🔧 RAV4 - Rear Brake Pads & Rotor Replacement

You’ll remove the rear wheels, take off the rear brake calipers and brackets, replace the pads and rotors, then reassemble everything to factory torque. This restores safe braking and fixes pulsing, squealing, or worn pads/rotors.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• 🛑 Work on level ground and support the RAV4 on jack stands before going under or pulling wheels.
• 🛑 Chock the front wheels; keep the transmission in Park.
• 🛑 Release the parking brake before removing rear rotors (these use a drum-in-hat parking brake).
• 🛑 Do not press the brake pedal with a caliper removed.
• 🛑 Brake dust is unhealthy; use brake cleaner, not compressed air.
• 🛑 Battery disconnect is not required.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm lug nut socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (20-150 ft-lbs range)
• 14mm socket
• 17mm socket
• Ratchet (3/8" or 1/2")
• Needle-nose pliers
• Flat-blade screwdriver
• Brake caliper piston compressor tool (specialty)
• Bungee cord or mechanics wire
• Wire brush
• Rubber mallet
• M8 x 1.25 bolts (pair, 25-40mm long)
• Spray brake cleaner
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear brake pad set - Qty: 1
• Rear brake rotors - Qty: 2
• Brake caliper hardware kit (rear) - Qty: 1
• High-temp silicone brake grease - Qty: 1
• Brake parts cleaner - Qty: 1
• Anti-seize compound - Qty: 1

---

📋 Before You Begin

• Park on level ground, turn the engine off, and remove the key.
• Make sure the parking brake is fully released (handle/foot pedal down).
• Crack the rear lug nuts loose 1/4 turn using a 21mm lug nut socket and breaker bar before lifting.
• Lift the rear using a floor jack and support with jack stands under solid rear lift points.
• Do one side at a time to compare.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the rear wheels

• Use a 21mm lug nut socket and ratchet to remove the lug nuts, then remove the wheel.

Step 2: Locate the caliper and remove the caliper bolts

• The caliper is the clamp that squeezes the pads on the rotor.
• Use a 14mm socket and ratchet to remove the two caliper slide pin bolts.
• Lift the caliper off the bracket.
• Hang the caliper from the suspension using a bungee cord or mechanics wire (never let it dangle by the hose).

Step 3: Remove the brake pads and hardware

• Pull the pads out of the bracket by hand.
• Remove the stainless pad clips (hardware) from the bracket using a flat-blade screwdriver.

Step 4: Remove the caliper bracket

• Use a 17mm socket and breaker bar to remove the two caliper bracket bolts.
• Remove the bracket.
• On reassembly: Torque to 79 Nm (58 ft-lbs).

Step 5: Remove the rotor (and deal with a stuck rotor if needed)

• Pull the rotor straight off the hub by hand.
• If it’s stuck from rust, tap the rotor hat with a rubber mallet to break it loose.
• If it’s still stuck, thread two M8 x 1.25 bolts into the rotor’s push-off holes and tighten evenly with a ratchet until the rotor pops free.

Step 6: If the rotor won’t come off, back off the parking brake shoes

• The parking brake shoes sit inside the “hat” of the rotor (like a small drum brake).
• Remove the rubber access plug (if equipped) and use a flat-blade screwdriver to rotate the star-wheel adjuster through the access hole to loosen the shoes.
• Try removing the rotor again by hand; tap with a rubber mallet if needed.

Step 7: Clean and prep the hub surface

• Use a wire brush to clean rust off the hub face (where the rotor sits).
• Spray the hub and surrounding area with spray brake cleaner and wipe dry.
• Apply a very thin film of anti-seize compound to the hub face to help prevent future rotor sticking (keep it off studs and braking surfaces).

Step 8: Install the new rotor

• Clean the new rotor with spray brake cleaner to remove protective oil.
• Slide the rotor onto the hub.
• Hold it with one lug nut finger-tight.

Step 9: Service the slide pins (critical for even pad wear)

• Pull the slide pins out of the bracket by hand (a “slide pin” is the smooth pin the caliper moves on).
• Wipe old grease off, then apply fresh high-temp silicone brake grease.
• Make sure the rubber boots seat properly (no twists).

Step 10: Install new pad hardware and pads

• Install the new stainless pad clips from the brake caliper hardware kit (rear) into the bracket by hand.
• Apply a light smear of high-temp silicone brake grease where the pad “ears” touch the clips (metal-to-metal contact points only).
• Install the new pads into the bracket.

Step 11: Reinstall the bracket

• Position the bracket over the rotor and start the bolts by hand.
• Use a 17mm socket and ratchet to snug them.
• Final tighten using a torque wrench: Torque to 79 Nm (58 ft-lbs).

Step 12: Compress the caliper piston and reinstall the caliper

• Use a brake caliper piston compressor tool (specialty) to slowly press the piston fully back into the caliper.
• Reposition the caliper over the new pads.
• Install the caliper slide pin bolts using a 14mm socket and ratchet.
• Final tighten using a torque wrench: Torque to 25 Nm (18 ft-lbs).

Step 13: Repeat on the other rear side

• Repeat Steps 1-12 on the other rear wheel.

Step 14: Reinstall wheels and torque lug nuts

• Reinstall the wheels and hand-thread all lug nuts.
• Lower the RAV4 to the ground using the floor jack.
• Tighten lug nuts in a star pattern using a torque wrench: Torque to 103 Nm (76 ft-lbs).

---

✅ After Repair

• With the engine off, pump the brake pedal 10-15 times until it feels firm (this seats the pistons).
• Check brake fluid level in the reservoir; top off only if needed.
• Test at low speed first. Confirm no grinding, pulling, or warning lights.
• Bed-in the pads (recommended): make 6-10 moderate stops from ~30 mph to ~5 mph, allowing short cool-down between stops.
• Re-check lug nut torque after 25-50 miles using a torque wrench.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$850 (parts + labor)

DIY Cost: $140-$320 (parts only)

You Save: $310-$530 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
