🔧 Transit Connect - Front Windshield Wiper Blade Replacement

Replacing the front wiper blades keeps your windshield clear and prevents streaking and scratching. On your Transit Connect, the key is getting the wiper arms into “service position” so you can lift them safely.

Difficulty Level: Beginner | Estimated Time: 15-30 minutes

---

⚠️ Safety & Precautions

• ⚠️ Turn the ignition OFF before touching the wiper arms; they can move unexpectedly.
• ⚠️ Don’t let a bare wiper arm snap onto the glass—put a towel on the windshield to protect it.
• ⚠️ Lift the wiper arm gently; don’t force it past its natural hinge stop.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Clean shop towel
• Small flathead screwdriver

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front wiper blades - Replace in pairs - Qty: 2

---

📋 Before You Begin

• Park on level ground and shift to Park.
• Turn the ignition OFF and remove the key/fob from the cabin.
• Place a clean shop towel on the lower windshield area as a safety cushion.
• Assumption: blade lengths can vary by production/options; match the sizes printed on your old blades or measure them before buying.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Put the wipers in service position

• Use the ignition switch to turn the vehicle ON, then turn it OFF.
• Within a few seconds, use the wiper stalk to press and hold the wiper control to the mist/single-wipe position for about 2 seconds so the wipers park up on the glass (service position).
• If they don’t move up, use the wiper stalk to do one wipe, then turn ignition OFF when the arms are mid-sweep so you can lift them. Move slowly to avoid hitting the hood edge.

Step 2: Lift the driver-side wiper arm

• Use your hand to lift the wiper arm away from the windshield until it holds itself up.
• Keep the clean shop towel on the glass under the arm.

Step 3: Remove the old wiper blade

• At the blade’s connection point, locate the small release tab/clip.
• Use your fingers to press the tab; if it’s tight, use a small flathead screwdriver to gently help press the tab.
• Slide the blade down/off the end of the wiper arm (it will come off the hook or push-button mount depending on blade style).

Step 4: Install the new wiper blade

• Compare the new blade to the old one (same length and connector style).
• Slide/click the new blade onto the arm until you hear/feel a positive “click” lock.
• Gently tug the blade with your hand to confirm it is fully latched.

Step 5: Repeat on the passenger-side

• Use the same process to lift the arm, release the clip, remove the old blade, and click the new blade into place.

Step 6: Lower the arms and exit service position

• Carefully lower each arm back onto the windshield by hand (do not drop it).
• Remove the clean shop towel.
• Use the ignition switch to turn the vehicle ON, then use the wiper stalk for a quick wipe to return to normal parked position.

---

✅ After Repair

• Test washers and wipers at low speed, then high speed, using the wiper stalk.
• Check for streaks or chattering; if present, clean the windshield with glass cleaner and a towel.
• Re-check that both blades are fully clicked/locked if you hear any knocking.

---

💰 DIY vs Shop Cost

Shop Cost: $40-$90 (parts + labor)

DIY Cost: $20-$60 (parts only)

You Save: $20-$30 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.2-0.4 hours.

---
