🔧 Highlander - Rear Brake Pads & Rotor Replacement

On your Highlander, the rear brake pads clamp the rotor to slow the SUV down. When pads get thin or rotors get scored/pulsate, replacing pads and rotors together restores smooth, safe braking.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• 🛑 Work on level ground; support the Highlander on jack stands before going under.
• 🛑 Release the parking brake before removing rear calipers/rotors (the rear brakes can’t come off if it’s applied).
• 🛑 Do not press the brake pedal with a caliper removed.
• 🛑 Brake dust is harmful—use brake cleaner, not compressed air.
• 🛑 Watch brake fluid level; it can overflow when compressing pistons.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (20–150 ft-lbs range)
• 14mm socket
• 17mm socket
• Ratchet (3/8" drive)
• 3/8" drive torque wrench (10–50 ft-lbs range)
• C-clamp (6" minimum)
• Flat blade screwdriver
• Wire brush
• Bungee cord
• Rubber mallet
• Brake cleaner spray
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear brake pad set - Qty: 1
• Rear brake rotors - Qty: 2
• Rear pad hardware/clip kit - Qty: 1
• Brake caliper grease (silicone-based) - Qty: 1
• Brake fluid (DOT 3) - Qty: 1 quart

---

📋 Before You Begin

• 🧱 Park on level ground, shift to Park, and chock the front wheels with wheel chocks.
• 🦶 Make sure the parking brake is fully released (on the Highlander it’s a mechanical parking brake).
• 🧴 Open the hood and check the brake fluid reservoir level; if it’s near “MAX,” remove a small amount so it won’t overflow when you compress the pistons.
• 🧼 Set your new rotors aside somewhere clean (keep oil/grease off the braking surfaces).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the rear wheels

• Use a 21mm socket and breaker bar to loosen the rear lug nuts about 1 turn while the tires are still on the ground.

Step 2: Raise and support the rear

• Use a floor jack (rated 3-ton minimum) to lift the rear at the proper rear jacking point.
• Set the vehicle down onto jack stands (rated 3-ton minimum) placed at the rear support points.
• Remove the wheels using the 21mm socket.

Step 3: Remove the rear caliper (the part that squeezes the pads)

• Turn the steering slightly if you need better access (rear access is usually straight-on).
• Use a 14mm socket and ratchet to remove the two caliper slide pin bolts.
• Lift the caliper off the bracket and hang it with a bungee cord so the brake hose isn’t stretched. Never let the caliper hang by the hose.
• Caliper slide pins are the two small bolts that let the caliper move as pads wear.

Step 4: Remove the pads and hardware

• Pull the old pads out of the bracket by hand (use a flat blade screwdriver gently if they’re stuck).
• Remove the stainless pad clips (hardware) from the bracket.
• Use brake cleaner spray and a wire brush to clean the bracket pad “shelves” where the clips sit.

Step 5: Remove the caliper bracket

• Use a 17mm socket and breaker bar to remove the two caliper bracket bolts (they are tight).
• Set the bracket aside.
• Torque to 107 Nm (79 ft-lbs) when reinstalling the bracket bolts.
• Caliper bracket is the heavy mount the pads sit in.

Step 6: Remove the rotor

• Pull the rotor straight off the hub.
• If it’s stuck from rust, spray around the hub area with brake cleaner spray, then tap the rotor hat with a rubber mallet to break it loose.

Step 7: Install the new rotor

• Clean both sides of the new rotor with brake cleaner spray to remove protective oil.
• Slide the new rotor onto the hub.
• To keep the rotor from flopping while you work, thread on one lug nut by hand (use the 21mm socket only to snug lightly, not tighten).

Step 8: Reinstall the caliper bracket and hardware

• Reinstall the bracket and start both bolts by hand.
• Use a 17mm socket and torque wrench to tighten bracket bolts: Torque to 107 Nm (79 ft-lbs).
• Install the new pad clips from your hardware kit into the bracket.
• Apply a thin film of brake caliper grease (silicone-based) where the pad ears contact the clips (do not get grease on the rotor).

Step 9: Compress the caliper piston

• Place an old pad against the caliper piston face.
• Use a C-clamp (6" minimum) to slowly compress the piston fully back into the caliper.
• Check the brake fluid reservoir as you compress; remove excess fluid if it rises too high.
• Caliper piston is the round part that pushes the inner pad.

Step 10: Install new pads and reinstall the caliper

• Install the new pads into the bracket.
• Lower the caliper over the new pads.
• Use a 14mm socket and torque wrench to tighten the caliper slide pin bolts: Torque to 27 Nm (20 ft-lbs).

Step 11: Repeat on the other rear wheel

• Repeat Steps 3–10 on the other side.
• Replace rear pads and rotors as a pair (left and right) for even braking.

Step 12: Reinstall wheels and torque lug nuts

• Reinstall the wheels and hand-thread all lug nuts.
• Lower the Highlander off the jack stands using the floor jack (rated 3-ton minimum).
• Use a 21mm socket and torque wrench to tighten lug nuts in a star pattern: Torque to 140 Nm (103 ft-lbs).

---

✅ After Repair

• 🦶 Pump the brake pedal 10–15 times until it feels firm (this seats the pistons against the new pads).
• 🧴 Recheck brake fluid level and top off with DOT 3 only if needed.
• 🛣️ Perform a careful test drive: slow stops first, then moderate stops. Listen for grinding and confirm straight braking.
• 🔥 Pad/rotor break-in: make 8–10 moderate stops from ~40 mph to ~10 mph, letting brakes cool a bit between stops; avoid hard panic stops for the first 200 miles.

---

💰 DIY vs Shop Cost

Shop Cost: $550-$950 (parts + labor)

DIY Cost: $160-$380 (parts only)

You Save: $390-$570 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
