🔧 Escape - Front Wheel Bearing/Hub Replacement

This repair replaces the front wheel bearing and hub assembly on your Escape. A worn wheel bearing can cause humming, growling, vibration, ABS warnings, or wheel play, and it should be replaced promptly because it supports the wheel while driving.

Difficulty Level: Advanced | Estimated Time: 2.5-4 hours per side

Assumption: This guide covers the front wheel bearing/hub assembly. Rear bearing service on AWD is different.

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground only, and support your Escape with jack stands before removing the wheel.
• ⚠️ Never rely on a floor jack by itself. A floor jack lifts; jack stands hold the vehicle safely.
• ⚠️ The axle nut is very tight. Loosen it only with the vehicle secure and the wheel prevented from turning.
• ⚠️ Do not let the brake caliper hang by the brake hose. Support it with mechanic’s wire or a bungee cord.
• ⚠️ Keep the wheel speed sensor wiring safe. Damaging it can trigger ABS and traction control lights.
• ⚠️ Replace the axle nut with a new one. It is designed for one-time use.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 1/2-inch drive breaker bar
• 1/2-inch drive torque wrench rated to 250 ft-lbs
• 3/8-inch drive torque wrench rated to 100 ft-lbs
• 21mm socket
• 32mm axle nut socket
• 18mm socket
• 15mm socket
• 13mm socket
• 10mm socket
• 8mm socket
• Ratchet handle
• 6-inch socket extension
• Flathead screwdriver
• Needle-nose pliers
• Dead-blow hammer
• Ball-peen hammer
• Brass drift punch
• Hub puller kit (specialty)
• Axle pusher tool (specialty)
• Brake caliper hanger
• Wire brush
• Brake cleaner spray
• Floor jack rated 3-ton minimum
• Jack stands rated 3-ton minimum
• Wheel chocks
• Mechanic’s gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front wheel bearing and hub assembly - Qty: 1 per side
• Front axle nut - Qty: 1 per side
• Brake cleaner - Qty: 1 can
• Anti-seize compound - Qty: 1 small tube

---

📋 Before You Begin

• 🚗 Park your Escape on flat, solid ground.
• 🅿️ Shift to Park and apply the parking brake.
• 🧱 Place wheel chocks behind the rear wheels.
• 🔌 No battery disconnect is normally required for this front wheel bearing replacement.
• 📌 A hub assembly is the wheel bearing and wheel mounting flange built into one service part.
• 📌 A torque wrench tightens bolts to the correct force so parts are safe and not over-tightened.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Wheel Lug Nuts

• Use the 21mm socket and 1/2-inch drive breaker bar to loosen the front wheel lug nuts about one turn.
• Do not remove the lug nuts yet.
• Loosen before lifting the vehicle.

Step 2: Loosen the Front Axle Nut

• Use the 32mm axle nut socket and 1/2-inch drive breaker bar to loosen the front axle nut.
• Have a helper press the brake pedal, or carefully reinstall two lug nuts and use a pry bar through the wheel studs to stop the hub from turning.
• Do not fully remove the axle nut yet.

Step 3: Raise and Support Your Escape

• Use the floor jack rated 3-ton minimum to lift the front of your Escape at the proper front jacking point.
• Place jack stands rated 3-ton minimum under the front support points.
• Lower the vehicle gently onto the jack stands.
• Shake the vehicle lightly by hand to confirm it is stable.

Step 4: Remove the Wheel

• Use the 21mm socket and ratchet handle to remove the loosened lug nuts.
• Remove the front wheel and place it flat under the vehicle as an extra safety backup.

Step 5: Remove the Brake Caliper

• Use the 15mm socket and ratchet handle to remove the brake caliper slide-pin bolts.
• Lift the brake caliper off the rotor.
• Use the brake caliper hanger to hang the caliper from the strut spring.
• Do not stretch, twist, or pull on the brake hose.

Step 6: Remove the Brake Caliper Bracket

• Use the 18mm socket and 1/2-inch drive breaker bar to remove the caliper bracket bolts.
• Remove the caliper bracket and set it aside.
• During reassembly, use the 18mm socket and 3/8-inch drive torque wrench to tighten the caliper bracket bolts to Torque to 175 Nm (129 ft-lbs).

Step 7: Remove the Brake Rotor

• Pull the brake rotor straight off the hub by hand.
• If it is stuck, use the dead-blow hammer to tap around the rotor hat until it loosens.
• Do not hit the braking surface hard.

Step 8: Disconnect the Wheel Speed Sensor Wire

• Use the flathead screwdriver to gently release the wheel speed sensor wire clips from the knuckle.
• Use the 8mm socket or 10mm socket to remove the wheel speed sensor retaining bolt if sensor access is needed.
• A wheel speed sensor tells the ABS system how fast the wheel is turning.
• Move the wiring safely away from the hub area.

Step 9: Remove the Axle Nut

• Use the 32mm axle nut socket and ratchet handle to remove the axle nut fully.
• Discard the old axle nut.
• Do not reuse it.

Step 10: Push the Axle Inward

• Install the axle pusher tool (specialty) onto the hub following the tool instructions.
• Use the ratchet handle to press the axle splines inward slightly.
• If using a punch, use the brass drift punch and ball-peen hammer to tap the axle end gently.
• Do not mushroom or damage the axle threads.

Step 11: Remove the Hub Assembly Bolts

• From the back side of the steering knuckle, use the 13mm socket, 6-inch socket extension, and ratchet handle to remove the hub mounting bolts.
• If the bolts are tight, use the 1/2-inch drive breaker bar with the correct socket setup.
• Keep the bolts organized so you can compare them with the replacements if included.

Step 12: Remove the Old Hub Assembly

• Install the hub puller kit (specialty) onto the wheel studs.
• Use the ratchet handle to pull the hub assembly out of the steering knuckle.
• If it is rusted in place, use the dead-blow hammer to tap around the hub flange while applying puller tension.
• Do not pry against the wheel speed sensor tone area.

Step 13: Clean the Mounting Surface

• Use the wire brush to clean rust and dirt from the hub mounting bore.
• Use brake cleaner spray to clean the area.
• Apply a very thin film of anti-seize compound to the knuckle bore by hand while wearing mechanic’s gloves.
• Keep anti-seize away from the wheel studs, brake rotor surface, and sensor area.

Step 14: Install the New Hub Assembly

• Slide the new front wheel bearing and hub assembly into the steering knuckle by hand.
• Align the axle splines through the hub carefully.
• Start all hub bolts by hand first to avoid cross-threading.
• Use the 13mm socket, 6-inch socket extension, and 3/8-inch drive torque wrench to tighten the hub mounting bolts to Torque to 115 Nm (85 ft-lbs).

Step 15: Install the New Axle Nut

• Thread the new front axle nut on by hand.
• Use the 32mm axle nut socket and 1/2-inch drive torque wrench rated to 250 ft-lbs to tighten the axle nut to Torque to 258 Nm (190 ft-lbs).
• Do not use an impact gun for final tightening.

Step 16: Reconnect the Wheel Speed Sensor Wire

• Route the wheel speed sensor wire exactly as it was before.
• Use the flathead screwdriver to help seat the wire clips gently.
• If removed, use the 8mm socket or 10mm socket to reinstall the sensor retaining bolt snugly.
• Make sure the wire cannot rub the axle, rotor, or tire.

Step 17: Reinstall the Brake Rotor

• Use brake cleaner spray to clean the rotor braking surfaces.
• Slide the rotor back onto the hub by hand.
• Install one lug nut finger-tight to hold the rotor in place.

Step 18: Reinstall the Caliper Bracket

• Place the caliper bracket over the rotor.
• Start the bracket bolts by hand.
• Use the 18mm socket and 3/8-inch drive torque wrench to tighten the caliper bracket bolts to Torque to 175 Nm (129 ft-lbs).

Step 19: Reinstall the Brake Caliper

• Place the brake caliper back over the rotor and bracket.
• Use the 15mm socket and 3/8-inch drive torque wrench to tighten the caliper slide-pin bolts to Torque to 35 Nm (26 ft-lbs).
• Confirm the brake hose is not twisted.

Step 20: Reinstall the Wheel

• Remove the temporary lug nut holding the rotor.
• Install the wheel onto the hub.
• Use the 21mm socket and ratchet handle to snug the lug nuts in a star pattern.

Step 21: Lower and Torque the Wheel

• Use the floor jack rated 3-ton minimum to lift the vehicle slightly off the jack stands.
• Remove the jack stands rated 3-ton minimum.
• Lower your Escape until the tire just touches the ground.
• Use the 21mm socket and 1/2-inch drive torque wrench to tighten the lug nuts in a star pattern to Torque to 135 Nm (100 ft-lbs).
• Fully lower the vehicle.

---

✅ After Repair

• ✅ Pump the brake pedal several times before driving so the caliper seats correctly.
• ✅ Start your Escape and check that the ABS and traction control lights turn off after a short drive.
• ✅ Test drive at low speed first, then gradually increase speed while listening for noise.
• ✅ Recheck for rubbing sounds, vibration, brake drag, or warning lights.
• ✅ After 25-50 miles, recheck wheel lug nut torque to 135 Nm (100 ft-lbs).
• ✅ If the ABS light remains on, scan the ABS module before replacing more parts.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$750 per front side (parts + labor)

DIY Cost: $120-$280 per front side (parts only)

You Save: $330-$470 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours per side.

---
