🔧 Supra - Ignition Coil Replacement

Your Supra’s ignition coils sit on top of the spark plugs and provide the high voltage needed for ignition. Replacing a weak coil can fix misfires, rough idle, and flashing check-engine lights. This is mostly a careful “remove and reinstall” job, but you must keep dirt out of the spark plug wells.

Difficulty Level: Beginner | Estimated Time: 0.8-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cold engine; the turbo/engine cover area gets very hot.
• ⚠️ Disconnect the battery if you’re unsure around connectors.
• ⚠️ Do not pull on wires; only pull on the connector body.
• ⚠️ Keep debris out of the spark plug tubes; blow them out before removing coils.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 1/4" drive ratchet
• 6" extension (1/4" drive)
• Plastic trim removal tool
• Ignition coil puller tool (specialty)
• Compressed air blow gun
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Ignition coil - Qty: 6 Replace as a full set if aging.
• Dielectric grease (silicone) - Qty: 1
• Spark plugs - Qty: 6 Optional but smart if due.

---

📋 Before You Begin

• Park on level ground, select Park, and set the parking brake.
• Let the engine fully cool.
• If disconnecting the battery: open the hatch area and disconnect the negative terminal using a 10mm socket; Torque to 5 Nm (44 in-lbs) on re-tightening.
• Lay out coils in order (cylinder 1 to 6) so you don’t mix anything up.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover

• Use a plastic trim removal tool to gently lift the cover at the corners if it feels stuck.
• Lift the cover straight up and set it aside on a shop towel.

Step 2: Clean around the coils

• Put on safety glasses.
• Use a compressed air blow gun to blow dirt away from the top of each coil and around the spark plug wells.
• Clean first so nothing falls inside.

Step 3: Unplug the ignition coil electrical connector

• At one coil, use your fingers (or a plastic trim removal tool) to release the connector lock.
• Pull the connector straight back by the connector body (not the wiring).

Step 4: Remove the ignition coil

• Use an ignition coil puller tool (specialty) to pull the coil straight up.
• If you don’t have a puller: rock the coil gently while pulling straight up by hand—do not pry against plastic valve cover edges.
• Set the coil aside where it won’t pick up dirt.

Step 5: Install the new ignition coil

• Apply a tiny smear of dielectric grease (silicone) inside the new coil boot (the rubber end that grips the spark plug).
• Align the coil with the spark plug tube and push straight down firmly until it fully seats.
• You should feel it “bottom out”.

Step 6: Reconnect the electrical connector

• Push the connector on until it clicks/locks fully.
• Gently tug-test the connector to confirm it’s latched.

Step 7: Repeat for the remaining coils

• Repeat Steps 3–6 for each cylinder, one at a time, to avoid mixing connectors or leaving anything unplugged.

Step 8: Reinstall the engine cover

• Align the cover with its mounting points and press down evenly by hand until fully seated.

Step 9: If you removed spark plugs (optional)

• Install spark plugs and tighten with a torque wrench: Torque to 23 Nm (17 ft-lbs).
• Reinstall coils following Steps 5–8.

---

✅ After Repair

• Start the engine and let it idle for 1–2 minutes; it should run smooth with no shaking.
• If the check-engine light was on, use a scan tool to clear faults and confirm no misfire codes return.
• Test drive 10–15 minutes and re-check for warning lights.
• Recheck that the engine cover is fully seated and no connectors are loose.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$950 (parts + labor)

DIY Cost: $200-$650 (parts only)

You Save: $250-$300+ by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
