🔧 Accord - Front Brake Pad Replacement

You’ll be removing the front brake calipers, swapping the pads, and making sure everything is clean and moves freely so your Accord can stop safely and quietly. This guide is written for a first-time DIYer, so follow each step slowly.

Difficulty Level: Intermediate | Estimated Time: 1.5–2.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Always work on a cool brake system; hot brakes can burn skin quickly.
• ⚠️ Park your Accord on level ground, shift to P, and set the parking brake.
• ⚠️ Front brakes do not use the electric parking brake, but the rear does—do not press the brake pedal hard while a front caliper is off.
• ⚠️ Turn the car completely off (NOT in “READY” hybrid mode) and keep the key at least 3–4 meters away.
• ⚠️ Always support the car with jack stands; never rely only on a floor jack.
• ⚠️ Brake dust can be harmful; avoid blowing it with compressed air. Use brake cleaner instead.
• ⚠️ Disconnecting the 12V battery is not required for this job, but do not switch the ignition on while a caliper is removed.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🛠️ Floor jack (rated 3-ton minimum)
• 🛠️ Jack stands (rated 3-ton minimum), Qty: 2
• 🛠️ Wheel chocks
• 🛠️ Lug nut wrench or 19mm socket
• 🛠️ 3/8" drive ratchet
• 🛠️ 1/2" drive ratchet or breaker bar
• 🛠️ 14mm socket
• 🛠️ 17mm socket
• 🛠️ Torque wrench (3/8" or 1/2" drive)
• 🛠️ Flat-head screwdriver (medium size)
• 🛠️ C-clamp (6"–8") or disc brake spreader tool (specialty)
• 🛠️ Wire brush (small, handheld)
• 🛠️ Bungee cord or wire hanger
• 🛠️ Shop rags
• 🛠️ Safety glasses
• 🛠️ Mechanic gloves
• 🛠️ Catch pan or tray (for any drips)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🔩 Front brake pad set (left and right) - Qty: 1 set (replace in pairs)
• 🔩 Front brake hardware kit (anti-rattle/slide clips) - Qty: 1 set
• 🔩 High-temperature brake grease - Qty: small tube
• 🔩 Brake cleaner spray - Qty: 1–2 cans
• 🔩 Disposable nitrile gloves - Qty: 1 box
• 🔩 Shop towels or paper towels - Qty: as needed
• 🔩 Brake fluid DOT 3 or DOT 4 (Honda spec) - Qty: 1 small bottle (for topping off only)

---

📋 Before You Begin

• 🔹 Park your Accord on level ground, shift to P, set the parking brake, and switch the ignition fully off.
• 🔹 Turn off features that might move the car: no “Brake Hold” (if previously used).
• 🔹 Place wheel chocks behind the rear wheels so the car cannot roll.
• 🔹 Loosen the front wheel lug nuts slightly before lifting the car.
• 🔹 Open the hood and locate the brake fluid reservoir; remove the cap and set it loosely on top so air can escape. Stop if fluid is at max line.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen front wheel lug nuts

• Use the lug nut wrench or 19mm socket with a ratchet or breaker bar to crack each front lug nut loose about 1/4 turn while the car is still on the ground.
• Do not remove them yet; just loosen so removal is easy when the wheels are in the air.

Step 2: Lift and support the front of your Accord

• Use the floor jack on the front center jacking point (just behind the front bumper on the subframe). Check your owner’s manual picture if unsure.
• Raise the car high enough to place jack stands under the left and right front pinch welds (the reinforced seams under the doors).
• Lower the car gently onto the jack stands and give the car a small push to confirm it’s stable.
• Leave the floor jack lightly touching the subframe as backup support if possible.

Step 3: Remove the front wheels

• Use the lug nut wrench or 19mm socket and ratchet to remove the lug nuts completely.
• Remove the wheels and set them aside, lying flat so they don’t roll away.

Step 4: Inspect the brake assembly

• Look at the front brakes: you will see the rotor (big metal disc) and the caliper (clamp that squeezes the rotor) with the bracket behind it.
• Note the position of any metal clips or shims on the pads so you can match them later. Take a phone picture for reference.

Step 5: Remove the lower caliper slide bolt

• On the back of the caliper, locate the upper and lower slide bolts that hold the caliper to the bracket. On your Accord’s front brakes these are typically 14mm.
• Use a 14mm socket and 3/8" ratchet to remove the lower caliper bolt.
• The upper bolt can stay installed; you will swing the caliper up on it like a hinge.

Step 6: Swing the caliper up and support it

• Use a flat-head screwdriver between the pad and rotor to gently pry and create a small gap; this makes it easier to lift the caliper off.
• Rotate the caliper upward on the upper bolt and lift it away from the pads.
• Use a bungee cord or wire hanger to hang the caliper from the coil spring or strut. Do not let it hang by the rubber brake hose.

Step 7: Remove old brake pads and hardware

• Pull the inner and outer pads out of the bracket by hand; they may need a gentle wiggle.
• Remove the metal pad clips (hardware) from the caliper bracket. These are the thin, shiny metal pieces the pads slide in.
• Use a wire brush to clean the areas on the bracket where the clips sit. Remove rust and dirt for smooth pad movement.

Step 8: Compress the caliper piston

• Place an old brake pad against the caliper piston (the round metal piece inside the caliper).
• Use a C-clamp or disc brake spreader tool between the back of the caliper body and the old pad, and slowly tighten to push the piston fully back into the caliper.
• Watch the brake fluid reservoir under the hood; if the level approaches the “MAX” line, remove some with a clean rag or syringe into a container. Do not spill brake fluid on paint.

Step 9: Lubricate the slide pins and install new hardware

• Carefully pull the caliper slide pins (that the 14mm bolts go into) out of the rubber boots one at a time.
• Wipe them clean with a shop rag.
• Apply a thin coat of high-temperature brake grease to each pin and slide it back into its boot until fully seated.
• Install the new metal hardware clips from your kit into the caliper bracket by hand, making sure they snap in and sit flat.

Step 10: Install the new brake pads

• Check your new pads: one is usually marked as “inner” (often with a spring clip or wear sensor tab) and the other as “outer.”
• Apply a very thin layer of brake grease to the metal backing plates where they contact the clips (do not get grease on friction surfaces).
• Slide the new inner and outer pads into the bracket, making sure they sit fully in the hardware and move smoothly.

Step 11: Reinstall the caliper over the new pads

• Rotate the caliper back down over the new pads, making sure the rubber boots on the slide pins are not twisted.
• Align the lower slide pin and install the lower 14mm caliper bolt by hand first to avoid cross-threading.
• Use the 14mm socket and 3/8" ratchet to snug the bolt.
• Finally, torque the lower slide bolt to 34 Nm (25 ft-lbs) with a torque wrench. If you removed the upper bolt, torque it to the same spec.

Step 12: Repeat on the other front side

• Repeat Steps 5–11 on the other front wheel.
• Do one side at a time for reference.

Step 13: Clean the rotors and area

• Spray brake cleaner on the rotor surfaces and pad area to remove grease and dust.
• Wipe with shop towels until the rotors look clean and dry.

Step 14: Reinstall front wheels

• Place each wheel back on the hub and install lug nuts by hand, turning them several full turns to avoid cross-threading.
• Use the lug nut wrench or 19mm socket to lightly snug each lug nut in a star pattern (criss-cross) while the car is still on jack stands.

Step 15: Lower the car and torque lug nuts

• Use the floor jack to raise the car slightly and remove the jack stands.
• Lower the car fully to the ground.
• Use a torque wrench with 19mm socket to torque the wheel lug nuts in a star pattern to 127 Nm (94 ft-lbs).

Step 16: Pump the brake pedal and check fluid level

• Sit in the driver’s seat and slowly press the brake pedal 10–15 times until it becomes firm. This seats the pads against the rotors.
• Check the brake fluid level in the reservoir and top off with the correct DOT 3 or DOT 4 fluid if needed, keeping it between “MIN” and “MAX.”
• Reinstall the brake fluid reservoir cap securely.

Step 17: Final checks before driving

• Look through the wheels to make sure calipers look even and nothing is hanging or touching the inside of the wheel.
• Check around the calipers and brake lines for any obvious leaks or loose parts.

---

✅ After Repair

• 🔹 Start your Accord (make sure it goes to “READY” normally) and press the brake pedal a few times; it should feel firm and consistent.
• 🔹 Drive slowly in a safe area and test the brakes at low speed first (10–20 km/h), then slightly higher once you’re confident.
• 🔹 Listen for grinding, scraping, or loud clunks—if you hear any, stop and recheck your work.
• 🔹 Bed-in (break in) the new pads: make 5–8 gentle-to-moderate stops from about 40–50 km/h down to 10 km/h, allowing a minute of driving between stops to cool the brakes. No hard panic stops at first.
• 🔹 After driving, recheck the lug nuts once more with the torque wrench when the wheels are cool.

---

💰 DIY vs Shop Cost

Shop Cost: $250–$400 (parts + labor)

DIY Cost: $70–$150 (parts only)

You Save: $180–$250 by doing it yourself!

Shop labor rates vary but typically run $100–$150/hour. This repair takes a shop approximately 1.0–1.5 hours.

---
