🔧 Escape - Shock/Strut Replacement

On your Escape, the front suspension uses struts (shock + spring as one unit), and the rear uses separate shock absorbers. Replacing worn shocks/struts restores ride control, braking stability, and prevents uneven tire wear.

Difficulty Level: Intermediate | Estimated Time: 3-6 hours (rear only: 1.5-3 hours)

---

⚠️ Safety & Precautions

• ⚠️ Support the Escape with jack stands; never rely on a floor jack.
• ⚠️ If replacing front struts without “quick-struts”, a coil spring compressor is required. The spring is stored energy and can cause serious injury if released.
• ⚠️ Keep hands clear when lowering/raising the steering knuckle; don’t let it hang by the brake hose or ABS wire.
• ⚠️ After front strut replacement, a 4-wheel alignment is strongly recommended.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Lug nut socket 19mm
• Breaker bar 1/2"
• Torque wrench 20–250 Nm (15–185 ft-lbs)
• Socket set 8mm–21mm (1/2" drive)
• Wrench set 8mm–21mm
• Torx bit set (T30–T50)
• Pry bar 18"
• Hammer 16 oz
• Punch set 6mm–10mm
• Needle-nose pliers
• Penetrating oil
• Paint marker
• Coil spring compressor (specialty)
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front strut assemblies (quick-struts, complete) - Replace in pairs - Qty: 2
• Rear shock absorbers - Replace in pairs - Qty: 2
• Front strut upper mount nuts - Qty: 6
• Front strut-to-knuckle nuts/bolts - Qty: 4
• Rear shock upper nuts - Qty: 4
• Rear shock lower bolts/nuts - Qty: 2
• Anti-seize compound - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels (for front work) or front wheels (for rear work).
• Use a 19mm socket to loosen lug nuts 1/2 turn before lifting.
• Spray penetrating oil on the strut-to-knuckle bolts (front) and shock bolts (rear) and let it soak 10 minutes.
• If you are not using complete quick-struts: confirm you have a coil spring compressor (a tool that safely squeezes the spring so it can be removed).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and remove the wheel

• Use a floor jack (rated 3-ton minimum) to lift at the correct jack point and set the vehicle on jack stands.
• Remove the wheel using a 19mm socket.

Step 2 (Front): Disconnect brackets and sway bar link from the strut

• Remove the brake hose/ABS wire brackets from the strut using a socket set 8mm–21mm and/or Torx bit set (T30–T50) (hardware varies by bracket).
• Remove the sway bar end link nut at the strut using a wrench set 8mm–21mm and socket set 8mm–21mm.
• Tip: Hold the stud with Torx if it spins.

Step 3 (Front): Separate the strut from the steering knuckle

• Support the steering knuckle lightly with the floor jack so it doesn’t drop.
• Mark the strut-to-knuckle position with a paint marker for a reference line.
• Remove the two strut-to-knuckle bolts/nuts using a breaker bar 1/2" and socket set 8mm–21mm.
• Tap bolts out using a hammer 16 oz and punch set 6mm–10mm.
• Pull the knuckle away from the strut using a pry bar 18" if needed.
• Torque to 185 Nm (136 ft-lbs) for strut-to-knuckle fasteners (final tighten during reassembly).

Step 4 (Front): Remove the strut from the body

• Open the hood.
• Remove the strut upper mount nuts using a socket set 8mm–21mm while holding the strut from below.
• Lower and remove the strut assembly from the wheel well.
• Torque to 25 Nm (18 ft-lbs) for upper mount nuts (final tighten during reassembly).

Step 5 (Front option A): Install complete quick-strut assembly

• Position the quick-strut into the tower and start the upper nuts by hand using a socket set 8mm–21mm.
• Slide the strut into the knuckle and install the two lower bolts/nuts using a socket set 8mm–21mm and breaker bar 1/2".
• Reconnect the sway bar end link using a wrench set 8mm–21mm and socket set 8mm–21mm.
• Reinstall brake hose/ABS brackets using a socket set 8mm–21mm and/or Torx bit set (T30–T50).
• Final-tighten fasteners with a torque wrench:
  Upper mount nuts: 25 Nm (18 ft-lbs)
  Strut-to-knuckle: 185 Nm (136 ft-lbs)

Step 6 (Front option B): If reusing springs (not quick-struts)

• Install a coil spring compressor (specialty) on the spring and compress evenly until the spring is loose in the seats.
• Remove the strut shaft top nut using a socket set 8mm–21mm and wrench set 8mm–21mm.
• Transfer spring, upper mount, bearing, boot, and bump stop to the new strut.
• Slowly release the compressor, ensuring the spring ends sit correctly in the upper and lower seats.
• Tip: If anything looks crooked, stop and re-seat.

Step 7 (Rear): Access the upper shock mounts

• Open the rear cargo area.
• Remove the rear side trim access panels as needed using a trim tool (use needle-nose pliers carefully if needed) and needle-nose pliers.
• Locate the rear shock upper nuts.

Step 8 (Rear): Remove the rear shock

• Lift the rear and support with jack stands, then remove the wheel using a 19mm socket.
• Support the rear suspension arm lightly with the floor jack.
• Remove the lower shock bolt using a breaker bar 1/2" and socket set 8mm–21mm.
• Remove the upper shock nuts using a socket set 8mm–21mm, then pull the shock out.
• Torque to 115 Nm (85 ft-lbs) for the lower shock bolt (final tighten during reassembly).
• Torque to 35 Nm (26 ft-lbs) for upper shock nuts (final tighten during reassembly).

Step 9 (Rear): Install the new rear shock

• Install the shock into the upper mount and hand-start the nuts using a socket set 8mm–21mm.
• Align the lower mount and install the lower bolt using a socket set 8mm–21mm and breaker bar 1/2".
• Final-tighten with a torque wrench:
  Upper shock nuts: 35 Nm (26 ft-lbs)
  Lower shock bolt: 115 Nm (85 ft-lbs)

Step 10: Reinstall wheels and lower the vehicle

• Reinstall wheels using a 19mm socket.
• Lower the vehicle and torque lug nuts in a star pattern using a torque wrench: 135 Nm (100 ft-lbs).

---

✅ After Repair

• Test drive at low speed first and listen for clunks or rattles over small bumps.
• Re-check all visible fasteners and brackets after the first short drive.
• Get a 4-wheel alignment as soon as possible if you replaced the front struts.
• If the steering wheel is off-center or it pulls, stop and schedule alignment immediately.

---

💰 DIY vs Shop Cost

Shop Cost: $800-$1,600 (parts + labor, front + rear)

DIY Cost: $250-$900 (parts only, depending on quick-struts and brand)

You Save: $550-$700+ by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 3-5 hours.

---
