🔧 Explorer - Front Brake Pads & Rotor Replacement

You’ll remove the front wheels, swap the brake pads, and replace both front rotors (always do rotors in pairs). This restores braking performance and prevents vibration or pulsing caused by worn or warped rotors.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• 🧯 Work on level ground and support the Explorer with jack stands—never rely on a jack alone.
• 🔥 Brakes get extremely hot; let everything cool before touching the rotor/caliper.
• 🧤 Brake dust is irritating—use a mask and brake cleaner, not compressed air.
• 🔩 Do one side at a time so you can use the other side as a reference.
• 🔋 Battery disconnect is not required for front brake/rotor replacement.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (30-200 ft-lbs range)
• Socket set (10mm-21mm)
• Ratchet (3/8" drive)
• Torque wrench (in-lb or low Nm range)
• Flat-blade screwdriver
• C-clamp (6" minimum)
• Brake caliper hanger hook
• Wire brush
• Rubber mallet
• Safety glasses
• Nitrile gloves
• Dust mask

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake rotors - Replace in pairs - Qty: 2
• Brake parts cleaner - Qty: 1
• Brake lubricant (silicone or synthetic brake grease) - Qty: 1
• Brake fluid (DOT 4) - Qty: 1 bottle

---

📋 Before You Begin

• 🅿️ Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• 🧴 Open the hood and locate the brake fluid reservoir. Leave the cap on but be ready to check the fluid level while compressing the pistons (fluid can rise).
• 🔎 Quick check (important): look at the two caliper bracket bolts on one front wheel and confirm the bolt-head size with a socket (commonly 18mm, but verify). This prevents getting stuck mid-job.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the front lug nuts

• Use a 21mm socket and 1/2" drive breaker bar to loosen the lug nuts 1/2 turn while the tire is still on the ground.

Step 2: Lift and support the front end

• Use a floor jack (rated 3-ton minimum) to lift the front at the proper jacking point.
• Place jack stands (rated 3-ton minimum) under secure support points and lower the vehicle onto them.
• Shake the vehicle lightly to confirm it’s stable before you work.

Step 3: Remove the front wheels

• Use a 21mm socket and ratchet (3/8" drive) or breaker bar to remove the lug nuts.
• Remove both front wheels and set them aside.

Step 4: Remove the brake caliper (do not hang it by the hose)

• Turn the steering wheel to give yourself more room at the side you’re working on.
• Use the correct-size socket from your socket set (10mm-21mm) and a ratchet (3/8" drive) to remove the two caliper slide pin bolts.
• Lift the caliper off the bracket. Use a brake caliper hanger hook to hang it from the strut/spring.
• Never let the hose carry the caliper’s weight.

Step 5: Remove the old pads and caliper bracket

• Pull the pads out of the bracket by hand. If tight, use a flat-blade screwdriver gently.
• Use the verified socket size and a 1/2" drive breaker bar to remove the two caliper bracket bolts.
• Remove the caliper bracket.

Step 6: Remove the old rotor

• If your rotor has a small retaining screw, remove it with the correct bit from your socket set (10mm-21mm) (some use a small Torx/hex). If there is no screw, skip this.
• Pull the rotor straight off. If it’s stuck, tap around the rotor hat with a rubber mallet.
• Use brake parts cleaner and a wire brush to clean rust off the hub face (where the rotor sits).

Step 7: Install the new rotor

• Spray both sides of the new rotor with brake parts cleaner to remove the protective shipping oil.
• Install the rotor onto the hub. If there was a retaining screw, reinstall it and Torque to 10 Nm (89 in-lbs).

Step 8: Reinstall the caliper bracket

• Position the bracket over the new rotor.
• Install the two bracket bolts by hand first (to avoid cross-threading), then tighten with a 1/2" drive torque wrench.
• Torque to 184 Nm (136 ft-lbs).

Step 9: Compress the caliper piston

• Before compressing, check the brake fluid reservoir level under the hood.
• Place one old brake pad against the piston face, then use a C-clamp (6" minimum) to slowly push the piston fully back into the caliper.
• If the reservoir starts to overflow, remove a small amount of fluid (keep paint protected—brake fluid damages paint).
• Go slow to avoid damaging seals.

Step 10: Install the new pads and refit the caliper

• Apply a thin layer of brake lubricant (silicone or synthetic brake grease) to pad contact points where they slide in the bracket (not on pad friction material).
• Install the new pads into the bracket.
• Lower the caliper over the new pads and line up the slide pin bolt holes.
• Install the slide pin bolts and tighten with a torque wrench.
• Torque to 35 Nm (26 ft-lbs).

Step 11: Reinstall the wheels

• Put the wheel back on and hand-thread all lug nuts.
• Snug lug nuts in a star pattern using a 21mm socket and ratchet (3/8" drive).
• Lower the Explorer to the ground using the floor jack (rated 3-ton minimum).
• Final-tighten with a 1/2" drive torque wrench in a star pattern: Torque to 204 Nm (150 ft-lbs).

Step 12: Repeat on the other front wheel

• Repeat Steps 4–11 on the other side.

---

✅ After Repair

• 🦶 With the engine off, press the brake pedal slowly 10–15 times until it feels firm. This seats the pads against the rotors.
• 🧴 Recheck brake fluid level and top off with DOT 4 if needed (do not overfill).
• 🔍 Start the engine and test the brakes at very low speed first. Confirm no pulling, grinding, or warning lights.
• 🛣️ Pad break-in: do 8–10 moderate stops from 40 to 10 mph with cool-down driving between. Avoid hard panic stops for the first 200 miles.

---

💰 DIY vs Shop Cost

Shop Cost: $550-$950 (parts + labor)

DIY Cost: $180-$420 (parts only)

You Save: $370-$530 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
