🔧 Escape - Front Brake Pad Replacement

You’ll be removing the front wheels, taking off the brake calipers, swapping the pads, and reassembling everything with proper torque. This restores braking performance and prevents rotor damage.

Difficulty Level: Beginner/Intermediate | Estimated Time: 1.5–3 hours

---

⚠️ Safety & Precautions

• ⚠️ Always support the vehicle with jack stands; never work under a car held only by a jack.
• ⚠️ Wear safety glasses and mechanic gloves; brake dust and metal edges can injure you.
• ⚠️ Do not press the brake pedal with a caliper removed; you can pop the piston out.
• ⚠️ Keep brake fluid off paint; it can damage painted surfaces. Wipe spills immediately.
• ⚠️ Work on a cool vehicle; hot brakes and wheels can burn you.
• ⚠️ Chock (block) the rear wheels so the Escape cannot roll.
• ⚠️ Do not open the driver door and pump the brake pedal until both sides are fully reassembled.
• ⚠️ For this job, battery disconnection is not required.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🛠️ Floor jack (rated 3-ton minimum)
• 🛠️ Jack stands (rated 3-ton minimum, Qty: 2)
• 🛠️ Wheel chocks
• 🛠️ Lug nut wrench (19mm)
• 🛠️ 3/8" drive ratchet
• 🛠️ 1/2" drive ratchet
• 🛠️ 13mm socket
• 🛠️ 18mm socket
• 🛠️ Torque wrench 3/8" drive (5–80 ft-lbs range)
• 🛠️ Torque wrench 1/2" drive (30–150 ft-lbs range)
• 🛠️ C-clamp (4" or 6")
• 🛠️ Brake caliper piston compression tool (specialty)
• 🛠️ Flathead screwdriver (medium)
• 🛠️ Small wire brush
• 🛠️ Bungee cord or strong zip ties
• 🛠️ Shop rags or paper towels
• 🛠️ Disposable gloves
• 🛠️ Safety glasses
• 🛠️ Brake cleaner spray
• 🛠️ Plastic catch pan or tray

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🔩 Front brake pad set - Qty: 1 (replaces both front wheels, pads only)
• 🔩 Front brake hardware kit (pad clips/shims) - Qty: 1
• 🔩 Synthetic brake grease (high-temp) - Qty: 1 small tube
• 🔩 Brake cleaner (aerosol) - Qty: 1–2 cans
• 🔩 Front brake rotors - Qty: 2 (optional but recommended if worn/warped)
• 🔩 New caliper bracket bolts - Qty: 4 (recommended, one-time-use on many Fords)

---

📋 Before You Begin

• Park the Escape on a level surface, engage the parking brake, and place the transmission in Park.
• Place wheel chocks behind both rear wheels.
• Loosen (do not remove) the front wheel lug nuts a half turn with the lug wrench while the vehicle is on the ground.
• Open the hood and locate the brake fluid reservoir; make sure it is not overfilled. You may need to remove a little fluid if it’s at the very top.
• Gather all tools and parts so you are not searching while the Escape is in the air.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and Support the Front of the Escape

• Use the floor jack at the front center jacking point or one side pinch weld (check your owner’s manual diagram).
• Raise the front of the vehicle high enough so both front wheels are off the ground.
• Place jack stands under the recommended support points on both sides and gently lower the Escape onto them.
• Give the car a firm shake to confirm stability.

Step 2: Remove the Front Wheels

• Use the lug nut wrench (19mm) to remove the front wheel lug nuts completely.
• Remove both front wheels and set them aside.
• Lay lug nuts in a small tray so you don’t lose them.

Step 3: Inspect the Front Brakes

• Look at the brake caliper (the part that clamps the rotor) and the rotor (the large disc).
• Check rotor surface; if it is deeply grooved, cracked, or badly rusted, plan to replace the rotors as well.
• Replacing rotors with pads gives best braking feel.

Step 4: Remove Caliper Guide Pin Bolts

• Turn the steering wheel slightly to give easier access to the caliper bolts on the side you’re working on.
• On the back of the caliper, locate the two smaller bolts (guide pin bolts).
• Use a 3/8" ratchet with a 13mm socket to loosen and remove the upper and lower caliper bolts.
• Set these bolts aside; keep them clean.

Step 5: Remove and Support the Caliper

• Use a flathead screwdriver between the pad and rotor to gently pry the caliper outward a bit; this helps relieve pressure.
• Lift the caliper off the pads and rotor.
• Use a bungee cord to hang the caliper from the suspension spring or a solid point. Do not let it dangle by the brake hose.
• Never twist or stretch the rubber brake hose.

Step 6: Remove Old Brake Pads and Hardware

• Slide the old inner and outer pads out of the caliper bracket.
• Remove the metal pad clips (hardware) from the caliper bracket using your fingers or a flathead screwdriver.
• Use a small wire brush to clean the pad contact areas of the bracket where the clips sit.
• Spray brake cleaner on the area and catch runoff with the plastic tray.

Step 7: (Optional) Remove Caliper Bracket and Rotor

• If you are replacing rotors, remove the caliper bracket.
• Use a 1/2" ratchet with an 18mm socket to remove the two large caliper bracket bolts behind the rotor.
• Lift the caliper bracket off and set it aside.
• Slide the rotor off the hub. If it is stuck, tap around the hat (center area) with the palm of your hand or a rubber mallet.
• Clean the hub face with a wire brush and a little brake cleaner.
• Install the new rotor onto the hub.
• Reinstall the caliper bracket with new bolts if you have them.
• Use a 1/2" torque wrench and an 18mm socket to tighten the caliper bracket bolts to 115 Nm (85 ft-lbs).

Step 8: Install New Pad Hardware

• Press the new pad clips (hardware) into the cleaned caliper bracket by hand until they snap fully into place.
• Make sure each clip sits flat and is not twisted.
• Misaligned clips can cause squeaks and uneven wear.

Step 9: Compress the Caliper Piston

• The piston is the round piece inside the caliper that pushes the pad.
• Place an old pad against the piston face.
• Use a C-clamp or caliper piston compression tool between the back of the caliper and the old pad to slowly push the piston back into the caliper housing.
• Go slowly and steadily until the piston is fully seated flush with the caliper body.
• Check the brake fluid reservoir under the hood; if the level is now above MAX, remove a little using a clean syringe or turkey baster and a rag.
• Slow compression protects seals inside the caliper.

Step 10: Install New Brake Pads

• Apply a very thin layer of synthetic brake grease to the metal ears of the pads where they contact the hardware clips. Do not get grease on the pad friction surface or rotor.
• Install the new inner and outer pads into the caliper bracket. They should slide in smoothly and move slightly by hand.
• If the pads feel extremely tight, remove them and lightly clean the contact surfaces again.

Step 11: Reinstall the Caliper Over New Pads

• Remove the bungee cord and carefully lower the caliper over the new pads and rotor.
• Line up the caliper holes with the guide pin threads on the bracket.
• Install the upper and lower caliper guide pin bolts by hand first to avoid cross-threading.
• Use a 3/8" ratchet with a 13mm socket to snug them down.
• Then use a 3/8" torque wrench with the 13mm socket to tighten the guide pin bolts to 34 Nm (25 ft-lbs).

Step 12: Repeat on the Other Front Side

• Repeat Steps 4–11 on the other front wheel.
• Always replace front pads as a pair.

Step 13: Reinstall Wheels

• Place each wheel back onto its hub and hand-thread the lug nuts.
• Use the lug nut wrench (19mm) to snug the lug nuts in a star pattern.
• Raise the Escape slightly with the floor jack to remove the jack stands, then lower the vehicle to the ground.

Step 14: Torque the Lug Nuts

• Use a 1/2" torque wrench with the 19mm socket to tighten the lug nuts in a star pattern.
• Torque each lug nut to 135 Nm (100 ft-lbs).

Step 15: Pump the Brake Pedal and Final Checks

• With the Escape on the ground and engine off, slowly press the brake pedal 5–8 times until it feels firm. This seats the pads against the rotors.
• Check the brake fluid reservoir again and make sure the level is between MIN and MAX.
• Look around each front wheel area for any leaks or loose parts.

---

✅ After Repair

• Start the engine and press the brake pedal; it should feel firm and consistent.
• Drive slowly in a safe area and make gentle stops from 10–20 mph to verify normal braking and no noises.
• For the first 200–300 km, avoid very hard stops if possible so the pads can bed-in smoothly.
• If you hear grinding, feel pulsing, or the pedal feels spongy, stop and recheck your work.

---

💰 DIY vs Shop Cost

Shop Cost: $280–$450 (parts + labor)

DIY Cost: $80–$170 (pads, hardware, cleaner, grease)

You Save: $200–$300 by doing it yourself!

Shop labor rates vary but typically run $100–$150/hour. This repair takes a shop approximately 1.0–1.5 hours.

---
