🔧 Cherokee - Ignition Coil Replacement

Your Cherokee’s ignition coils sit on top of the spark plugs and create the high voltage needed to fire each cylinder. Replacing a weak coil can fix misfires, rough idle, and flashing check-engine lights.

Difficulty Level: Intermediate | Estimated Time: 0.5-2.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Let the engine cool fully before starting (hot intake and exhaust parts burn).
• ⚠️ Disconnect the negative battery cable to prevent accidental shorts.
• ⚠️ If the check-engine light is flashing, avoid driving until repaired (can damage the catalytic converter).
• ⚠️ Keep dirt out of the intake if you remove it (cover openings immediately).

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Ratchet (3/8")
• Torque wrench (inch-pound, 30-250 in-lb range)
• Socket set (metric)
• 10mm socket
• 8mm socket
• 6" extension (3/8")
• Trim clip remover
• Flat-blade screwdriver
• Needle-nose pliers
• Shop light
• Fender cover
• OBD2 scan tool

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Ignition coil - Qty: 1-6
• Upper intake manifold gasket set - Qty: 1 (needed if removing intake)
• Throttle body gasket - Qty: 1 (recommended if removing throttle body)
• Dielectric grease - Qty: 1 (optional)

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Open the hood and remove loose jewelry/clothing.
• Disconnect the negative battery cable using a 10mm socket.
• Plan your access: the “front bank” coils are easier; the “rear bank” (near the firewall) may require upper intake removal. The upper intake manifold is the plastic air passage on top of the engine.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Verify which cylinder is misfiring (recommended)

• Plug in your OBD2 scan tool and read codes.
• If you see codes like P0302, P0304, etc., that last digit usually points to the misfiring cylinder.
• Fix one cylinder first if budget is tight.

Step 2: Remove the engine cover

• Pull up on the engine cover to release it, or remove any fasteners using a trim clip remover (varies by cover style).
• Set the cover aside where it won’t get stepped on.

Step 3: Choose the access path (front bank vs rear bank)

• Front bank coils (radiator side): Usually accessible after removing the engine cover.
• Rear bank coils (firewall side): If your hands/tools can’t reach the coil bolts/connectors, you’ll need to remove the upper intake manifold for access.

Step 4: Unplug the coil electrical connector

• Press the connector lock tab and pull the connector straight off the coil.
• If it’s stubborn, use a flat-blade screwdriver gently on the tab (don’t pry on wires).
• Use a shop light so you can clearly see the lock tab.

Step 5: Remove the coil mounting bolt

• Use a 10mm socket with a ratchet (3/8") and a 6" extension (3/8") to remove the coil bolt.
• Put the bolt somewhere safe (a magnetic tray is helpful).

Step 6: Remove the ignition coil

• Twist the coil slightly, then pull straight upward to unseat the rubber boot from the spark plug.
• If it won’t come out, keep pulling straight up—don’t lever against plastic parts.

Step 7: Install the new coil

• Add a tiny smear of dielectric grease inside the coil boot (optional).
• Push the coil straight down until you feel it fully seat on the spark plug.
• Install the coil bolt by hand first to avoid cross-threading.
• Tighten using a torque wrench (inch-pound, 30-250 in-lb range): Torque to 8 Nm (71 in-lb).

Step 8: Reconnect the coil connector

• Push the connector on until it clicks/locks.
• Do a quick “tug test” with your fingers to confirm it’s latched.

Step 9 (Rear bank only): Remove the upper intake manifold if needed for access

• Loosen the air duct clamps using an 8mm socket or flat-blade screwdriver (clamp style varies), then remove the ducting enough to access intake fasteners.
• Disconnect any visible vacuum/PCV lines using needle-nose pliers (squeeze clamps) and pull hoses off gently.
• Unplug sensors on the intake as needed by pressing the tabs (use flat-blade screwdriver gently if required).
• Remove the upper intake manifold bolts using a socket set (metric) and ratchet (3/8").
• Lift the upper intake manifold straight up and off.
• Immediately cover the exposed intake ports using clean shop towels (keeps hardware from falling in).
• Replace the intake gaskets with the upper intake manifold gasket set before reassembly.
• Reinstall the upper intake manifold and tighten bolts evenly in a crisscross pattern using a torque wrench (inch-pound, 30-250 in-lb range).
• If you want, tell me “front only” or “rear only” and I’ll tailor access steps.

Step 10: Reinstall the engine cover and reconnect battery

• Reinstall the engine cover by pressing it back into place.
• Reconnect the negative battery cable using a 10mm socket.

---

✅ After Repair

• Start the engine and let it idle for 2-3 minutes. Listen for smooth idle (no shaking).
• Use the OBD2 scan tool to clear codes, then recheck for pending codes after a short drive.
• If the same misfire returns, the spark plug or injector on that cylinder may be the cause (next diagnostic step).
• Make sure no vacuum hoses were left disconnected (can cause rough idle and lean codes).

---

💰 DIY vs Shop Cost

Shop Cost: $250-$750 (parts + labor)

DIY Cost: $40-$450 (parts only)

You Save: $210-$300 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-2.0 hours.

---
