🔧 TITAN - Front Brake Pad Replacement

You’ll remove the front wheels, swing the front brake calipers out of the way, replace the pads and hardware, then reassemble and confirm proper pedal feel. This restores braking performance and prevents rotor damage when pads wear low.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and support your TITAN with jack stands before going under or removing wheels.
• ⚠️ Do not breathe brake dust; use brake cleaner and let parts dry.
• ⚠️ Don’t press the brake pedal with the caliper removed (it can push the piston out).
• ⚠️ Watch the brake fluid level; pushing pistons back can overflow the reservoir.
• ⚠️ If you disconnect the battery: keep radio settings in mind (not required for this job).

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (20-200 ft-lbs range)
• Metric socket set (10mm-24mm)
• Metric wrench set (10mm-24mm)
• Flat-blade screwdriver
• C-clamp brake piston compressor
• Wire brush
• Bungee cord
• Brake parts cleaner
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware kit (abutment clips) - Qty: 1
• Brake caliper grease (silicone-based) - Qty: 1
• Brake cleaner - Qty: 1
• DOT 3 brake fluid - Qty: 1 quart

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Chock the rear wheels with wheel chocks.
• Open the hood and locate the brake fluid reservoir; make sure it isn’t filled to the brim.
• Loosen the front lug nuts about 1/2 turn using a 21mm socket and breaker bar before lifting.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front end

• Lift the front using a floor jack (rated 3-ton minimum) at the front jacking point.
• Set the frame on jack stands (rated 3-ton minimum) and gently lower the truck onto them.
• Give the truck a small shake to confirm it’s stable.

Step 2: Remove the front wheels

• Remove lug nuts using a 21mm socket and take both front wheels off.
• Set wheels under the frame as an extra safety backup.

Step 3: Access the caliper and pads

• Turn the steering so the caliper you’re working on faces outward (more room).
• If the caliper has an outer spring/retainer, carefully pry it off using a flat-blade screwdriver.
• Locate the two caliper slide-pin bolts (back side of caliper).

Step 4: Remove the caliper (do not hang it by the hose)

• Remove the slide-pin bolts using the correct size from your metric socket set (10mm-24mm) or metric wrench set (10mm-24mm).
• Lift the caliper off the bracket and support it with a bungee cord so the brake hose is not stretched.
• Tip: Hook the bungee to the coil spring.

Step 5: Remove old pads and hardware

• Slide the old pads out of the bracket by hand.
• Remove the stainless pad clips (abutment clips) using a flat-blade screwdriver.
• Clean the bracket pad “rails” using a wire brush and spray with brake parts cleaner.

Step 6: Compress the caliper piston

• Place an old pad against the piston face, then use a C-clamp brake piston compressor to slowly push the piston back into the caliper.
• Check the brake fluid reservoir while compressing; remove a little fluid if it begins to overflow.
• Tip: Compress slowly to protect seals.

Step 7: Install new hardware and pads

• Install new abutment clips from the front brake pad hardware kit (abutment clips) into the bracket.
• Apply a thin film of brake caliper grease (silicone-based) to the pad ears where they contact the clips (not on pad friction material).
• Install the new pads into the bracket (inner/outer as supplied with your set).

Step 8: Reinstall the caliper and torque fasteners

• Lower the caliper over the new pads.
• Install the slide-pin bolts using the correct size from your metric socket set (10mm-24mm).
• Torque to 31 Nm (23 ft-lbs) for the front caliper slide-pin bolts.
• If you removed the outer spring/retainer, reinstall it using a flat-blade screwdriver.

Step 9: Repeat on the other front side

• Repeat Steps 3–8 on the other front wheel.
• Replace pads on both front sides as a pair.

Step 10: Reinstall wheels and torque lug nuts

• Reinstall wheels and hand-thread lug nuts.
• Lower the truck off the jack stands using the floor jack (rated 3-ton minimum).
• Tighten lug nuts in a star pattern using a 1/2" drive torque wrench (20-200 ft-lbs range).
• Torque to 133 Nm (98 ft-lbs) for the lug nuts.

---

✅ After Repair

• With the engine OFF, pump the brake pedal 10–15 times until it feels firm.
• Check brake fluid level and top off with DOT 3 brake fluid if needed.
• Start the engine and confirm the pedal stays firm.
• Road test at low speed first; confirm no pulling, grinding, or warning lights.
• Pad break-in (bedding): make 6–10 moderate stops from 40 mph to 10 mph, letting brakes cool slightly between stops.

---

💰 DIY vs Shop Cost

Shop Cost: $300-$550 (parts + labor)

DIY Cost: $90-$220 (parts only)

You Save: $210-$330 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.0 hours.

---
