🔧 GX460 - Headlight Bulb Replacement

You can replace your GX460’s headlight bulbs from the engine bay without removing the front bumper. The main “headlight” can mean the low beam (HID) and/or the high beam (halogen), so below covers replacing both sides for both bulb types.

Assumption: Your GX460 uses D4S HID for low beams and 9005 for high beams (common US-spec setup).

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ HID systems generate very high voltage—turn lights off, remove key, and disconnect the battery before touching the low beam bulb.
• ⚠️ Let the headlight area cool for 15+ minutes before working near bulbs and housings.
• ⚠️ Do not touch the glass of halogen or HID bulbs; skin oil can shorten bulb life. Use clean gloves.
• ⚠️ Secure the hood and keep tools clear of the radiator fans.
• 🔋 Battery disconnect is recommended: remove the negative cable first.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 1/4" ratchet
• 6" socket extension
• Flathead screwdriver
• Trim clip removal tool
• Needle-nose pliers
• Flashlight
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Low beam HID bulb (D4S) - Replace in pairs - Qty: 2
• High beam bulb (9005) - Replace in pairs - Qty: 2
• Headlight dust cover gasket - Qty: 2

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Turn the headlight switch to OFF and remove the key.
• Open the hood and support it securely.
• Disconnect the battery negative terminal: use a 10mm socket to loosen the clamp and move the cable aside so it can’t spring back.
• Keep bulbs in packaging until installed.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Create working space at each headlight

• Use a flashlight to locate the rear of each headlight assembly (behind the lens, in the engine bay).
• If access is tight on the passenger side, use a 10mm socket and ratchet to remove the air intake snorkel bolts, then loosen any hose clamp with a flathead screwdriver and move the snorkel slightly for room.
• If access is tight on the driver side, use a trim clip removal tool to pop any plastic clips holding covers/ducting and move them aside.

Step 2: Remove the low beam (HID) dust cover

• Put on nitrile gloves and safety glasses.
• At the back of the headlight, find the larger round cover (low beam area).
• Twist the cover counterclockwise by hand to remove it. If it’s stubborn, gently help it with a trim clip removal tool (do not pry hard).

Step 3: Remove the low beam HID bulb (D4S)

• Locate the bulb base and connector inside the housing.
• Disconnect the electrical connector by pressing the tab and pulling straight back (use needle-nose pliers only if needed, gently).
• Release the bulb retainer (typically a twist-lock ring): rotate counterclockwise and pull the bulb straight out.
• Do not touch the bulb glass.

Step 4: Install the new low beam HID bulb (D4S)

• With nitrile gloves on, align the bulb’s locating tabs with the slots in the projector.
• Insert the bulb fully, then lock it by turning clockwise until it stops.
• Reconnect the electrical connector until it clicks.
• Reinstall the dust cover and twist clockwise until snug.

Step 5: Replace the high beam bulb (9005)

• Find the high beam access at the rear of the headlight (usually a smaller socket area than the HID low beam).
• Disconnect the electrical connector by pressing the tab and pulling back.
• Twist the bulb counterclockwise and remove it.
• Install the new 9005 bulb, twist clockwise to lock, then reconnect the connector until it clicks.
• Don’t force it—re-seat and try again.

Step 6: Reassemble any ducts/covers you moved

• Reposition the intake snorkel/ducting and reinstall fasteners using a 10mm socket, ratchet, and 6" socket extension.
• Torque to 7.5 Nm (66 in-lbs) for small 10mm bolts on plastic brackets/duct mounts.
• Reinstall any push clips using a trim clip removal tool to align them, then press them in by hand.

Step 7: Reconnect the battery

• Reconnect the negative battery cable and tighten the clamp using a 10mm socket.
• Torque to 5 Nm (44 in-lbs).

---

✅ After Repair

• Turn the ignition to ON and test low beams and high beams on both sides.
• Verify the dust covers are fully seated (keeps moisture out).
• Check the beam pattern against a wall at night; if a beam looks “off,” the bulb may not be fully locked in place.
• If the HID low beam flickers or doesn’t ignite, recheck the connector and bulb seating. Do not swap sides while powered.

---
