🔧 Ignition Coil Replacement - Coil Pack Replacement

Your 5.7L uses one ignition coil per cylinder, mounted on top of each spark plug. Replacing a bad coil restores smooth idle, fixes misfire issues, and helps prevent catalytic converter damage from unburned fuel.

Difficulty Level: Beginner | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• Let the engine cool fully before starting. Coil boots and valve covers can stay hot.
• Disconnect the negative battery cable before removing coils to avoid accidental sparking.
• Do not pull on the coil wire lead, if equipped; always remove the coil by the body.
• Keep dirt out of the spark plug wells. Debris can fall into the cylinder when a coil is removed.
• If you are replacing coils after a misfire, inspect the spark plugs too. A worn plug can damage a new coil.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 8mm socket
• 3/8-inch ratchet
• 3-inch extension
• Trim panel tool
• Flat blade screwdriver
• Torque wrench
• Gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Ignition coil - Qty: 8, replace as needed or replace all eight as a set
• Coil boot grease - Qty: 1
• Spark plugs - Qty: 8, recommended if plugs are worn or unknown age

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Turn the ignition off and remove the key/fob from the vehicle.
• Disconnect the negative battery cable before touching the ignition coils.
• Let the engine cool completely before opening the hood.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Disconnect battery power

• Use an 8mm socket to loosen the negative battery terminal.
• Move the cable aside so it cannot spring back and touch the post.
• Keep the cable isolated.

Step 2: Remove the engine cover

• Lift the engine cover straight up by hand. If it feels stuck, use a trim panel tool gently at the edges.
• Set the cover aside in a safe spot.

Step 3: Access the coil you are replacing

• Locate the coil on top of the cylinder you are servicing.
• If anything blocks access, move it carefully out of the way without stressing hoses or wiring.

Step 4: Unplug the coil

• Press the connector lock tab and pull the electrical connector straight off the coil.
• If the connector is tight, use a flat blade screwdriver gently on the tab, not the wires.

Step 5: Remove the coil hold-down bolt

• Use an 8mm socket and 3/8-inch ratchet with a 3-inch extension to remove the coil bolt.
• Set the bolt aside for reuse unless it is damaged.
• Torque on installation: 12 Nm (106 in-lbs)

Step 6: Remove the ignition coil

• Twist the coil gently and pull it straight up out of the spark plug well.
• If it sticks, wiggle it side to side while lifting. Do not pry hard on the valve cover.
• Pull straight to protect the boot.

Step 7: Inspect the spark plug well

• Look for oil, water, or dirt in the well.
• If you find contamination, clean it out before installing the new coil.
• If the rubber boot is torn or burned, replace the coil and inspect the plug.

Step 8: Install the new ignition coil

• Apply a small amount of coil boot grease inside the new boot if included or recommended.
• Slide the new coil straight down onto the spark plug until fully seated.
• Install the coil bolt by hand first, then tighten with the 8mm socket.
• Torque to 12 Nm (106 in-lbs)

Step 9: Reconnect the electrical connector

• Push the connector onto the coil until the lock tab clicks.
• Lightly tug on the connector to make sure it is locked in place.

Step 10: Reinstall the engine cover and battery cable

• Set the engine cover back in place and press it down evenly.
• Reconnect the negative battery cable using the 8mm socket and tighten it snugly.

---

✅ After Repair

• Start the engine and listen for smooth idle.
• Check the dashboard for a check engine light or flashing misfire light.
• If a misfire was present before, clear codes with a scan tool and road test the vehicle.
• If the misfire returns, inspect the spark plug, connector, and wiring for that cylinder.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$650 (parts + labor)

DIY Cost: $40-$320 (parts only)

You Save: $210-$330 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1-2 hours.

---
