🔧 Atlas - Front Windshield Wiper Blade Replacement

Replacing the front wiper blades restores clear vision in rain and reduces streaking and chatter. On your Atlas, it’s easiest if you first move the wiper arms into “service position” so you can lift them safely.

Difficulty Level: Beginner | Estimated Time: 15-30 minutes

---

⚠️ Safety & Precautions

• ⚠️ Never let a wiper arm snap back onto the glass; it can crack the windshield.
• ⚠️ Keep fingers clear of the hinge area when lifting the arms.
• ⚠️ If the blades were just used, the glass and arms may be warm—use gloves.
• ⚠️ Battery disconnect is not required.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Nitrile gloves
• Safety glasses
• Microfiber towel
• Painter’s tape

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front wiper blades (match your Atlas’ current blade lengths and connector type) - Qty: 2

---

📋 Before You Begin

• Park on level ground and shift to Park.
• Turn the ignition ON, then OFF.
• Within about 10 seconds of switching OFF, tap the wiper stalk DOWN once to move the wipers to service position. Arms should stop partway up.
• Place a microfiber towel at the base of the windshield as extra protection.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Put the wipers in service position

• Turn ignition ON, then OFF.
• Within ~10 seconds, press the wiper stalk DOWN once to park the arms in service position.

Step 2: Lift the driver-side wiper arm

• Use nitrile gloves and lift the arm away from the glass until it stays up.
• Apply a small strip of painter’s tape on the windshield where the blade normally rests (optional reference point).

Step 3: Remove the old blade from the arm

• Hold the wiper arm with one hand so it can’t spring back.
• At the blade connector, find the small release tab and press it (usually a “pinch tab” style).
• Slide the blade down and away from the arm hook/adapter until it disconnects.
• If it’s stuck, wiggle while pressing the tab.

Step 4: Install the new driver-side blade

• Compare the new blade to the old one for matching length and connector style.
• Slide the new blade onto the arm connector until you hear/feel a click.
• Gently tug the blade to confirm it’s locked in place.

Step 5: Repeat for the passenger-side blade

• Use nitrile gloves and lift the passenger arm.
• Press the release tab and slide the old blade off.
• Click the new blade into place and tug-check it.

Step 6: Return the wipers to normal parked position

• Lower both arms carefully back onto the windshield (use the microfiber towel as protection while lowering if you want).
• Turn ignition ON and cycle the wipers once using the stalk to let them return to their normal park position.
• Remove any painter’s tape you used.

---

✅ After Repair

• Test washer + wipers on low speed and check for streaking or skipping.
• If there’s chatter, clean the glass and wipe the rubber edge with a damp microfiber towel.
• Confirm both blades are fully clicked in and not loose.

---

💰 DIY vs Shop Cost

Shop Cost: ₹800-₹2,000 (parts + labor)

DIY Cost: ₹600-₹1,600 (parts only)

You Save: ₹200-₹400 by doing it yourself!

Shop labor rates vary but typically run ₹600-₹1,200/hour. This repair takes a shop approximately 0.2-0.4 hours.

---
