🔧 Edge - Front Windshield Wiper Blade Replacement

On your Edge, the front wiper blades clip onto the wiper arms and can be replaced without removing any other parts. The key is getting the wiper arms into a safe “service position” so you don’t scratch the hood or let the arm snap into the glass.

Difficulty Level: Beginner | Estimated Time: 0.25-0.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Don’t let a bare wiper arm snap onto the windshield—cover the glass with a towel.
• ⚠️ Keep fingers clear of the hinge area when lifting the wiper arm (it’s spring-loaded).
• ⚠️ Turn ignition OFF before handling the blades unless placing wipers into service position.
• ⚠️ Battery disconnect is not required.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Mechanic gloves
• Microfiber towel
• Plastic trim tool (specialty)
• Tape measure (inch)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front wiper blades - Qty: 2

---

📋 Before You Begin

• Park on level ground and shift to Park.
• Have a microfiber towel ready to lay on the windshield under the wiper arms.
• Confirm your blade lengths: use a tape measure (inch) or read the size printed on the old blades.
• Put the wipers into service position (so the arms are away from the hood): try Method A, then Method B if needed.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Move the wiper arms to “service position”

• Method A (common Ford method): Turn ignition ON, then OFF. Within a few seconds, use the wiper stalk to do a single wipe (the “mist”/single-swipe position). The wipers should stop partway up the windshield.
• Method B (if Method A doesn’t work): Turn ignition ON and run the wipers, then turn ignition OFF when the blades are mid-sweep (partway up). This leaves them accessible.
• Place a microfiber towel on the windshield under the wiper area.
• If unsure, stop—tell me what the wipers do.

Step 2: Lift the first wiper arm safely

• Use mechanic gloves and lift the wiper arm away from the glass until it stays up.
• Keep the microfiber towel in place as a safety cushion.

Step 3: Remove the old blade from the arm

• Look at where the blade connects to the arm (the “connector”).
• If it has a top push-button: press the button with your thumb (or gently with a plastic trim tool (specialty)), then slide the blade down and off the hook/arm.
• If it has pinch tabs on the sides: squeeze the tabs with your fingers, then slide the blade off the arm.
• Avoid using metal tools here to prevent scratching.

Step 4: Install the new blade

• Match the new blade to the old one using a tape measure (inch) to confirm length.
• Slide the new blade onto the arm connector until it clicks/locks.
• Gently tug on the blade to confirm it’s fully latched.
• “Click + tug test” prevents fly-offs.

Step 5: Lower the wiper arm carefully

• Lower the arm back onto the windshield slowly by hand (don’t drop it).
• Repeat Steps 2–5 for the other side.

Step 6: Return wipers from service position

• Remove the microfiber towel.
• Turn ignition ON and use the wiper stalk to run the wipers once so they park normally.

---

✅ After Repair

• Test the wipers on low speed with washer fluid.
• Verify both blades wipe cleanly and don’t chatter or skip.
• If one blade isn’t wiping well, re-check that it’s clicked fully onto the connector.

---

💰 DIY vs Shop Cost

Shop Cost: $50-$120 (parts + labor)

DIY Cost: $25-$70 (parts only)

You Save: $25-$50 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.2-0.4 hours.

---
