Assumption: Your NX200t has LED low beams (not bulb-replaceable) and halogen high beams (bulb-replaceable). I’ll show both paths so you can complete the job without guessing.

🔧 NX - Headlight Bulb Replacement

On your NX, “headlight bulbs” can mean the high beams (replaceable bulbs) or the low beams (often LED modules that are not serviced as a bulb). Access is from under the hood behind each headlamp, and space is tight on one side.

Difficulty Level: Beginner | Estimated Time: 0.5-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Turn the light switch OFF and remove the key before starting.
• ⚠️ Let the headlight area cool; bulbs and housings get hot.
• ⚠️ Wear gloves; skin oil can shorten halogen bulb life.
• ⚠️ Do not touch the glass part of a halogen bulb.
• ⚠️ Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 1/4" ratchet
• 6" socket extension
• Trim clip removal tool
• Phillips screwdriver
• Flashlight
• Nitrile gloves
• Safety glasses
• Fender cover

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• High beam headlight bulbs - Replace in pairs - Qty: 2
• Dielectric grease (small packet) - Qty: 1
• Isopropyl alcohol wipes - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Open the hood and place a fender cover to protect paint.
• Lay out the new bulbs and keep them in the package until install.
• A trim clip tool removes plastic clips safely.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Identify what’s replaceable on your NX

• Use a flashlight to look at the back of each headlamp.
• If the low beam says LED and there is no removable bulb socket, the low beam is part of the headlamp assembly (not a bulb swap).
• If you see a round twist-lock bulb socket with a wiring plug, that position is bulb-replaceable (commonly the high beam).

Step 2: Create access room (passenger side)

• Use a 10mm socket, 1/4" ratchet, and 6" extension to loosen/remove the intake duct fasteners if they block access.
• Remove any plastic push-clips using a trim clip removal tool.
• Set the duct/trim aside carefully. Torque to 7.5 Nm (66 in-lbs) on reassembly.

Step 3: Create access room (driver side)

• If the windshield washer fill neck blocks access, use a 10mm socket and 1/4" ratchet to remove its retaining bolt.
• Gently pull the washer neck up/out of its grommet enough to reach the bulb area (do not yank the hose).
• Reinstall later and Torque to 5 Nm (44 in-lbs).

Step 4: Remove the old bulb (each side)

• Put on nitrile gloves and safety glasses.
• Reach behind the headlamp and unplug the connector by pressing the lock tab (use a flashlight to see the tab).
• Twist the bulb socket counterclockwise about 1/8–1/4 turn, then pull it straight out.
• Twist gently—plastic tabs can crack.

Step 5: Install the new bulb (each side)

• Keep the new bulb glass clean. If you touch it, clean with isopropyl alcohol wipes and let it dry.
• Insert the bulb into the housing, aligning the tabs, then twist clockwise until it locks.
• Apply a tiny amount of dielectric grease to the connector seal (not on the bulb glass), then reconnect the plug until it clicks.

Step 6: Reinstall removed ducts/covers

• Reinstall intake duct pieces using a 10mm socket, 1/4" ratchet, and 6" extension. Torque to 7.5 Nm (66 in-lbs).
• Reinstall any push-clips using a trim clip removal tool.
• If removed, reinstall the washer neck bolt using a 10mm socket. Torque to 5 Nm (44 in-lbs).

Step 7: If your low beams are LED (common on NX)

• If the “bulb” you’re trying to replace is actually the LED low beam, there is no service bulb to twist out.
• In that case, diagnosis is next (fuse/driver/module) and the repair may require headlamp assembly or LED driver service (depending on configuration).

---

✅ After Repair

• Turn the headlights ON and confirm both sides work on the correct setting (high beam vs low beam).
• Check that the bulb sits fully locked; a loose bulb can aim wrong and flicker.
• At night, verify beam aim looks even left-to-right on a wall.
• Keep the old working bulb as an emergency spare if only one was failed.

---

💰 DIY vs Shop Cost

Shop Cost: $120-$280 (parts + labor)

DIY Cost: $25-$90 (parts only)

You Save: $95-$190 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
