🔧 Highlander - Ignition Coil Replacement

Replacing the ignition coils on your Highlander means removing the coil-on-plug units that sit directly on top of the spark plugs. A failed coil can cause misfires, rough running, poor fuel economy, or a flashing check engine light.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Your Highlander is a hybrid, so avoid touching any orange high-voltage cables or hybrid components.
• ⚠️ Turn the vehicle OFF and keep the key fob at least 15 feet away so the hybrid system cannot wake up unexpectedly.
• ⚠️ Disconnect the 12V battery negative terminal before working near engine electrical connectors.
• ⚠️ Let the engine cool fully before starting. The rear ignition coils are near hot exhaust and tight engine-bay areas.
• ⚠️ Replace coils one at a time if possible so connectors and positions do not get mixed up.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 12mm socket
• 14mm socket
• 3/8-inch ratchet
• 3/8-inch torque wrench
• 3-inch extension
• 6-inch extension
• Needle-nose pliers
• Flat-blade screwdriver
• Trim clip removal tool
• Paint marker
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Ignition coil - Qty: 1-6 as needed
• Upper intake manifold gasket set - Qty: 1 if removing the intake manifold
• Throttle body gasket - Qty: 1 if throttle body is removed
• Dielectric grease - Qty: 1 small tube

---

📋 Before You Begin

• 🅿️ Park your Highlander on level ground, shift to Park, and set the parking brake.
• 🔑 Turn the power switch OFF and remove the key fob from the vehicle area.
• 🔋 Disconnect the 12V battery negative cable using a 10mm socket. The 12V battery supplies normal vehicle electronics, separate from the orange high-voltage hybrid battery.
• 🧊 Let the engine cool for at least 30-60 minutes before touching ignition coils.
• 📝 Use a paint marker to label hoses and connectors before removal. This makes reassembly much easier for a first-time DIYer.
• 📌 Assumption: front-bank coils can be replaced directly; rear-bank coils require upper intake manifold removal for access.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the Engine Cover

• Use both hands to lift the plastic engine cover straight upward.
• If it feels stuck, gently rock it side to side. It is held by rubber grommets, not screws.
• Set the cover aside where it cannot be stepped on.
• Pull upward evenly.

Step 2: Disconnect the 12V Battery Negative Cable

• Use a 10mm socket and 3/8-inch ratchet to loosen the negative battery terminal clamp.
• Lift the negative cable off the battery post and move it aside so it cannot spring back.
• Wait at least 90 seconds before unplugging engine connectors.

Step 3: Locate the Ignition Coils

• The ignition coils are black electrical units mounted on top of the spark plug tubes.
• The front bank has three coils facing the radiator and is easier to reach.
• The rear bank has three coils close to the firewall and usually requires upper intake manifold removal.
• Use a shop towel to wipe loose dirt away from the coil area before removal.

Step 4: Replace a Front Ignition Coil

• Put on safety glasses and nitrile gloves.
• Press the tab on the coil electrical connector with your thumb or a flat-blade screwdriver, then pull the connector straight back.
• Use a 10mm socket, 3-inch extension, and 3/8-inch ratchet to remove the coil hold-down bolt.
• Twist the coil gently by hand, then pull it straight upward out of the spark plug tube.
• Apply a very small amount of dielectric grease inside the new coil boot. Dielectric grease is a non-conductive grease that helps seal out moisture.
• Push the new coil straight down until it fully seats on the spark plug.
• Install the coil bolt using a 10mm socket and 3/8-inch torque wrench.
• Torque to 8 Nm (71 in-lbs)
• Reconnect the electrical connector until it clicks.
• Do one coil at a time.

Step 5: Prepare for Rear Ignition Coil Access

• Use a paint marker to label vacuum hoses, breather hoses, and electrical connectors around the upper intake manifold.
• Use a trim clip removal tool to release any harness clips attached to the intake area.
• Use needle-nose pliers to release spring clamps on small hoses, then slide the hoses off carefully.
• Use a flat-blade screwdriver only to gently help loosen stuck hoses. Do not pry hard on plastic fittings.

Step 6: Remove the Air Intake Tube

• Use a 10mm socket or flat-blade screwdriver to loosen the intake tube clamps.
• Unplug any attached intake tube connector by pressing the locking tab and pulling straight back.
• Remove the intake tube and set it aside.
• Cover the open throttle body area with a clean shop towel if the opening is exposed.

Step 7: Remove the Upper Intake Manifold

• Use a 12mm socket, 6-inch extension, and 3/8-inch ratchet to remove the upper intake manifold bolts and nuts.
• Use a 14mm socket if a support bracket fastener blocks manifold movement.
• Lift the upper intake manifold carefully. Check that all hoses and connectors are free before pulling it away.
• Remove the old upper intake manifold gaskets.
• Cover the lower intake openings immediately with clean shop towels so nothing falls into the engine.
• Nothing can fall inside.

Step 8: Replace the Rear Ignition Coils

• Use a shop towel to clean around each rear coil before removal.
• Press each coil connector tab with your thumb or a flat-blade screwdriver, then unplug the connector.
• Use a 10mm socket, 3-inch extension, and 3/8-inch ratchet to remove each coil hold-down bolt.
• Twist each coil gently, then pull it straight upward.
• Apply a tiny amount of dielectric grease inside each new coil boot.
• Install each new coil straight down onto its spark plug.
• Use a 10mm socket and 3/8-inch torque wrench to tighten each coil bolt.
• Torque to 8 Nm (71 in-lbs)
• Reconnect each coil connector until it clicks.

Step 9: Reinstall the Upper Intake Manifold

• Remove the shop towels from the lower intake openings and double-check that no debris is inside.
• Install the new upper intake manifold gasket set into position.
• Lower the upper intake manifold straight down by hand.
• Start all bolts and nuts by hand first to avoid cross-threading.
• Use a 12mm socket, 6-inch extension, and 3/8-inch torque wrench to tighten the intake manifold fasteners evenly.
• Torque to 21 Nm (15 ft-lbs)
• Use a 14mm socket and 3/8-inch torque wrench to reinstall any removed support bracket fastener.
• Torque to 37 Nm (27 ft-lbs)

Step 10: Reconnect Hoses, Harnesses, and Intake Tube

• Use your labels from the paint marker to reconnect every hose and connector to its original location.
• Use needle-nose pliers to reposition spring clamps fully over the hose nipples.
• Reinstall the air intake tube.
• Use a 10mm socket or flat-blade screwdriver to tighten the intake tube clamps snugly.
• Reconnect any intake tube electrical connector until it clicks.

Step 11: Reconnect the 12V Battery

• Place the negative battery cable back onto the battery post.
• Use a 10mm socket and 3/8-inch ratchet to tighten the clamp.
• Do not overtighten the battery terminal. It only needs to be secure and unable to twist by hand.

Step 12: Reinstall the Engine Cover

• Line up the cover with the mounting studs.
• Press down firmly by hand until the rubber grommets seat.
• Do not use tools on the plastic engine cover.

---

✅ After Repair

• ✅ Start your Highlander and let it idle for several minutes.
• 👂 Listen for hissing sounds. A hiss may mean a vacuum hose or intake gasket is leaking.
• ⚠️ If the check engine light was flashing before, avoid hard driving until misfire codes are cleared and the engine runs smoothly.
• 🔍 Check that every connector is locked and every hose is fully seated.
• 🚗 Take a short test drive. Acceleration should feel smooth with no shaking or misfire.
• 🧠 If warning lights remain, scan for diagnostic trouble codes and clear them after confirming the repair.

---
