🔧 Sonata - Front Brake Pad Replacement

On your Sonata, the front pads sit in the front brake calipers and clamp the rotor to slow the car down. Replacing them means safely lifting the front end, removing the caliper, swapping pads and hardware, then compressing the caliper piston so everything fits back together.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Hybrid safety: Make sure the car is fully OFF (not in READY) before starting, and keep the key/fob at least 10 ft away.
• ⚠️ Support the car on jack stands before working underneath or removing wheels.
• ⚠️ Do not press the brake pedal with a caliper removed.
• ⚠️ Brake dust is unhealthy—use brake cleaner, not compressed air.
• ⚠️ Watch brake fluid level while compressing pistons; it can overflow.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 3/8" drive ratchet
• 1/2" drive breaker bar
• Torque wrench (20–200 ft-lbs range)
• 14mm socket
• 17mm socket
• Flathead screwdriver
• C-clamp (6" or larger)
• Bungee cord
• Wire brush
• Brake cleaner spray
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake hardware kit (abutment clips) - Qty: 1
• Brake caliper grease (silicone-based) - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Confirm the vehicle is OFF (not READY) and keep the key/fob away.
• Chock the rear wheels with wheel chocks.
• Loosen the front wheel lug nuts slightly before lifting.
• Open the hood and locate the brake fluid reservoir; you’ll watch the level during piston compression.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift the front and remove the wheels

• Use wheel chocks behind the rear tires.
• Use a 21mm socket and breaker bar to loosen lug nuts 1/2 turn.
• Lift the front with the floor jack at the front center jack point, then support with jack stands on both sides.
• Remove lug nuts using the 21mm socket and ratchet, then remove both front wheels.
• During reassembly: Torque lug nuts to 107–127 Nm (79–94 ft-lbs) using a torque wrench.

Step 2: Remove the caliper (do not let it hang)

• Turn the steering wheel to give yourself more room (left for right side, right for left side).
• Use a 14mm socket and ratchet to remove the 2 caliper slide pin bolts.
• Carefully lift the caliper off the bracket.
• Hang the caliper from the strut spring using a bungee cord. Don’t stretch the brake hose.
• During reassembly: Torque caliper slide pin bolts to 28–34 Nm (21–25 ft-lbs) using a torque wrench.

Step 3: Remove old pads and hardware

• Slide the old inner and outer pads out by hand; if stuck, gently pry with a flathead screwdriver.
• Remove the stainless abutment clips (hardware) from the bracket.
• Use brake cleaner spray to clean the bracket pad-contact areas.
• Use a wire brush to remove rust where the clips sit, then spray again with brake cleaner spray.

Step 4: Compress the caliper piston

• Check the brake fluid reservoir level under the hood; be ready to remove a little fluid if it rises too high.
• Use a C-clamp (6" or larger) to slowly push the piston back into the caliper until it’s fully seated.
• If it fights you hard or won’t go in smoothly, stop—there may be a seized caliper or swollen hose.

Step 5: Install new hardware and pads

• Install new abutment clips from the front brake hardware kit (abutment clips) onto the bracket.
• Apply a thin film of brake caliper grease (silicone-based) on the clip “rails” where the pad ears slide. Keep grease off pad friction material.
• Install the new pads into the bracket (inner pad goes on the piston side).

Step 6: Reinstall the caliper and (if removed) the bracket

• Lower the caliper over the new pads by hand.
• Install the caliper slide pin bolts using a 14mm socket and ratchet, then finish with a torque wrench.
• Torque caliper slide pin bolts to 28–34 Nm (21–25 ft-lbs).
• If you removed the caliper bracket at any point, reinstall it with a 17mm socket and breaker bar, then torque bracket bolts to 78–98 Nm (58–72 ft-lbs) using a torque wrench.

Step 7: Reinstall wheels

• Reinstall the wheels and hand-thread all lug nuts.
• Lower the car off the jack stands using the floor jack.
• Use a torque wrench to tighten lug nuts in a star pattern: Torque to 107–127 Nm (79–94 ft-lbs).

---

✅ After Repair

• With the car still OFF, pump the brake pedal slowly 10–15 times until it feels firm.
• Check brake fluid level and top off only if needed (use the correct fluid listed on the reservoir cap).
• Start the car and confirm there are no warning lights related to brakes.
• Do a low-speed test in a safe area: gentle stops first, then moderate stops.
• Pad bedding (break-in): make 6–10 smooth stops from ~30 mph to ~5 mph, letting brakes cool a bit between stops.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $50-$150 (parts only)

You Save: $200-$300 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
