🔧 Rogue - Front Brake Pad Replacement

You’ll be replacing the front brake pads on your Rogue to restore safe braking and stop any grinding or squealing. This involves removing the front wheels, the brake calipers, and swapping in new pads and hardware.

Difficulty Level: Beginner/Intermediate | Estimated Time: 2–3 hours

---

⚠️ Safety & Precautions

• 🛑 Always support the vehicle with jack stands; never work under a car held only by a jack.
• 🛑 Wear safety glasses and mechanic gloves; brake dust and rust can irritate eyes and skin.
• 🛑 Keep the car in Park with the parking brake set and wheels chocked before lifting.
• 🛑 Do not let the brake caliper hang by the rubber brake hose; support it with a hook or wire.
• 🛑 Use only brake cleaner on brake parts; never use oil-based cleaners.
• 🛑 Engine does not need to be running and battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🧰 Floor jack (rated 3-ton minimum)
• 🧰 Jack stands (rated 3-ton minimum)
• 🧰 Wheel chocks
• 🧰 21mm lug nut socket
• 🧰 1/2" drive breaker bar
• 🧰 1/2" drive torque wrench (10–150 ft-lbs range)
• 🧰 14mm socket
• 🧰 17mm socket
• 🧰 3/8" drive ratchet
• 🧰 3/8" drive extension (3"–6")
• 🧰 C-clamp (6" or larger) or disc brake caliper compressor tool
• 🧰 Flathead screwdriver (medium)
• 🧰 Wire brush (small, steel bristles)
• 🧰 Bungee cord or wire hanger
• 🧰 Shop rags
• 🧰 Safety glasses
• 🧰 Mechanic gloves
• 🧰 Disposable dust mask

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🔩 Front brake pad set (left and right) - Qty: 1 set
• 🔩 Front brake pad hardware kit (abuttment clips / shims) - Qty: 1 set
• 🔩 Brake grease / silicone-based brake lubricant - Qty: 1 small tube
• 🔩 Brake cleaner spray - Qty: 1–2 cans
• 🔩 Anti-seize compound - Qty: 1 small tube
• 🔩 Shop towels - Qty: as needed

---

📋 Before You Begin

• 🚗 Park the Rogue on level ground, shift to Park, and set the parking brake.
• 🧱 Place wheel chocks behind the rear wheels so the car cannot roll.
• 🔧 Loosen the front wheel lug nuts 1/2 turn with the 21mm socket before lifting the vehicle.
• 🆙 Lift the front at the front crossmember with the floor jack and support both sides with jack stands under the front pinch welds.
• 🔍 Turn the steering wheel left/right (engine off) as needed to give more access to each side while you work.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the front wheels

• Use the floor jack to raise the front of the Rogue and place it securely on jack stands.
• Use the 21mm lug nut socket and breaker bar to remove the front wheel lug nuts completely.
• Remove both front wheels and set them aside.

Step 2: Inspect the brake assembly

• Look at the caliper (the metal “clamp” over the rotor), the pads (between caliper and rotor), and the rotor (the large disc).
• Check for any wetness around the caliper that might indicate a brake fluid leak.
• Do not continue if you see fluid leaks.

Step 3: Loosen caliper slide pin bolts

• On the back of the caliper, locate the two smaller bolts (top and bottom). These are the slide pin bolts.
• Use a 14mm socket and 3/8" ratchet to loosen and remove both slide pin bolts.
• Set the bolts aside somewhere clean; you’ll reuse them.

Step 4: Remove and support the caliper

• Use a flathead screwdriver between the old pad and rotor to gently pry the caliper outward slightly; this takes a little tension off the pads.
• Lift the caliper off the bracket and rotor and support it using a bungee cord or wire hanger from the suspension spring.
• Never let the caliper dangle by the rubber hose.

Step 5: Remove old pads and hardware

• Slide the old brake pads out of the bracket by hand; note which side the pad with the wear indicator (small metal tab) is on.
• Remove the metal clips (hardware) from the caliper bracket using your flathead screwdriver.
• Use a wire brush to clean the areas of the bracket where the clips sit until bare metal shows.
• Cleaning helps new pads move freely.

Step 6: Compress the caliper piston

• Check the brake fluid reservoir under the hood. If it is very full, remove a bit of fluid with a clean rag or turkey baster so it doesn’t overflow when you push the piston back.
• Place one old pad against the piston in the caliper.
• Use a C-clamp or brake caliper compressor tool to slowly push the piston fully back into the caliper body.
• Go slowly and stop if you feel unusual resistance.

Step 7: Install new hardware clips

• Match the new hardware clips to the old ones so they are oriented correctly.
• Press the new clips into the caliper bracket by hand until they snap fully into place.
• Lightly brush a thin layer of brake grease on the areas of the clips where the pad “ears” will slide. Do not get grease on the rotor or friction surfaces.

Step 8: Install new brake pads

• Apply a very thin layer of brake grease to the metal backing plate tabs of each pad (the ears), and on the back where they contact the caliper or shim, but not on the friction surface.
• Install the inner pad and outer pad into the bracket, making sure they sit fully in the hardware clips.
• If your new pads have a wear indicator tab, make sure it is installed in the same position as the old one (usually on the inner pad at the top).

Step 9: Reinstall the caliper

• Lower the caliper carefully over the new pads and onto the bracket.
• Align the caliper slide pin holes with the threaded holes in the bracket.
• Install the two 14mm slide pin bolts by hand first to avoid cross-threading.
• Use the 14mm socket and 3/8" ratchet to snug them.
• Then use your torque wrench with the 14mm socket to tighten the slide pin bolts to 34 Nm (25 ft-lbs).

Step 10: Repeat on the other side

• Repeat Steps 3 through 9 on the other front wheel.
• Always replace brake pads in pairs.

Step 11: Reinstall wheels

• Place each wheel back onto the hub and hand-thread all lug nuts.
• Use the 21mm socket and ratchet to snug the lug nuts in a crisscross pattern while the car is still on jack stands.
• Use the floor jack to carefully lift the vehicle slightly, remove the jack stands, then lower the vehicle fully to the ground.
• Use the 21mm socket and torque wrench to tighten the lug nuts in a star pattern to 108 Nm (80 ft-lbs).

Step 12: Clean up and check fluid

• Spray the rotor and caliper area lightly with brake cleaner to remove grease or fingerprints. Wipe with shop rags.
• Check the brake fluid reservoir. Adjust the fluid level to between MIN and MAX if needed.

Step 13: Seat the brake pads

• Before driving, sit in the driver’s seat with the engine running.
• Firmly press the brake pedal slowly 5–10 times until it feels solid. This moves the pads into their working position.
• Do not skip pumping the pedal.

---

✅ After Repair

• 🧪 Test brakes at low speed in an empty area. Start with gentle stops from 10–20 km/h, then 30–40 km/h.
• 👂 Listen for grinding, clunks, or pulling to one side. If anything feels wrong, re-check your work.
• 🛞 For the first 300–500 km, avoid hard emergency-style stops unless needed. Use moderate braking to “bed in” the pads.
• 🔍 After a few drives, recheck the lug nut torque with the torque wrench set to 108 Nm (80 ft-lbs).

---

💰 DIY vs Shop Cost

Shop Cost: $300–$450 (parts + labor) for front pads only on a Rogue.

DIY Cost: $70–$150 (parts and supplies)

You Save: About $150–$300 by doing it yourself!

Shop labor rates vary but typically run $100–$150/hour. This repair takes a shop approximately 1.0–1.5 hours.

---
