🔧 Front Strut Assembly - Replacement

This job replaces the front strut assembly to restore ride control, reduce bouncing, and fix clunks or uneven tire wear. On your Outback, the safest beginner-friendly approach is to replace the complete strut assembly, then repeat the same steps on the other side.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• Use jack stands on solid ground. Never work under a vehicle held up only by a jack.
• The spring is under high tension. Replace the complete strut assembly if possible. Do not disassemble the spring without a spring compressor.
• Support the steering knuckle so brake hose and CV axle are not stretched.
• Mark camber bolt positions before removal if your front bolts have alignment cams.
• An alignment is required after this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Breaker bar
• 21mm lug wrench
• 14mm socket
• 17mm socket
• 19mm socket
• 14mm wrench
• 17mm wrench
• Torque wrench
• Ratchet
• Penetrating oil
• Bungee cord or hanger
• Paint marker
• Safety glasses
• Gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front strut assembly - Qty: 2
• Front strut mount nuts - Qty: 6
• Front lower strut-to-knuckle nuts and bolts - Qty: 2 sets
• Front stabilizer link nuts - Qty: 2

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels.
• Break the front lug nuts loose before lifting the vehicle.
• Spray the lower strut bolts and top mount nuts with penetrating oil ahead of time.
• Have the replacement strut ready before teardown.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the vehicle

• Use a floor jack to lift the front of the Outback at the proper jacking point.
• Place jack stands under the pinch welds or approved support points.
• Remove the wheel with a 21mm lug wrench.

Step 2: Free the strut from the steering knuckle

• Use a 17mm socket and 17mm wrench to remove the lower strut bolts and nuts.
• Mark the bolt positions with a paint marker before removal if camber bolts are fitted.
• Support the knuckle with a bungee cord or hanger so the brake hose is not pulled tight.

Step 3: Disconnect the stabilizer link and brackets

• Use a 14mm wrench or 14mm socket to remove the stabilizer link nut from the strut.
• Remove any brake hose or wire brackets attached to the strut with a 14mm socket.

Step 4: Remove the upper strut mounts

• Open the hood and locate the three upper strut mount nuts.
• Use a 14mm socket to remove the upper nuts while holding the strut assembly from below.
• Lower the old strut assembly out of the wheel well.

Step 5: Install the new strut assembly

• Raise the new strut into position and start the upper nuts by hand with a 14mm socket.
• Align the lower holes with the knuckle and install the lower bolts and nuts using a 17mm socket and 17mm wrench.
• Torque the upper strut mount nuts to 39 Nm (29 ft-lbs).

Step 6: Reconnect the lower hardware

• Reconnect the stabilizer link using a 14mm wrench.
• Reinstall brake hose and wire brackets with a 14mm socket.
• Torque the lower strut-to-knuckle fasteners to 177 Nm (131 ft-lbs).
• Torque the stabilizer link nut to 44 Nm (32 ft-lbs).

Step 7: Reinstall the wheel and repeat

• Install the wheel and hand-tighten the lug nuts.
• Lower the vehicle and use a torque wrench to tighten the lug nuts in a star pattern.
• Torque the lug nuts to 120 Nm (89 ft-lbs).
• Repeat the same repair on the other front side.

---

✅ After Repair

• Test drive slowly and listen for clunks or rubbing.
• Check that the steering wheel is centered and the vehicle tracks straight.
• Schedule a professional wheel alignment as soon as possible.
• Recheck lug nut torque after 50-100 miles.

---

💰 DIY vs Shop Cost

Shop Cost: $700-$1,400 (parts + labor)

DIY Cost: $220-$520 (parts only)

You Save: $480-$880 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-4 hours.

---
