🔧 Escape - Front Brake Pad Replacement

Replacing the front pads on your Escape involves safely lifting the front end, removing the front wheels, opening the brake caliper, swapping pads, then reassembling and bedding-in the pads. I can walk you through it step-by-step, but I need one quick detail to give you the exact Ford torque specs for your specific front brake hardware.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• 🧯 Support the Escape on jack stands; never rely on a jack.
• 🔥 Brakes can be hot; let them cool before touching parts.
• 🧤 Do not inhale brake dust; use brake cleaner, not compressed air.
• ⚠️ Do not press the brake pedal with a caliper removed (the piston can pop out).
• 🔋 Battery disconnect is not required for front pad replacement.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Lug nut socket (19mm)
• Breaker bar (1/2")
• Torque wrench (20–200 ft-lbs range)
• Socket set (8–21mm)
• Ratchet (3/8")
• Wrench set (8–21mm)
• C-clamp (6")
• Brake caliper piston compressor (specialty)
• Flat trim tool
• Wire hook or bungee cord
• Brake parts cleaner
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Brake hardware/abutment clip kit - Qty: 1
• Brake caliper slide pin grease (silicone) - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• Park on level ground, transmission in Park, and set the parking brake.
• Chock the rear wheels with wheel chocks.
• Loosen front lug nuts slightly before lifting (do not remove yet).
• Please answer these so I can provide the exact Ford torque specs and the correct caliper bolt sizes:
  • Are you replacing pads only, or pads + rotors?
  • Can you upload a clear photo of the front caliper/bracket with the wheel off (straight-on shot)?

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the front lug nuts

• Use a 19mm lug nut socket with a breaker bar (1/2") to loosen each front lug nut about 1/2 turn.
• Do not fully remove the lug nuts yet.

Step 2: Lift and support the front

• Use a floor jack (rated 3-ton minimum) to lift the front at the proper front jacking point.
• Set the Escape onto jack stands (rated 3-ton minimum) and gently shake the vehicle to confirm it’s stable.

Step 3: Remove the front wheels

• Remove the loosened lug nuts using the 19mm lug nut socket and take both front wheels off.
• When reinstalling later: Torque to 135 Nm (100 ft-lbs) in a star pattern.

Step 4: Inspect the brake setup before disassembly

• Turn the steering wheel to give yourself working room (left for right side, right for left side).
• Use safety glasses and look at the caliper:
  • Find the caliper slide-pin bolts (usually the smaller bolts at the back of the caliper).
  • Find the caliper bracket bolts (larger bolts holding the bracket to the knuckle).
• Take a photo now; it helps reassembly.

Step 5: Pause here for the correct torque specs

• Once you answer “pads only vs pads + rotors” and upload the caliper/bracket photo, I’ll give you the exact next steps with the correct bolt sizes and Ford torque specs for:
  • Caliper slide-pin bolts
  • Caliper bracket-to-knuckle bolts
  • Any pad wear sensor routing (if equipped)
• This avoids overtightening/undertightening critical brake fasteners.

---

✅ After Repair

• Before moving: pump the brake pedal until it feels firm.
• Confirm brake fluid level is between MIN and MAX.
• Test at low speed first, then perform pad bed-in (I’ll provide the exact procedure once we confirm pad type).
• Listen for scraping/grinding and recheck for any leaks or loose hardware.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $50-$150 (parts only)

You Save: $100-$350 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
