🔧 Insight - Ignition Coil Replacement

Your Insight uses one ignition coil per cylinder (4 total). Replacing weak or failed coils can fix misfires, rough running, and check-engine light issues, and it’s a straightforward job on this engine because the coils sit on top of the valve cover.

Difficulty Level: Beginner | Estimated Time: 0.5-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a fully cool engine to avoid burns.
• ⚠️ Turn the car OFF and keep the key fob at least 10+ feet away so the system can’t wake up unexpectedly.
• ⚠️ Disconnect the 12V battery negative cable before unplugging ignition components.
• ⚠️ Do not touch any orange high-voltage cables; this repair does not require high-voltage service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 1/4" drive ratchet
• 6" extension (1/4" drive)
• Torque wrench (2-20 Nm range)
• Flat trim tool
• Small pick tool
• Dielectric grease applicator brush
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Ignition coil - Qty: 4
• Dielectric grease - Qty: 1
• Intake/engine cover grommets (if damaged) - Qty: 1 set
• Spark plugs (iridium, correct spec for your Insight) - Qty: 4

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Open the trunk and access the 12V battery area (right-side panel) so you can disconnect it.
• Disconnect the 12V battery negative cable using a 10mm socket and isolate it so it can’t spring back.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover

• Use a flat trim tool to gently pop the engine cover up at the corners (it’s held by rubber grommets).
• Lift it off and set it aside. Pull straight up, don’t twist.

Step 2: Unplug the ignition coil electrical connectors

• At each coil, press the connector lock tab and pull the connector straight off.
• If the tab is stubborn, use a small pick tool to lift the lock gently while pulling.

Step 3: Remove the ignition coil hold-down bolts

• Use a 10mm socket, 6" extension (1/4" drive), and 1/4" drive ratchet to remove the single bolt holding each coil.
• Set bolts aside so they don’t get lost.

Step 4: Pull the ignition coils out

• Grab the coil body and pull straight up while gently wiggling it.
• If it feels stuck, keep the wiggle small and steady—don’t pry hard on the valve cover.

Step 5: Install the new ignition coils

• Put a very thin film of dielectric grease inside the end of each coil boot using a dielectric grease applicator brush.
• Push each coil straight down onto its spark plug until you feel it seat.

Step 6: Reinstall the coil hold-down bolts

• Start each bolt by hand first to avoid cross-threading.
• Tighten with a 10mm socket until snug, then use a torque wrench (2-20 Nm range).
• Torque to 12 Nm (9 ft-lbs).

Step 7: Reconnect the electrical connectors

• Push each connector on until it clicks/locks.
• Do a quick tug-check by hand to confirm it’s latched.

Step 8: Reinstall the engine cover

• Align the cover with the mounting posts/grommets and press down firmly by hand.

Step 9: Reconnect the 12V battery

• Reconnect the negative cable using a 10mm socket.

---

✅ After Repair

• Start your Insight and let it idle for 1-2 minutes; it should run smooth with no shaking.
• If the check-engine light was on, it may take a few drive cycles to turn off unless codes are cleared.
• Road test for 10-15 minutes and recheck for any warning lights or rough running.
• If you still have a misfire, the next step is checking spark plugs and scanning for cylinder-specific codes.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$600 (parts + labor)

DIY Cost: $120-$400 (parts only)

You Save: $130-$200 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.7-1.2 hours.

---
