🔧 Tacoma - Ignition Coil Replacement

Ignition coils sit on top of each spark plug and create the high voltage needed for spark. Replacing a weak coil can fix misfires, rough running, and flashing check-engine lights.

Difficulty Level: Beginner | Estimated Time: 0.8-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Let the engine cool fully; coils sit near hot parts.
• ⚠️ Keep the key out of the truck while unplugging coils.
• ⚠️ If you disconnect the battery, you may lose radio presets.
• ⚠️ Don’t pull on wiring; press the connector tab and pull the plug body.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 3/8" drive ratchet
• 3" extension
• 6" extension
• Torque wrench (inch-pound)
• Flathead screwdriver
• Needle-nose pliers
• Trim clip removal tool
• Shop rags
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Ignition coil - Qty: 1 (or Qty: 6 to replace all)
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Open the hood and let the engine cool.
• If you’re replacing multiple coils, label them by cylinder with masking tape so nothing gets mixed up.
• Optional: Disconnect the negative battery cable using a 10mm socket.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover (if equipped)

• Lift the cover up to release the grommets. If your cover uses fasteners, remove them with a 10mm socket.

Step 2: Make space to reach the coils

• Loosen the air intake tube clamps with a flathead screwdriver.
• Unclip/remove any intake tube clips using a trim clip removal tool.
• Move the intake tube/air ducting aside for better access.
• Tip: Take a quick photo before moving hoses.

Step 3: Unplug the ignition coil connector

• Press the connector lock tab and pull the connector straight off the coil.
• If the tab is stubborn, gently help it with needle-nose pliers—do not crush it.
• Tip: Wiggle the connector, don’t yank.

Step 4: Remove the ignition coil hold-down bolt

• Remove the coil bolt using a 10mm socket, 3/8" drive ratchet, and a 3" extension (use a 6" extension if needed).

Step 5: Remove the ignition coil

• Twist the coil slightly, then pull it straight up to remove it from the spark plug tube.
• Wipe dirt away from the coil area using shop rags before installing the new coil.

Step 6: Install the new ignition coil

• Apply a very small amount of dielectric grease inside the rubber boot (this helps prevent sticking and moisture). Dielectric grease is a non-conductive silicone grease.
• Push the coil straight down until it fully seats on the spark plug.

Step 7: Reinstall and torque the coil bolt

• Install the bolt by hand first to avoid cross-threading.
• Tighten with a 10mm socket, then torque using a torque wrench (inch-pound).
• Torque to 9 N·m (80 in-lbs)

Step 8: Reconnect the coil electrical connector

• Push the connector on until it clicks.
• Gently tug-test the connector to confirm it’s locked.

Step 9: Repeat for other coils (if replacing more than one)

• Repeat Steps 3–8 for each additional coil.
• Tip: Replace one coil at a time to avoid mix-ups.

Step 10: Reassemble the intake parts and cover

• Reinstall the intake tube and any clips using a flathead screwdriver and trim clip removal tool.
• Reinstall the engine cover.
• If disconnected, reconnect the negative battery cable using a 10mm socket.

---

✅ After Repair

• Start the engine and let it idle for 1–2 minutes. It should run smooth.
• If the check-engine light was on, clear codes with a scan tool (or it may turn off after a few drive cycles if the problem is fixed).
• Test drive for 10–15 minutes and recheck that the intake tube clamps are snug and nothing is left loose.
• If a misfire returns, the next most common items are spark plugs or a wiring/connector issue at that coil.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$650 (parts + labor, depending on 1 coil vs all 6)

DIY Cost: $40-$420 (parts only, depending on 1 coil vs all 6)

You Save: $140-$230 by doing one coil yourself (more if doing all 6)!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.5 hours.

---
