🔧 Camaro - Headlight Bulb Replacement

On your Camaro, the left and right headlight bulbs can be replaced without removing the whole headlamp, but access is tight. Most LS cars use halogen bulbs; if your car has factory HID/LED, the “bulb” may not be a simple replaceable part.

Difficulty Level: Intermediate | Estimated Time: 0.8-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Turn headlights OFF and let bulbs cool 10+ minutes (they get very hot).
• ⚠️ Do not touch the new bulb glass with bare fingers; skin oil can shorten bulb life.
• ⚠️ Keep the key away from the car so lights don’t auto-turn on.
• ⚠️ If your Camaro has factory HID/LED: do not open/probe wiring; high voltage is possible (HID), and LED modules may not be bulb-serviceable.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Nitrile gloves
• Safety glasses
• Flashlight
• Trim clip removal tool
• Ratchet
• 7mm socket
• 10mm socket
• Short Phillips screwdriver
• Small flat-blade screwdriver
• Torque wrench (inch-pound or small ft-lb range)
• Fender cover

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Low beam headlight bulb - Replace in pairs (left + right) - Qty: 2
• High beam headlight bulb - Replace in pairs (left + right) - Qty: 2
• Wheelhouse liner clips - Qty: 2-6 (as needed)

Tip: I’ll confirm the exact bulb type with 2 quick checks below.

---

📋 Before You Begin

• Park on level ground, steering unlocked, and set the parking brake.
• Turn the steering wheel fully left to access the right-side bulb area, and fully right to access the left-side bulb area.
• Open the hood for light and access to wiring routing.

Two quick questions so I match your exact setup:

• Do you mean the low beams (main headlights) or the high beams?
• Are your headlights halogen (more yellow, simple bulb with a 2-pin plug) or HID/LED (very white/blue-white; HID often has a warning label/ballast)?

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Verify which bulb you’re replacing

• Turn the headlight switch ON briefly and identify what’s out: low beam vs high beam.
• Turn the headlight switch OFF and remove the key/fob from the car.
• Use flashlight to look through the lens: the low beam is typically the projector; high beam is typically the reflector.

Step 2: Create access through the front wheelhouse liner

• Turn the steering wheel to give yourself space at the wheel you’re working behind.
• Use a trim clip removal tool and/or small flat-blade screwdriver to remove the plastic push-clips at the front section of the wheelhouse liner.
• If equipped with small screws, remove them using a 7mm socket with a ratchet.
• Gently pull the liner back just enough to reach the rear of the headlamp. Tip: Don’t crease the liner.

Step 3: Disconnect the bulb electrical connector

• Reach to the back of the headlamp and locate the bulb connector.
• Press the connector lock tab and pull straight off by hand (use nitrile gloves for grip).
• If it’s stubborn, use a small flat-blade screwdriver to gently help the lock tab—do not pry on the wires.

Step 4: Remove the old bulb

• Rotate the bulb counterclockwise (about a quarter-turn) and pull it straight out.
• Use flashlight to confirm the bulb’s locking tabs and orientation.
• If there is a rubber dust cap on your specific housing, remove/reinstall it by hand.

Step 5: Install the new bulb (no touching glass)

• Wear nitrile gloves and insert the new bulb in the same orientation as the old one.
• Push the bulb fully into the housing, then rotate clockwise until it locks.
• If you accidentally touch the glass, clean it with alcohol and let it dry completely.

Step 6: Reconnect and test before reassembly

• Reconnect the electrical connector until it clicks.
• Turn headlights ON and verify the replaced bulb works (low/high as applicable).
• Turn headlights OFF again before closing everything up.

Step 7: Reinstall the wheelhouse liner

• Reposition the liner and reinstall screws with a 7mm socket and ratchet.
• Reinstall push-clips using a trim clip removal tool (to seat them) and hand pressure.
• If you removed any small bolts on your specific liner edge, tighten with a 10mm socket and ratchet to Torque to 8 Nm (71 in-lbs).

Step 8: Repeat on the other side

• Turn the steering wheel the opposite direction and repeat Steps 2-7 for the other headlight.
• Replace bulbs in pairs so color and brightness match.

---

✅ After Repair

• Turn on low beams and high beams and confirm both sides work.
• Check that the wheelhouse liner is fully secured and not rubbing the tire.
• If the beam pattern looks off, inspect that the bulb is fully locked (an unseated bulb will aim wrong).
• If you have a bulb-out warning or flicker after install, stop and tell me what bulb type you bought and what lights you have (halogen vs HID/LED).

---

💰 DIY vs Shop Cost

Shop Cost: $150-$350 (parts + labor)

DIY Cost: $30-$140 (parts only)

You Save: $120-$210 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
