🔧 Titan - Front Ball Joints Replacement

On your Titan, “all ball joints” effectively means the front upper and front lower ball joints on both sides. On most Titans, the ball joints are serviced with the control arm assemblies (ball joint comes attached), so you replace the arms rather than pressing only the joint.

Difficulty Level: Advanced | Estimated Time: 4-8 hours

---

⚠️ Safety & Precautions

• 🧯 Support the truck on jack stands; never rely on a jack.
• 🧤 Wear eye protection; ball joint separations can “pop” loose suddenly.
• 🛑 Do not let the steering knuckle hang by the brake hose/ABS wire; support it with a bungee cord.
• 🔥 If you just drove, let brakes/rotors cool before working.
• 🔋 Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Lug nut socket 22mm
• Ratchet 3/8"
• Ratchet 1/2"
• Socket set 10mm-24mm
• Wrench set 10mm-24mm
• Breaker bar 24"
• Torque wrench 20-250 ft-lbs
• Needle-nose pliers
• Cotter pin puller
• Ball joint separator (specialty)
• Hammer 2 lb
• Pry bar 24"
• Bungee cord
• Penetrating oil
• Paint marker
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front upper control arm assembly (with ball joint) - Qty: 2
• Front lower control arm assembly (with ball joint) - Qty: 2
• Cotter pins assortment - Qty: 1
• New lower ball joint castle nuts - Qty: 2
• New upper ball joint nuts - Qty: 2

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels.
• Loosen the front lug nuts with a 22mm socket before lifting.
• Lift the front and support the frame on jack stands; keep the front suspension hanging.
• Spray penetrating oil on ball joint nuts and control-arm bolts and let it soak.
• Use a paint marker to mark cam bolts/adjusters (if equipped). Helps keep alignment close.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the wheels

• Remove lug nuts using a 22mm socket and breaker bar, then remove both front wheels.

Step 2: Support the steering knuckle

• Hook a bungee cord from the knuckle to the frame to prevent strain on the brake hose/ABS wire.

Step 3: Disconnect the front upper ball joint from the knuckle

• Remove the upper ball joint cotter pin using needle-nose pliers.
• Remove the upper ball joint nut using the correct socket/wrench.
• Separate the joint from the knuckle using a ball joint separator (specialty).

Step 4: Remove the front upper control arm

• Locate the upper control arm frame bolts and remove them using a ratchet and socket set.
• Remove the upper control arm from the truck.

Step 5: Install the new front upper control arm

• Position the new arm and install the frame bolts by hand using your socket set.
• Insert the upper ball joint stud into the knuckle and install the nut using the correct socket.
• Install a new cotter pin using needle-nose pliers.

Step 6: Disconnect the front lower ball joint from the knuckle

• Remove the lower ball joint cotter pin using needle-nose pliers.
• Remove the castle nut using a breaker bar and correct socket.
• Use the ball joint separator (specialty) to separate the lower ball joint from the knuckle.
• If it’s stubborn, strike the side of the knuckle boss with a 2 lb hammer (not the stud). Sharp hits work better.

Step 7: Remove the front lower control arm

• Support the lower arm with the floor jack to control spring/strut tension.
• Remove the lower control arm mounting bolts using a breaker bar and socket set.
• Work the arm out of position using a pry bar 24" as needed.

Step 8: Install the new front lower control arm

• Position the new arm and install the frame bolts by hand using your socket set.
• Guide the lower ball joint stud into the knuckle and install the new castle nut using the correct socket.
• Install a new cotter pin using needle-nose pliers.

Step 9: Final tightening at ride height

• Put the wheels back on and snug lug nuts using a 22mm socket.
• Lower the truck so the suspension is at normal ride height.
• Tighten the control arm pivot bolts using a torque wrench to prevent bushing preload damage.
• Tighten lug nuts using a torque wrench: Torque to 133 Nm (98 ft-lbs).

---

✅ After Repair

• Road test at low speed first; listen for clunks and verify the steering feels normal.
• Recheck for any looseness by shaking the tire at 12-and-6 o’clock with the truck safely lifted on jack stands.
• Get a 4-wheel alignment immediately. Control arm replacement changes alignment.

---

💰 DIY vs Shop Cost

Shop Cost: $1,200-$2,800 (parts + labor)

DIY Cost: $500-$1,600 (parts only)

You Save: $700-$1,200 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 4-6 hours.

---
