🔧 Escape - Front Strut Assembly Replacement

Replacing the front struts on your Escape improves ride comfort, braking stability, steering feel, and tire contact with the road. For a first-time DIYer, the safest approach is to replace the full front strut assemblies, also called “quick struts,” because they come preassembled with the spring, mount, and bearing.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• ⚠️ Replace front struts in pairs so your Escape handles and brakes evenly.
• ⚠️ Do not remove the large center nut on the old strut assembly. That nut holds the coil spring under heavy pressure.
• ⚠️ Use complete strut assemblies if you are a beginner. A coil spring compressor is a specialty tool that compresses the spring safely, but it can be dangerous if used incorrectly.
• ⚠️ Always support your Escape with jack stands. Never work under or beside a vehicle supported only by a floor jack.
• ⚠️ Do not let the brake hose or ABS sensor wire stretch while the strut is disconnected.
• ⚠️ A wheel alignment is required after strut replacement.
• ⚠️ Battery disconnect is not required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 19mm lug nut socket
• 10mm socket
• 13mm socket
• 15mm socket
• 18mm socket
• 21mm socket
• 15mm wrench
• 18mm wrench
• 21mm wrench
• 3/8-inch ratchet
• 1/2-inch breaker bar
• Torque wrench 20-250 Nm
• Pry bar 18-inch
• Hammer 16-ounce
• Paint marker
• Flat-blade screwdriver
• Needle-nose pliers
• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front complete strut assemblies - Qty: 2
• Front strut-to-knuckle bolts and nuts - Qty: 4
• Front strut upper mounting nuts - Qty: 6
• Front stabilizer bar link nuts - Qty: 2

---

📋 Before You Begin

• 🅿️ Park your Escape on a flat, solid surface.
• 🧱 Place wheel chocks behind the rear wheels.
• 🔩 Loosen the front wheel lug nuts before lifting your Escape.
• 📦 Compare the new strut assemblies with the old ones before installation. Make sure the left and right sides match correctly.
• 📐 Plan for a professional alignment after the repair.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Lug Nuts

• Use a 19mm lug nut socket and 1/2-inch breaker bar to loosen each front lug nut about one turn.
• Do not remove the lug nuts yet.
• Loosen before lifting.

Step 2: Raise and Support Your Escape

• Use a floor jack rated 2-ton minimum to lift the front of your Escape.
• Place jack stands rated 2-ton minimum under the front support points.
• Lower your Escape gently onto the jack stands.
• Give the vehicle a light shake by hand to confirm it is stable.

Step 3: Remove the Front Wheels

• Use a 19mm lug nut socket and 3/8-inch ratchet to remove the loosened lug nuts.
• Remove both front wheels.
• Slide the wheels flat under the side of the vehicle as an extra safety backup.

Step 4: Mark the Current Strut Position

• Use a paint marker to draw alignment marks where the lower strut bracket meets the steering knuckle.
• The steering knuckle is the heavy metal part that holds the wheel hub and brake assembly.
• This will not replace an alignment, but it helps keep your Escape close enough to drive carefully to an alignment shop.

Step 5: Remove the Brake Hose and ABS Wire Brackets

• Use a 10mm socket and 3/8-inch ratchet to remove the brake hose bracket bolt from the strut if equipped.
• Use a flat-blade screwdriver or needle-nose pliers to release the ABS wire clip from the strut.
• Move the hose and wire aside gently.
• Do not pull, twist, or stretch the brake hose.

Step 6: Disconnect the Stabilizer Bar Link

• Use a 15mm socket and 3/8-inch ratchet to remove the stabilizer bar link nut from the strut bracket.
• If the link stud spins, hold it with a 15mm wrench while turning the nut with the 15mm socket.
• The stabilizer bar link connects the suspension to the sway bar, which helps reduce body lean in turns.

Step 7: Support the Lower Control Arm

• Place the floor jack rated 2-ton minimum lightly under the lower control arm.
• The lower control arm is the lower suspension arm connected to the wheel hub area.
• Raise the jack only until it lightly supports the suspension.
• Do not lift your Escape off the jack stand.

Step 8: Remove the Lower Strut-to-Knuckle Bolts

• Use an 18mm wrench on the bolt head and a 21mm socket with the 1/2-inch breaker bar on the nut.
• Remove the two lower strut-to-knuckle nuts.
• Use a hammer 16-ounce to tap the bolts out if they are tight.
• Use a pry bar 18-inch gently if the strut bracket sticks to the steering knuckle.

Step 9: Remove the Upper Strut Mount Nuts

• Open the hood.
• Find the three upper strut mount nuts at the top of the strut tower.
• Use a 13mm socket and 3/8-inch ratchet to remove the three nuts.
• Support the strut assembly with one hand while removing the last nut.
• Do not remove the center nut on the strut.

Step 10: Remove the Old Strut Assembly

• Lower the strut assembly out through the wheel opening by hand.
• Watch the brake hose and ABS wire so they do not get pulled.
• Set the old strut upright on the ground.

Step 11: Install the New Complete Strut Assembly

• Guide the new front complete strut assembly into place through the wheel opening.
• Line up the upper studs with the holes in the strut tower.
• Install the three new upper mounting nuts by hand first.
• Use a 13mm socket and torque wrench 20-250 Nm to tighten the upper strut mount nuts to Torque to 35 Nm (26 ft-lbs).

Step 12: Reconnect the Strut to the Steering Knuckle

• Use the floor jack rated 2-ton minimum to raise or lower the suspension slightly until the bolt holes line up.
• Use a pry bar 18-inch gently if the knuckle needs small adjustment.
• Install the new lower strut-to-knuckle bolts and nuts by hand.
• Use an 18mm wrench, 21mm socket, and torque wrench 20-250 Nm to tighten the lower fasteners to Torque to 175 Nm (129 ft-lbs).

Step 13: Reconnect the Stabilizer Bar Link

• Insert the stabilizer bar link stud into the strut bracket.
• Install the new nut by hand.
• Use a 15mm wrench, 15mm socket, and torque wrench 20-250 Nm to tighten the stabilizer bar link nut to Torque to 55 Nm (41 ft-lbs).

Step 14: Reattach the Brake Hose and ABS Wire

• Use a 10mm socket and 3/8-inch ratchet to reinstall the brake hose bracket bolt if equipped.
• Clip the ABS wire back into the strut bracket by hand.
• Turn the steering from side to side by hand and make sure the hose and wire do not pull tight.

Step 15: Repeat the Repair on the Other Side

• Repeat Steps 4-14 for the other front strut.
• Use the same tools and torque specifications.
• Do one side at a time.

Step 16: Reinstall the Front Wheels

• Place each front wheel back onto the hub.
• Install the lug nuts by hand first to avoid cross-threading.
• Use a 19mm lug nut socket and 3/8-inch ratchet to snug the lug nuts in a star pattern.
• A star pattern means tightening every other lug nut so the wheel seats evenly.

Step 17: Lower Your Escape and Torque the Lug Nuts

• Use the floor jack rated 2-ton minimum to lift your Escape slightly off the jack stands.
• Remove the jack stands rated 2-ton minimum.
• Lower your Escape until the tires touch the ground.
• Use a 19mm lug nut socket and torque wrench 20-250 Nm to tighten the lug nuts to Torque to 135 Nm (100 ft-lbs) in a star pattern.

---

✅ After Repair

• ✅ Bounce the front of your Escape gently. It should settle quickly without repeated bouncing.
• ✅ Start with a slow test drive around the block.
• ✅ Listen for clunks, rattles, popping, or rubbing noises.
• ✅ Recheck that the brake hoses and ABS wires are secure and not stretched.
• ✅ Get a professional wheel alignment as soon as possible.
• ✅ Recheck lug nut torque after 25-50 miles.

---

💰 DIY vs Shop Cost

Shop Cost: $750-$1,250 (parts + labor)

DIY Cost: $250-$550 (parts only)

You Save: $500-$700 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
