🔧 TITAN XD - Shock Absorber/Strut Replacement

On your TITAN XD, the rear uses traditional shock absorbers, while the front uses a strut assembly (a shock + coil spring together). Replacing worn shocks/struts restores ride control, reduces bouncing, and improves braking stability.

Difficulty Level: Rear: Beginner | Front: Advanced | Estimated Time: Rear: 1-2 hours | Front: 3-5 hours

Assumption: You’re replacing both rear shocks and/or both front struts (pairs).

---

⚠️ Safety & Precautions

• 🛑 Support the truck with jack stands—never rely on a floor jack.
• 🛑 Chock the wheels with wheel chocks before lifting.
• 🛑 Front struts contain a compressed spring; if you don’t buy complete strut assemblies, you must use a coil spring compressor (a tool that squeezes the spring safely).
• 🛑 If you remove front struts, get a professional alignment afterward.
• 🛑 Keep hands clear when lowering/raising the suspension with the jack.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• Socket set (10mm-22mm)
• Wrench set (10mm-22mm)
• 1/2" drive breaker bar
• 1/2" drive torque wrench (30-250 ft-lbs)
• Pry bar (24")
• Needle-nose pliers
• Flat trim tool
• Penetrating oil
• Paint marker
• Rubber mallet
• Coil spring compressor (specialty)
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear shock absorbers - Replace in pairs - Qty: 2
• Front strut assemblies (complete/loaded) - Replace in pairs - Qty: 2
• Front strut mount nuts (if required) - Qty: 6
• Front strut-to-knuckle bolts/nuts (if required) - Qty: 4
• Rear shock mounting hardware (if required) - Qty: 1 set

---

📋 Before You Begin

• 🅿️ Park on level ground, shift to P, and set the parking brake.
• 🧱 Place wheel chocks at the wheels staying on the ground.
• 🔩 Use a 21mm socket to loosen lug nuts 1/2 turn before lifting.
• 🧴 Spray penetrating oil on shock/strut bolts and let it soak 5–10 minutes.
• 🖊️ Use a paint marker to mark any cam/adjusting bolt positions (if equipped) before removal.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the truck

• Use a floor jack (rated 3-ton minimum) to lift the end you’re working on.
• Place jack stands (rated 3-ton minimum) under the frame and lower onto them.
• Remove the wheel using a 21mm socket.

Step 2 (Rear): Support the rear axle

• Place the floor jack (rated 3-ton minimum) under the rear axle tube near the shock side you’re working on.
• Jack it up slightly to take tension off the shock bolts.

Step 3 (Rear): Remove the rear shock

• Use the correct-size socket set (10mm-22mm) and wrench set (10mm-22mm) to remove the lower shock bolt/nut.
• Use the socket set (10mm-22mm) and wrench set (10mm-22mm) to remove the upper shock bolt/nut.
• If it’s stuck, tap the bolt out gently with a rubber mallet. Don’t mushroom the bolt ends.

Step 4 (Rear): Install the new rear shock

• Position the new shock and start the upper and lower fasteners by hand using your wrench set (10mm-22mm).
• Use the floor jack (rated 3-ton minimum) to raise/lower the axle slightly until the bolt holes line up.
• Tighten fasteners using a torque wrench (30-250 ft-lbs): Torque to Nissan specification.

Step 5 (Front): Remove brake hose/ABS line brackets from the strut

• Use a socket set (10mm-22mm) to remove any small bolts holding the brake hose/ABS wire brackets to the strut body.
• Move lines aside carefully. Do not stretch or twist them.

Step 6 (Front): Disconnect the sway bar end link (if it blocks strut removal)

• Use the correct-size socket set (10mm-22mm) and wrench set (10mm-22mm) to remove the sway bar end link nut from the strut.
• If the stud spins, hold it with the appropriate tool from your socket set (10mm-22mm) while loosening the nut.

Step 7 (Front): Remove the strut-to-knuckle bolts

• Support the lower control arm/knuckle area with the floor jack (rated 3-ton minimum).
• Use a 1/2" drive breaker bar and socket set (10mm-22mm) to remove the strut-to-knuckle bolts/nuts.
• Use a paint marker to mark bolt orientation/position before removal (important if an adjusting bolt is present).
• If the knuckle won’t separate, use a pry bar (24") carefully to create space.

Step 8 (Front): Remove the top strut mount nuts

• Open the hood and locate the strut mount at the top of the suspension tower.
• Use a socket set (10mm-22mm) to remove the top mount nuts while holding the strut from below.
• Lower and remove the strut assembly from the wheel well.

Step 9 (Front): Install the new strut assembly

• Place the new strut assembly into position and start the top mount nuts by hand using your socket set (10mm-22mm).
• Align the strut to the knuckle and install the lower bolts/nuts using the socket set (10mm-22mm) and wrench set (10mm-22mm).
• Tighten all fasteners using a torque wrench (30-250 ft-lbs): Torque to Nissan specification.
• Reinstall brake hose/ABS brackets using the socket set (10mm-22mm): Torque to Nissan specification.
• Reconnect the sway bar end link (if removed) using the socket set (10mm-22mm) and wrench set (10mm-22mm): Torque to Nissan specification.

Step 10: Reinstall wheels and lower the truck

• Reinstall the wheel and hand-thread lug nuts.
• Lower the truck off the jack stands (rated 3-ton minimum) using the floor jack (rated 3-ton minimum).
• Tighten lug nuts in a star pattern using a torque wrench (30-250 ft-lbs): Torque to Nissan specification.

---

✅ After Repair

• 🧪 Do a bounce test: push down firmly and release—your TITAN XD should settle quickly.
• 🚗 Road test at low speed first; listen for clunks over small bumps.
• 🧰 Re-check all visible fasteners after the road test.
• 🧭 If front struts were replaced, schedule a 4-wheel alignment as soon as possible.

---

💰 DIY vs Shop Cost

Shop Cost: $600-$1,600 (parts + labor)

DIY Cost: $250-$1,000 (parts only)

You Save: $350-$600 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 4-6 hours.

---
