🔧 Odyssey - Ignition Coil Replacement

Your Odyssey uses one ignition coil per cylinder (6 total). Replacing a weak coil can fix misfires, rough running, and flashing check-engine lights, and replacing all six at once can be good preventive maintenance if they’re aging.

Difficulty Level: Intermediate | Estimated Time: 1.5–2.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool engine; the exhaust and cylinder heads get very hot.
• ⚠️ Disconnect the negative battery cable to prevent accidental shorts.
• ⚠️ Pull on connectors (plastic housings), not the wires.
• ⚠️ If the check-engine light is flashing, avoid driving until repaired (catalyst damage risk).

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 1/4" drive ratchet
• 3" extension (1/4" drive)
• 6" extension (1/4" drive)
• Torque wrench (inch-pound or small Nm range)
• Flat-blade screwdriver
• Trim clip removal tool
• Needle-nose pliers
• Flashlight
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Ignition coil - Qty: 6
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground and shift to Park.
• Open the hood and let the engine cool completely.
• Use a 10mm socket to disconnect the negative battery cable and move it aside so it can’t spring back.
• Tip: Replace coils one-by-one to avoid mix-ups.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover (if equipped)

• Lift off the engine cover by releasing its mounting points (some pull straight up).
• If clips are present, use a trim clip removal tool to release them.

Step 2: Make room to access the coils

• Inspect the top of the engine for any intake ducting or brackets blocking coil access.
• Loosen intake duct clamps with a flat-blade screwdriver and reposition the duct if it blocks access.
• For any plastic push-clips, remove them with a trim clip removal tool.

Step 3: Unplug the first ignition coil connector

• Choose one coil and work on only that coil until it’s fully installed.
• Press the connector lock tab and pull the connector off the coil (use a flashlight to see the tab clearly).
• If it’s stubborn, gently help it with needle-nose pliers on the connector body (not the wires).

Step 4: Remove the ignition coil retaining bolt

• Remove the coil hold-down bolt using a 10mm socket with a 1/4" drive ratchet and 3" extension.
• Set the bolt aside where it won’t fall into the engine bay.

Step 5: Remove the ignition coil

• Twist the coil slightly, then pull it straight up to remove it from the spark plug tube.
• Check the coil boot (rubber end) for oil or coolant contamination.
• Tip: Oil in the tube needs diagnosis first.

Step 6: Install the new ignition coil

• Apply a very small amount of dielectric grease inside the new coil boot (a thin film only).
• Push the new coil straight down until it seats fully on the spark plug.
• Install the hold-down bolt by hand first to avoid cross-threading.
• Tighten the bolt with a torque wrench: Torque to 12 Nm (9 ft-lbs).

Step 7: Reconnect the coil electrical connector

• Push the connector on until it clicks/locks.
• Gently tug the connector to confirm it’s locked.

Step 8: Repeat for the remaining coils

• Repeat Steps 3–7 for each remaining coil.
• Use a 6" extension as needed for the coils that sit further back.
• Tip: Keep bolts with each coil location.

Step 9: Reinstall ducting/covers and reconnect the battery

• Reinstall any intake ducting and clips using the flat-blade screwdriver and trim clip removal tool.
• Reinstall the engine cover.
• Reconnect the negative battery cable using the 10mm socket.

---

✅ After Repair

• Start the engine and let it idle for 2–3 minutes. It should run smooth with no shaking.
• Test drive for 10–15 minutes and confirm no misfire symptoms.
• If the check-engine light stays on, the code may need to be cleared; use an OBD2 scan tool and recheck for returning misfire codes.
• If you found oil in any spark plug tube, stop and address that leak before it damages the new coil.

---

💰 DIY vs Shop Cost

Shop Cost: $450–$900 (parts + labor)

DIY Cost: $180–$600 (parts only)

You Save: $270–$300+ by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5–2.0 hours.

---
