🔧 F-150 - Ignition Coil Replacement

Your A4—

Difficulty Level: Intermediate | Estimated Time: 1.0-2.5 hours

---

On your F-150, each cylinder uses a Coil-On-Plug (COP) ignition coil that sits directly on top of the spark plug. Replacing weak or failed coils can fix misfires, rough idle, flashing check engine light, and hesitation.

Difficulty Level: Beginner-Intermediate | Estimated Time: 1.0-2.0 hours (all 8 coils)

---

⚠️ Safety & Precautions

• 🧤 Let the engine cool fully before you start (hot exhaust/engine parts burn).
• 🔋 Disconnect the negative battery cable to prevent accidental shorts.
• 🧯 Do not pull on wiring—only on connectors and coil bodies.
• 🧼 Blow dirt out of the spark plug wells before removing coils to keep debris out of the engine.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 8mm socket
• 10mm socket
• 1/4" drive ratchet
• 1/4" drive extension set (3" and 6")
• Inch-pound torque wrench (0–120 in-lb range)
• Flathead screwdriver
• Trim clip removal tool
• Needle-nose pliers
• Compressed air blow gun
• Shop vacuum
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Ignition coil - Qty: 1 (or Qty: 8 if replacing all)
• Ignition coil boot - Qty: 1 (or Qty: 8 if replacing all)
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Open the hood and remove any loose items around the engine bay.
• Use a 10mm socket to disconnect the negative battery cable and move it aside.
• Tip: Do one coil at a time to avoid mixing connectors.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover (if equipped)

• Use an 8mm socket (or 10mm socket depending on cover) with a 1/4" drive ratchet to remove the engine cover fasteners.
• Lift the cover off and set it aside.

Step 2: Remove intake tubing only if it blocks access (passenger side)

• Use a flathead screwdriver to loosen the hose clamps on the intake tube.
• If there are push-pins/clips, remove them with a trim clip removal tool.
• Move the tube aside enough to access the coils.

Step 3: Clean around the coil and plug well

• Use a compressed air blow gun to blow dirt away from the coil area.
• If needed, use a shop vacuum to remove loose debris.
• Tip: Dirt in the well can cause future misfires.

Step 4: Unplug the ignition coil connector

• Press the locking tab and pull the connector straight off the coil.
• If the tab is stubborn, gently help it with a flathead screwdriver (do not break the lock).

Step 5: Remove the ignition coil hold-down bolt

• Use an 8mm socket with a 1/4" drive ratchet and a 1/4" drive extension (3" or 6") to remove the coil bolt.
• Set the bolt aside where it won’t get lost.

Step 6: Remove the ignition coil

• Grip the coil body and twist gently left-right to break the seal.
• Pull straight up to remove it from the spark plug well.
• If the boot sticks in the well, use needle-nose pliers to pull it out carefully.

Step 7: Prep the new coil/boot

• If you’re installing a new boot, push it onto the new coil until fully seated.
• Apply a small amount of dielectric grease inside the boot opening (this helps prevent moisture and makes future removal easier).
• Tip: Only a thin smear is needed.

Step 8: Install the new ignition coil

• Align the coil and push it straight down onto the spark plug until you feel it seat.
• Reinstall the hold-down bolt with an 8mm socket.
• Use an inch-pound torque wrench: Torque to 7 Nm (62 in-lb).

Step 9: Reconnect the electrical connector

• Push the connector on until it clicks/locks.
• Gently tug to confirm it’s fully latched.

Step 10: Repeat for the remaining coils

• Repeat Steps 3–9 for each coil you’re replacing.
• Tip: If one coil failed, consider replacing boots on all.

Step 11: Reinstall removed components

• Reinstall intake tubing using a flathead screwdriver for the clamps.
• Reinstall the engine cover using an 8mm socket or 10mm socket.

Step 12: Reconnect the battery

• Reconnect the negative battery cable using a 10mm socket.

---

✅ After Repair

• Start the engine and let it idle for 1–2 minutes. It should run smooth.
• If the check engine light was flashing before, it should stop flashing immediately if the misfire is fixed.
• Test drive for 10–15 minutes and watch for hesitation.
• If the check engine light stays on, the code may be stored—scan and clear it after confirming the repair.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$900 (parts + labor, depends on how many coils)

DIY Cost: $40-$480 (parts only, depends on how many coils)

You Save: $200-$450 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-2.0 hours.

---
