🔧 Atlas - Ignition Coil Replacement

Your Atlas uses one ignition coil per cylinder (6 total on the V6). A weak or failed coil can cause misfires, rough idle, flashing check-engine light, and poor acceleration. Replacing coils is straightforward, but you must be gentle with the electrical connectors and seat each coil fully.

Difficulty Level: Beginner | Estimated Time: 0.75-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Let the engine cool completely; coils sit near hot components.
• ⚠️ If the check-engine light is flashing, avoid driving until repaired (active misfire can damage the catalytic converter).
• ⚠️ Disconnect the negative battery cable if you’re nervous about shorting connectors (recommended for first-timers).
• ⚠️ Pull on connector housings, not the wires.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 1/4" ratchet
• 6" extension (1/4")
• Torx T30 bit socket
• Torque wrench (inch-pound or low-range) (specialty)
• Trim removal tool (plastic)
• Pick tool (small)
• Flashlight
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Ignition coil - Qty: 1 (or Qty: 6 to replace all)
• Dielectric grease (optional) - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Let the engine cool fully so you don’t burn yourself.
• If disconnecting the battery: use a 10mm socket to remove the negative (-) cable and tuck it aside so it can’t spring back.
• Tip: Replace coils one at a time.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover (if equipped)

• Grab the cover at the corners and pull upward to release the rubber grommets.
• If anything feels stuck, use a trim removal tool (plastic) to gently pry upward.

Step 2: Identify the coil(s) to replace

• Each coil is a small unit sitting on top of the valve cover with an electrical connector on it.
• If you’re replacing only one coil due to a misfire, use a flashlight to clearly see the coil and connector before touching anything.

Step 3: Unplug the ignition coil electrical connector

• Use a pick tool (small) to lift/slide the connector lock (a small safety tab) if your connector has one.
• Press the release tab and pull the connector straight off the coil.
• Tip: Wiggle gently; don’t yank.

Step 4: Remove the coil hold-down (if equipped) and pull the coil

• If your coil has a small hold-down bolt, remove it using either a 10mm socket or Torx T30 bit socket (your Atlas may use one or the other).
• Twist the coil slightly left-right to break the seal, then pull it straight up and out by hand.

Step 5: Prep and install the new coil

• Compare old vs new coil (connector position and boot length should match).
• If using it, apply a tiny smear of dielectric grease inside the rubber boot (this helps moisture resistance and easier future removal).
• Push the new coil straight down until it fully seats on the spark plug.

Step 6: Reinstall coil hold-down and torque

• Install the hold-down bolt by hand first to avoid cross-threading.
• Use a torque wrench to tighten the coil bolt: Torque to 10 Nm (7 ft-lbs).

Step 7: Reconnect the coil connector

• Push the connector on until it clicks.
• Re-engage the connector lock (if equipped).

Step 8: Repeat for remaining coils (if replacing more than one)

• Work one coil at a time so connectors don’t get mixed up.

Step 9: Reinstall the engine cover

• Line up the cover with the mounting grommets and press down firmly at each corner.

Step 10: Reconnect battery (if disconnected)

• Use a 10mm socket to tighten the negative (-) terminal: Torque to 6 Nm (53 in-lbs).

---

✅ After Repair

• Start the engine and let it idle for 1-2 minutes; it should run smooth with no shaking.
• If you have a scan tool, clear the misfire codes and confirm they don’t return.
• Test drive 10-15 minutes and recheck for a check-engine light.
• If a misfire remains, the spark plug on that cylinder may also need replacement.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$800 (parts + labor)

DIY Cost: $50-$480 (parts only, depending on 1 coil vs all 6)

You Save: $200-$400+ by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.5 hours.

---
