🔧 Sequoia - Front Brake Pads & Rotor Replacement

You’ll remove the front wheels, unbolt the front brake calipers, replace the pads and rotors, then reassemble with the correct torque. This restores braking performance and helps prevent vibration, noise, and uneven stopping.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• 🛑 Support your Sequoia on jack stands—never rely on a floor jack alone.
• 🔥 Brakes can be extremely hot; let everything cool before touching.
• 🧤 Do not breathe brake dust; use brake cleaner and wear a dust mask.
• 🧯 Do not press the brake pedal with a caliper removed.
• 🧪 Brake fluid damages paint; wipe spills immediately.
• 🔌 Battery disconnect is not required for this front brake job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (30-200 ft-lbs range)
• 17mm socket
• 14mm socket
• Ratchet (1/2" drive)
• Ratchet (3/8" drive)
• Socket extension (3" to 6")
• C-clamp brake piston compressor
• Small flathead screwdriver
• Needle-nose pliers
• Dead blow hammer
• M8 x 1.25 bolts (2 pack)
• Wire hook or bungee cord
• Wire brush
• Brake cleaner spray
• High-temp silicone brake grease
• Mechanic gloves
• Safety glasses
• Dust mask
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake rotors - Qty: 2 Replace in pairs
• Front brake hardware kit (clips/shims) - Qty: 1
• Brake fluid (DOT 3) - Qty: 1 quart

---

📋 Before You Begin

• Park on a level surface, shift to Park, and set the parking brake.
• Place wheel chocks behind the rear tires.
• Loosen the front lug nuts 1/2 turn using a 21mm socket and breaker bar before lifting.
• Open the hood and check the brake fluid level; when you compress the pistons, the level will rise. If it’s very full, remove a little with shop towels as needed. Don’t overflow the reservoir.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front end

• Lift the front with a floor jack (rated 3-ton minimum) at the front jacking point.
• Set the frame onto jack stands (rated 3-ton minimum) and gently shake the truck to confirm it’s stable.

Step 2: Remove the front wheels

• Remove lug nuts with a 21mm socket and ratchet (1/2" drive).
• Set wheels aside. Slide them under the frame as a backup.

Step 3: Remove the caliper (do not let it hang)

• Turn the steering wheel to give yourself more room at the side you’re working on.
• Remove the caliper slide bolts using a 14mm socket and ratchet (3/8" drive).
• Lift the caliper off the pads/rotor and hang it using a wire hook or bungee cord.
• Never hang the caliper by the hose.

Step 4: Remove the caliper bracket

• Remove the caliper bracket bolts using a 17mm socket, breaker bar, and socket extension (3" to 6").
• Set the bracket on a clean surface.
• When reinstalling later: Torque to 123 Nm (91 ft-lbs).

Step 5: Remove the old rotor

• If the rotor is stuck, tap around the rotor “hat” (center area) with a dead blow hammer.
• If it’s still stuck, thread two M8 x 1.25 bolts (2 pack) into the rotor’s push-off holes evenly and tighten with a ratchet (3/8" drive) until the rotor pops loose.
• Remove the rotor.

Step 6: Clean and prep the hub surface

• Clean rust from the hub face using a wire brush.
• Spray the area with brake cleaner spray and wipe with shop towels.
• A clean hub helps prevent brake vibration.

Step 7: Install the new rotor

• Clean the new rotor with brake cleaner spray and shop towels to remove protective oil.
• Install the rotor onto the hub.
• To keep it from wobbling while you work, temporarily install 1-2 lug nuts by hand.

Step 8: Service the bracket and install new hardware

• Remove old pad clips from the bracket using a small flathead screwdriver.
• Clean the bracket pad “slides” where the clips sit using a wire brush and brake cleaner spray.
• Install the new hardware clips (from the hardware kit) by hand.
• Apply a very thin layer of high-temp silicone brake grease where the pads contact the clips. Keep grease off rotor/pad friction.

Step 9: Reinstall the caliper bracket

• Install the bracket bolts by hand first, then tighten using a 17mm socket, ratchet (1/2" drive), and torque wrench (30-200 ft-lbs range).
• Torque to 123 Nm (91 ft-lbs).

Step 10: Compress the caliper pistons

• Place an old pad against the pistons, then compress slowly using a C-clamp brake piston compressor.
• Go slowly and watch the brake fluid reservoir as the level rises.
• Slow compression helps protect seals.

Step 11: Install the new pads

• Install the new pads into the bracket by hand.
• If your pads include shims, install them exactly as provided with the pad set.
• Use needle-nose pliers if you need help positioning any pad spring clips.

Step 12: Reinstall the caliper

• Lower the caliper over the new pads/rotor.
• Install the slide bolts using a 14mm socket and torque wrench (30-200 ft-lbs range).
• Torque to 34 Nm (25 ft-lbs).

Step 13: Reinstall wheels and torque lug nuts

• Reinstall wheels and hand-thread all lug nuts.
• Lower the truck to the ground using a floor jack (rated 3-ton minimum).
• Tighten lug nuts in a star pattern using a 21mm socket and torque wrench (30-200 ft-lbs range).
• Torque to 131 Nm (97 ft-lbs).

---

✅ After Repair

• Before moving, pump the brake pedal 10-15 times until it feels firm. This seats the pads.
• Check the brake fluid level and top off with DOT 3 only if needed.
• Test drive at low speed first. Confirm no pulling, grinding, or warning lights.
• Pad bedding (recommended): make 8-10 moderate stops from ~40 mph to ~10 mph, then drive a few minutes to cool.
• Recheck lug nut torque after 25-50 miles using a torque wrench (30-200 ft-lbs range).

---

💰 DIY vs Shop Cost

Shop Cost: $650-$1,050 (parts + labor)

DIY Cost: $220-$520 (parts only)

You Save: $430-$530 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
