🔧 LaCrosse - Ignition Coil Replacement

On your LaCrosse, the ignition coils sit on top of the spark plugs and create the high-voltage spark your engine needs to run smoothly. The front bank coils are easy to access, but the rear bank coils require removing the upper intake manifold (the large plastic/aluminum “air bridge” on top of the engine) to reach them.

Difficulty Level: Advanced | Estimated Time: 2.5–4.5 hours

Assumption: 3.6L V6 rear coils are under the intake manifold.

---

⚠️ Safety & Precautions

• Disconnect the negative battery cable before unplugging coils or sensors to prevent electrical damage.
• Work on a fully cool engine; the intake and cylinder heads can burn you when hot.
• Keep dirt out of the intake runners; stuff clean rags in openings as soon as the manifold is off.
• Do not pry on plastic connectors; use the release tabs to avoid breaking them.
• If you smell strong fuel, stop and check for a disturbed EVAP/fuel vapor line before continuing.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• 10mm socket
• 8mm socket
• 7mm socket
• 3/8" drive ratchet
• 3/8" drive torque wrench (10–30 Nm range)
• 6" socket extension
• 12" socket extension
• 3/8" universal joint adapter
• Flathead screwdriver
• Trim clip removal tool
• Needle-nose pliers
• Magnetic pickup tool
• Shop flashlight
• Masking tape and marker
• Clean shop rags

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Ignition coil - Qty: 6 Replace as a complete set for best reliability
• Upper intake manifold gasket set - Qty: 1
• Throttle body gasket - Qty: 1
• Dielectric grease - Qty: 1 Moisture-proof electrical grease for boots
• Intake hose clamp - Qty: 1 Only if yours is damaged

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Open the hood and remove any loose jewelry/clothing that can snag.
• Use masking tape and a marker to label hoses and connectors as you unplug them (simple and prevents mix-ups).
• Disconnect the negative battery terminal using a 10mm socket and move it aside so it can’t spring back.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover and open up access

• Pull up on the engine cover to pop it off its grommets (no tools).
• Use a 7mm socket and 3/8" ratchet to loosen the air intake duct clamps.
• Use a flathead screwdriver if your clamps are screw-type.
• Remove the air intake duct and set it aside.

Step 2: Unplug and remove the front bank ignition coils

• On the front side of the engine, unplug each coil electrical connector by pressing the lock tab (don’t yank the wires).
• Use a 10mm socket with a 6" extension and 3/8" ratchet to remove the coil hold-down bolt.
• Twist the coil slightly, then pull it straight up to remove it from the spark plug.
• Torque to 10 Nm (89 in-lbs) when reinstalling coil bolts later. (A torque wrench is a tool that tightens bolts to a precise setting.)

Step 3: Label and disconnect intake manifold connections

• Use masking tape and marker to label each hose/connector you remove.
• Use needle-nose pliers to release spring clamps on small vacuum/PCV hoses (PCV hoses handle crankcase vapors).
• Use a trim clip removal tool to pop any harness retainers off the manifold without breaking them.
• Unplug sensors on/near the intake as needed by hand, using a flashlight to see the lock tabs.

Step 4: Remove the throttle body (to clear the manifold)

• Unplug the throttle body connector by hand (release tab first).
• Use an 8mm socket with a 6" extension and 3/8" ratchet to remove the throttle body bolts.
• Remove the throttle body and the old gasket. Do not drop anything into the opening.
• Tip: Cover the opening with a clean rag.
• Torque to 10 Nm (89 in-lbs) when reinstalling throttle body bolts.

Step 5: Remove the upper intake manifold

• Use a 10mm socket with a 12" extension, universal joint adapter (a “swivel” that helps reach angled bolts), and a 3/8" ratchet to remove the intake manifold bolts.
• If a bolt feels stuck, stop and re-seat the socket straight to avoid rounding it.
• Lift the intake manifold straight up and out.
• Immediately stuff clean shop rags into the exposed intake ports to prevent dropping hardware inside.
• Torque to 25 Nm (18 ft-lbs) when reinstalling intake manifold bolts.

Step 6: Remove the rear bank ignition coils

• With the manifold off, unplug each rear coil connector by hand.
• Use a 10mm socket with a 6" extension and 3/8" ratchet to remove each coil hold-down bolt.
• Twist and pull each coil straight up to remove.
• Use a magnetic pickup tool if you drop a bolt (don’t leave hardware in the valley).

Step 7: Install the new coils

• Put a small smear of dielectric grease inside each coil boot (the rubber part that grips the spark plug). This helps prevent moisture intrusion and makes future removal easier.
• Push each coil straight down until you feel it seat on the spark plug.
• Install each coil bolt using a 10mm socket and 3/8" ratchet, then tighten with a torque wrench.
• Torque to 10 Nm (89 in-lbs).
• Plug in all coil electrical connectors until they click.

Step 8: Reinstall the upper intake manifold with new gaskets

• Remove the clean shop rags from the intake ports (count them to be sure none are left behind).
• Install the new upper intake manifold gaskets onto the manifold.
• Set the manifold in place carefully without pinching wires or hoses.
• Start all manifold bolts by hand first to avoid cross-threading.
• Tighten manifold bolts evenly using a 10mm socket and 3/8" ratchet, then final-tighten with a torque wrench.
• Torque to 25 Nm (18 ft-lbs).

Step 9: Reinstall the throttle body, intake duct, and reconnect everything

• Install a new throttle body gasket and reinstall the throttle body using an 8mm socket.
• Torque to 10 Nm (89 in-lbs).
• Reconnect every labeled hose/connector (use your tape labels).
• Reinstall the air intake duct and tighten clamps using a 7mm socket or flathead screwdriver.
• Snap the engine cover back on.

Step 10: Reconnect the battery

• Reconnect the negative battery terminal using a 10mm socket.
• Make sure the terminal is snug and does not rotate by hand.

---

✅ After Repair

• Turn the key on (engine off) for 10 seconds, then off for 10 seconds, then start the engine. This helps the throttle system re-initialize after being unplugged.
• Let it idle for 2–3 minutes and listen for vacuum leaks (a loud hissing sound) around the intake manifold area.
• Verify the engine runs smooth and the check engine light stays off.
• Do a short test drive, then recheck for any loose clamps, disconnected hoses, or fuel/vapor smells.

---

💰 DIY vs Shop Cost

Shop Cost: $450–$950 (parts + labor)

DIY Cost: $180–$480 (parts only)

You Save: $270–$470 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2.5–4.5 hours.

---
