🔧 Camry - Rear Brake Pads & Rotor Replacement

You’ll remove the rear wheels, swap the rear brake pads and rotors, then reassemble and verify safe brake operation. This restores braking performance and prevents noise/vibration when rotors are worn, rusted, or warped.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and support the car with jack stands before going under or pulling wheels.
• ⚠️ Do not press the brake pedal with a caliper removed; the piston can pop out and leak fluid.
• ⚠️ Brake dust is harmful—use brake cleaner, not compressed air.
• ⚠️ Keep brake fluid off paint; it can damage the finish.
• ⚠️ Chock the front wheels; you’ll be releasing the parking brake during the job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 3/8" drive ratchet
• 1/2" drive breaker bar
• Torque wrench (20-150 ft-lbs range)
• 14mm socket
• 17mm socket
• Flathead screwdriver
• C-clamp brake piston compressor
• Wire brush
• Bungee cord
• Rubber mallet
• Brake cleaner spray
• Catch pan
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear brake pad set - Qty: 1
• Rear brake rotors - Replace in pairs - Qty: 2
• Brake hardware kit (rear pad clips/shims) - Qty: 1
• Disc brake caliper grease (silicone-based) - Qty: 1
• Brake cleaner - Qty: 1-2 cans

---

📋 Before You Begin

• Park on flat ground, put the shifter in P, and place wheel chocks in front of both front tires.
• Release the parking brake fully before starting (rear calipers must move freely).
• Loosen rear lug nuts 1/2 turn with a 21mm socket and breaker bar while the car is on the ground.
• Open the hood and locate the brake fluid reservoir; keep the cap loosely set on top. Fluid may rise when compressing pistons.
• Assumption: Stock rear disc brakes (no electronic parking brake).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the rear

• Use a floor jack to lift the rear at the approved rear jacking point.
• Set the car down onto jack stands at solid rear support points (pinch welds or rear support locations).
• Give the car a gentle shake to confirm it’s stable before removing wheels.

Step 2: Remove the rear wheels

• Remove lug nuts using a 21mm socket and ratchet.
• Remove both rear wheels and set them aside.

Step 3: Remove the caliper (pads stay with bracket for now)

• Turn the steering wheel is not needed for the rear; access the caliper from behind.
• Remove the two caliper slide pin bolts using a 14mm socket and ratchet.
• Lift the caliper off the bracket, then hang it from the suspension spring using a bungee cord (do not let it hang by the hose).
• Slide pins are the moving bolts the caliper “floats” on.

Step 4: Remove the old pads and hardware

• Pull the inner and outer pads out of the bracket by hand (use a flathead screwdriver gently if stuck).
• Remove the stainless pad clips/hardware from the bracket.
• Clean the bracket pad “shelves” (where clips sit) with brake cleaner spray and a wire brush.

Step 5: Remove the caliper bracket

• Remove the two caliper bracket bolts using a 17mm socket and breaker bar.
• Set the bracket on a clean surface.
• During reassembly: Torque to 88 Nm (65 ft-lbs).

Step 6: Remove the rotor

• Pull the rotor straight off the hub.
• If it’s rust-stuck, spray the hub/rotor center with brake cleaner spray, then tap the rotor “hat” with a rubber mallet until it breaks free.
• Clean the hub face with a wire brush so the new rotor sits flat. Flat hub = no vibration.

Step 7: Install the new rotor

• Clean the new rotor braking surfaces using brake cleaner spray (removes packing oil).
• Place the rotor onto the hub.
• To hold it steady while you work, thread on one lug nut by hand (use the old lug nut) and snug it lightly.

Step 8: Reinstall the caliper bracket with new hardware clips

• Install new pad clips/hardware onto the bracket by hand.
• Reinstall the bracket over the rotor and start both bolts by hand.
• Tighten using a 17mm socket and ratchet, then final tighten with a torque wrench: Torque to 88 Nm (65 ft-lbs).

Step 9: Compress the caliper piston

• Place an old brake pad against the piston face, then use a C-clamp brake piston compressor to slowly press the piston fully back into the caliper.
• Watch the brake fluid reservoir under the hood; if it gets too full, remove a little fluid into a catch pan (do not spill).
• The piston is the round “push” part that clamps the pads.

Step 10: Install new pads

• Apply a thin film of disc brake caliper grease (silicone-based) to pad ears (the metal ends that slide in the clips).
• If your pad set includes shims, install them as supplied (match inner/outer).
• Install the inner and outer pads into the bracket.
• Do not get grease on pad friction material or rotor.

Step 11: Reinstall the caliper

• Slide the caliper over the new pads and align the slide pin bolt holes.
• Install the slide pin bolts by hand first, then tighten with a 14mm socket.
• Final tighten with a torque wrench: Torque to 34 Nm (25 ft-lbs).

Step 12: Repeat on the other rear side

• Repeat Steps 3 through 11 on the opposite rear wheel.
• Always replace pads and rotors in pairs.

Step 13: Reinstall wheels and torque lug nuts

• Reinstall both rear wheels and hand-thread all lug nuts.
• Lower the car off the jack stands using the floor jack.
• Tighten lug nuts in a star pattern with a torque wrench: Torque to 103 Nm (76 ft-lbs).

---

✅ After Repair

• With the engine off, pump the brake pedal 10-15 times until it feels firm. This seats the pistons to the pads.
• Check brake fluid level and top off only if needed (do not overfill).
• Test the parking brake operation and confirm the rear wheels hold when applied.
• Do a cautious test drive: low speed first, then normal braking.
• Pad bedding (recommended): make 6-10 moderate stops from ~40 mph to 10 mph, with 30-60 seconds between stops to cool slightly.
• Recheck lug nut torque after 25-50 miles with a torque wrench: Torque to 103 Nm (76 ft-lbs).

---

💰 DIY vs Shop Cost

Shop Cost: $450-$800 (parts + labor)

DIY Cost: $160-$320 (parts only)

You Save: $290-$480 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
