C-clamp or piston compressor
• Brake caliper wind-back tool (specialty)
• Small flathead screwdriver
• Pry bar
• Wire brush
• Rubber mallet
• Bungee cord or mechanics wire
• Brake parts cleaner spray
• Shop towels
• Nitrile gloves
• Safety glasses
• Scan tool with EPB service function (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear brake pad set - Qty: 1
• Rear brake rotors - Replace in pairs - Qty: 2
• Rear brake hardware kit (clips/shims) - Qty: 1
• Brake caliper slide pin grease (silicone) - Qty: 1
• Brake lubricant (anti-seize or brake quiet) - Qty: 1
• Brake fluid (DOT 3) - Qty: 1 quart

---

📋 Before You Begin

• Park on level ground, set the transmission to Park, and chock the front wheels.
• Release the parking brake before starting rear brake work.
• Open the hood and locate the brake fluid reservoir; keep the cap loosely on to prevent splashes.
• If your A4 has EPB: use scan tool with EPB service function to enter pad replacement/service mode (this retracts the parking brake motors so the piston can move).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the rear lug nuts

• Use a 21mm lug nut socket and breaker bar (1/2") to crack the lug nuts loose about 1/2 turn while the wheels are on the ground.

Step 2: Raise and support the rear

• Use a floor jack (rated 3-ton minimum) to lift the rear at a proper lift point.
• Set the vehicle onto jack stands (rated 3-ton minimum) and keep the wheel chocks in place.
• Remove lug nuts with the 21mm lug nut socket and take off both rear wheels.

Step 3: Remove the caliper (outer portion)

• Turn the steering wheel is not needed for the rear; position yourself for access.
• Locate the caliper slide pin bolts on the back of the caliper.
• Use the correct socket set (10mm-19mm) or hex bit socket set (5mm-8mm) (whichever fits your caliper) and a ratchet (3/8") to remove the slide pin bolts.
• Lift the caliper off the bracket and hang it using a bungee cord or mechanics wire. Never let the caliper dangle by the hose.
• Torque on install: Torque to OEM specification (slide pin bolts).

Step 4: Remove the old pads and hardware

• Pull the pads out of the bracket by hand; use a small flathead screwdriver to gently pry if stuck.
• Remove the stainless hardware clips from the bracket (if equipped) with the small flathead screwdriver.
• Clean the pad lands (where pads slide) using brake parts cleaner spray, shop towels, and a wire brush.

Step 5: Remove the caliper bracket

• Use the appropriate socket set (10mm-19mm), breaker bar (1/2"), and ratchet (3/8") to remove the caliper bracket bolts (these are usually tight).
• Remove the bracket and set it aside.
• Torque on install: Torque to OEM specification (caliper bracket bolts).

Step 6: Remove the rotor

• If your rotor has a retaining screw, remove it using the correct driver from the hex bit socket set (5mm-8mm).
• Pull the rotor off the hub. If it’s rust-stuck, tap between the studs with a rubber mallet.
• Clean the hub face with a wire brush and wipe with brake parts cleaner spray. A clean hub helps prevent rotor wobble.

Step 7: Install the new rotor

• Spray both sides of the new rotor with brake parts cleaner spray and wipe with shop towels to remove packing oil.
• Install the rotor onto the hub. If equipped, reinstall the retaining screw using the correct bit from the hex bit socket set (5mm-8mm) and a ratchet (3/8").
• Torque on install: Torque to OEM specification (rotor retaining screw, if equipped).

Step 8: Service the slide pins

• Pull the slide pins out of the bracket by hand.
• Wipe them clean with shop towels.
• Apply a thin coat of brake caliper slide pin grease (silicone) and reinstall the pins.
• Slide pins must move smoothly by hand.

Step 9: Reinstall the bracket and hardware

• Reinstall the bracket using the socket set (10mm-19mm) and breaker bar (1/2"), then tighten with a torque wrench (1/2").
• Install new hardware clips (if included) into the bracket.
• Torque: Torque to OEM specification (caliper bracket bolts).

Step 10: Retract the rear caliper piston

• Check the brake fluid reservoir under the hood before compressing; remove some fluid if it’s near MAX.
• If your Outlander uses a screw-in rear piston: use a brake caliper wind-back tool (specialty) to rotate and push the piston back in. (A wind-back tool is a tool that turns the piston while pushing it in.)
• If your Outlander has EPB: use a scan tool with EPB service function (specialty) to retract/park the EPB motors first, then use a piston compressor or C-clamp to push the piston straight in.
• Go slowly and keep the tool square so you don’t damage the piston boot.

Step 11: Install new pads

• Apply a light film of brake lubricant to pad ears where they contact the hardware (avoid friction material).
• Install the inner and outer pads into the bracket by hand.
• If your pad set includes a wear indicator, install it on the correct side per the pad instructions.

Step 12: Reinstall the caliper

• Place the caliper over the new pads.
• Reinstall the slide pin bolts using the correct socket set (10mm-19mm) or hex bit socket set (5mm-8mm) and ratchet (3/8").
• Tighten with a torque wrench (3/8").
• Torque: Torque to OEM specification (caliper slide pin bolts).

Step 13: Repeat on the other rear side

• Repeat Steps 3 through 12 on the other rear wheel.
• Do one side at a time to compare parts.

Step 14: Reinstall wheels and torque lug nuts

• Reinstall both wheels and hand-thread lug nuts.
• Lower the vehicle with the floor jack (rated 3-ton minimum).
• Use a torque wrench (1/2") and 21mm lug nut socket to tighten lug nuts in a star pattern.
• Torque: Torque to OEM specification (wheel lug nuts).

Step 15: Restore brake pedal and parking brake

• With the vehicle on the ground, pump the brake pedal 10–15 times until it feels firm.
• If equipped with EPB, use the scan tool with EPB service function (specialty) to exit service mode and reapply the EPB.
• Top off brake fluid only if needed (do not overfill).

---

✅ After Repair

• Start the engine and confirm the brake pedal stays firm.
• Check the brake fluid reservoir for correct level and inspect for leaks at both rear calipers.
• Test in a safe area: slow stops first, then normal stops.
• Brake bedding (recommended): perform 6–10 moderate stops from ~30 mph to ~5 mph, letting brakes cool a bit between stops.
• If an EPB/brake warning light stays on, scan for codes using the scan tool with EPB service function (specialty).

---

💰 DIY vs Shop Cost

Shop Cost: $450-$850 (parts + labor)

DIY Cost: $140-$380 (parts only)

You Save: $310-$470 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2.0-3.0 hours.

---
