🔧 Forte - Front Brake Pads & Rotor Replacement

You’ll remove the front wheels, unbolt the calipers, replace the pads and rotors, then reassemble and torque everything correctly. This restores safe stopping power and helps prevent vibration/pulsation caused by worn or warped rotors.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

Assumption: Torque specs can vary by package; verify with a service manual if available.

---

⚠️ Safety & Precautions

• 🛑 Work on level ground and support your Forte with jack stands before going under/working at the wheels.
• 🛑 Don’t press the brake pedal while a caliper is off the rotor (the piston can pop out and leak).
• 🛑 Brake dust is irritating—avoid blowing it with compressed air; use brake cleaner instead.
• 🛑 Keep brake fluid off paint; it can damage the finish.
• 🛑 No battery disconnect is required for front brakes on your Forte.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 3/8" drive ratchet
• 1/2" drive breaker bar
• Torque wrench (20-150 ft-lbs range)
• 14mm socket
• 17mm socket
• Flathead screwdriver
• C-clamp (6" or larger)
• Brake caliper hanger hook
• Wire brush
• Rubber mallet
• Micrometer or vernier caliper (specialty)
• Brake cleaner spray
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake rotors - Qty: 2
• Front brake hardware kit (clips/shims) - Qty: 1
• Brake caliper slide pin boots (if torn) - Qty: 1
• Brake grease (silicone or ceramic) - Qty: 1
• Brake fluid (DOT 3 or DOT 4) - Qty: 1 quart

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Place wheel chocks behind the rear wheels.
• Loosen the front wheel lug nuts 1/2 turn using a 21mm socket and breaker bar before lifting.
• Open the hood and locate the brake fluid reservoir; keep the cap sitting loosely on top (this helps fluid move back when compressing pistons).
• C-clamp: a screw clamp used to gently push the caliper piston back in.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front end

• Lift the front using a floor jack (rated 3-ton minimum) at the front jacking point.
• Set the vehicle onto jack stands (rated 3-ton minimum) at the pinch welds/subframe points.
• Confirm stability by gently rocking the car before removing wheels.

Step 2: Remove the front wheels

• Remove lug nuts using a 21mm socket and 3/8" drive ratchet.
• Set wheels aside.

Step 3: Inspect and prep the caliper

• Turn the steering wheel for easier access (left side: turn wheel right; right side: turn wheel left).
• Spray the caliper/bracket area with brake cleaner spray and wipe with shop towels.
• Use a flathead screwdriver to gently pry the pad ears away if they’re stuck on the rotor lip.

Step 4: Remove the caliper (keep the hose safe)

• Remove the two caliper slide bolts using a 14mm socket and 3/8" drive ratchet.
• Lift the caliper off the bracket.
• Hang the caliper using a brake caliper hanger hook so it does not dangle by the rubber brake hose.
• Never let the caliper hang by the hose.

Step 5: Remove old pads and hardware

• Slide the brake pads out by hand.
• Remove pad clips/hardware from the bracket using a flathead screwdriver.
• Clean the bracket “pad shelf” areas with a wire brush and brake cleaner spray until smooth.

Step 6: Remove the caliper bracket

• Remove the two caliper bracket bolts using a 17mm socket and breaker bar.
• Set the bracket aside.
• When reinstalling later, Torque to 88-108 Nm (65-80 ft-lbs).

Step 7: Remove the rotor

• If the rotor is stuck, tap the rotor hat (center area) with a rubber mallet to break rust loose.
• Remove the rotor from the hub.
• Clean the hub face with a wire brush and wipe with brake cleaner spray so the new rotor sits flat.
• A dirty hub can cause brake pulsation.

Step 8: Install the new rotor

• Spray both sides of the new rotor with brake cleaner spray and wipe with shop towels (removes shipping oil).
• Install rotor onto the hub.
• Hold it in place temporarily by hand (or loosely thread on one lug nut if needed, using the 21mm socket).

Step 9: Service slide pins and install new hardware

• Pull the caliper slide pins out of the bracket by hand.
• Wipe pins clean with shop towels, inspect boots for tears.
• Apply a thin, even coat of brake grease (silicone or ceramic) to the smooth part of each pin (not the threads).
• Reinstall pins and confirm they move smoothly.
• Install new pad clips/hardware into the bracket.

Step 10: Reinstall the bracket

• Position the bracket over the new rotor.
• Install bracket bolts by hand first, then tighten with a 17mm socket and ratchet.
• Torque to 88-108 Nm (65-80 ft-lbs) using a torque wrench (20-150 ft-lbs range).

Step 11: Install new pads

• Apply a thin layer of brake grease (silicone or ceramic) to pad backing plates where they contact the caliper/bracket (avoid friction material).
• Slide pads into the bracket/clip rails by hand. They should move freely.
• If pads feel tight, re-clean the bracket pad shelves using a wire brush.

Step 12: Compress the caliper piston

• Place an old brake pad against the piston face.
• Use a C-clamp (6" or larger) to slowly compress the piston until it bottoms out.
• Check the brake fluid reservoir while compressing; if it rises near the top, remove some with shop towels (do not overflow).
• Go slow to protect seals.

Step 13: Reinstall the caliper

• Set the caliper over the new pads.
• Install slide bolts and tighten using a 14mm socket and ratchet.
• Torque to 24-34 Nm (18-25 ft-lbs) using a torque wrench (20-150 ft-lbs range).

Step 14: Repeat on the other front wheel

• Repeat Steps 3 through 13 on the opposite side.
• Do one side at a time to avoid confusion.

Step 15: Reinstall wheels and torque lug nuts

• Reinstall wheels and hand-thread lug nuts.
• Lower the car until tires just touch the ground.
• Tighten lug nuts in a star pattern using a 21mm socket.
• Torque to 118-127 Nm (87-94 ft-lbs) using a torque wrench (20-150 ft-lbs range).

---

✅ After Repair

• With the engine off, pump the brake pedal 10-15 times until it feels firm (this seats the pads against the rotors).
• Check brake fluid level; top off with DOT 3 or DOT 4 if needed.
• Start the engine and confirm the pedal stays firm.
• Do a slow test drive in a safe area; confirm no pulling, grinding, or warning lights.
• Bed-in (break-in) the pads: perform 6-10 medium stops from ~40 mph down to ~10 mph, with 30-60 seconds of driving between stops to cool them. Avoid hard stops for the first 200 miles.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 (parts + labor)

DIY Cost: $120-$280 (parts only)

You Save: $230-$370 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
