🔧 Front Brake Pads - Replacement

Your Camry uses front disc brakes with a floating caliper, so this job is mainly removing the caliper, swapping the pads, and making sure the caliper moves freely before reassembly. Do both front sides together so braking stays even.

Difficulty Level: Beginner | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• Work on a flat surface and chock the rear wheels.
• Do not press the brake pedal with a caliper removed.
• The brakes and rotors can be hot after driving.
• Support the vehicle with jack stands; never rely on a jack alone.
• Use brake cleaner only in a well-ventilated area.
• Your Camry has an electronic parking brake system on some trims, but front pad replacement does not require EPB service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (pair)
• Wheel chocks
• 21mm lug wrench or 21mm socket
• 14mm socket
• Ratchet
• Breaker bar
• Bungee cord or caliper hanger
• C-clamp
• Flathead screwdriver
• Torque wrench
• Brake cleaner
• Wire brush
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Brake hardware kit - Qty: 1
• Brake caliper grease - Qty: 1
• Brake cleaner - Qty: 1 can

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Loosen the front lug nuts before lifting the vehicle.
• Raise the front and support it securely on jack stands.
• Open the brake fluid reservoir and check the level before compressing the caliper piston. If it is already near the top, remove a small amount if needed.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the wheel

• Use a 21mm lug wrench or 21mm socket to loosen and remove the front wheel lug nuts.
• Set the wheel aside safely.

Step 2: Remove the caliper

• Use a 14mm socket and ratchet to remove the caliper slide bolts.
• Lift the caliper off the bracket.
• Hang the caliper with a bungee cord or caliper hanger; do not let it dangle by the hose.

Step 3: Remove the old pads and hardware

• Pull the old brake pads out of the bracket.
• Remove the pad clips and any wear indicators.
• Use a wire brush and brake cleaner to clean the pad contact points.

Step 4: Retract the caliper piston

• Use a C-clamp to slowly push the caliper piston back into the bore.
• Compress it evenly and stop if it binds.
• Go slow to avoid seal damage.

Step 5: Install new hardware and pads

• Install the new pad clips from the brake hardware kit.
• Apply a thin layer of brake caliper grease to the pad ears and contact points only.
• Install the new brake pads into the bracket.

Step 6: Reinstall the caliper

• Slide the caliper over the new pads.
• Use the 14mm socket and torque wrench to tighten the caliper slide bolts to 34 Nm (25 ft-lbs).

Step 7: Reinstall the wheel

• Install the wheel and hand-tighten the lug nuts.
• Lower the vehicle.
• Use a torque wrench with a 21mm socket to tighten the lug nuts to 103 Nm (76 ft-lbs) in a star pattern.

Step 8: Repeat on the other side

• Replace the front pads on both sides.

---

✅ After Repair

• Press the brake pedal several times before driving to seat the pads against the rotors.
• Check the brake fluid level again and top off only if needed.
• Test the brakes at low speed first.
• Listen for rubbing or clicking sounds.
• New brake pads need a short break-in period. Use gentle stops for the first 200 miles.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $70-$180 (parts only)

You Save: $180-$270 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
