🔧 Trax - Front Brake Pad Replacement

Replacing the front brake pads on your Trax means removing the front wheels, lifting the front brake caliper off the rotor, swapping the pads, and compressing the caliper piston so everything fits back together. Doing it carefully prevents brake noise, uneven wear, and braking vibration.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Support the vehicle with jack stands; never rely on a jack alone.
• ⚠️ Do not press the brake pedal while a caliper is removed.
• ⚠️ Brake dust is harmful—wear a mask and avoid blowing dust with compressed air.
• ⚠️ Use only brake cleaner on brake parts; keep grease off pad/rotor friction surfaces.
• ⚠️ Watch brake fluid level—compressing pistons can overflow the reservoir.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Torque wrench (10-200 ft-lbs range)
• Breaker bar (1/2" drive)
• 19mm socket
• 14mm socket
• 18mm socket
• 1/2" drive ratchet
• 3/8" drive ratchet
• Flathead screwdriver
• Bungee cord
• C-clamp or disc brake piston compressor (specialty)
• Wire brush
• Brake parts cleaner spray
• Nitrile gloves
• Safety glasses
• Dust mask

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake hardware kit (abutment clips) - Qty: 1
• Brake caliper slide pin grease (silicone) - Qty: 1
• Brake lubricant (anti-squeal) - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Loosen the front wheel lug nuts about 1/2 turn using a 19mm socket and breaker bar before lifting.
• Open the hood and locate the brake fluid reservoir; make sure it is not overfilled.
• Know your tool: a C-clamp or brake piston compressor pushes the caliper piston back into the caliper so the new, thicker pads fit.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front end

• Use a floor jack to lift the front of your Trax at the approved front jack point.
• Place jack stands under solid frame/support points and lower the vehicle onto them.
• Remove the front wheels using a 19mm socket and ratchet.

Step 2: Access the caliper and pads

• Turn the steering so the caliper you’re working on faces outward for more room.
• Use a flathead screwdriver to gently pry the caliper outward slightly at the outer pad edge to create a little clearance.

Step 3: Remove the caliper guide pin bolts

• Use a 14mm socket and ratchet to remove the two caliper guide pin bolts (upper and lower).
• Lift the caliper off the bracket and rotor.
• Hang the caliper from the strut spring using a bungee cord. Never let it hang by the hose.

Step 4: Remove the old pads and hardware

• Pull the inner and outer pads out of the bracket by hand.
• Remove the pad abutment clips from the bracket (new ones typically come in the hardware kit).

Step 5: Clean and prep the bracket

• Spray the bracket pad-contact areas with brake parts cleaner spray.
• Use a wire brush to clean rust where the abutment clips sit.
• Install the new abutment clips from the hardware kit.

Step 6: Service the slide pins

• Pull the slide pins out of the bracket by hand (one at a time).
• Wipe them clean and apply a thin coat of brake caliper slide pin grease (silicone).
• Reinstall the slide pins and make sure they move smoothly.

Step 7: Compress the caliper piston

• Check the brake fluid reservoir level before compressing.
• Use a C-clamp or disc brake piston compressor (specialty) to slowly push the piston fully back into the caliper.
• If fluid rises near the top of the reservoir, stop and remove a small amount (do not spill on paint).

Step 8: Install the new pads

• Apply a thin layer of brake lubricant (anti-squeal) to the pad backing plates where they contact the caliper/bracket (not on the pad friction material).
• Install the new inner and outer pads into the bracket.

Step 9: Reinstall the caliper and torque fasteners

• Set the caliper over the new pads.
• Install the caliper guide pin bolts using a 14mm socket and ratchet.
• Torque to 30 Nm (22 ft-lbs) using a torque wrench.

Step 10: Reinstall wheels and torque lug nuts

• Reinstall the wheels and hand-start all lug nuts.
• Lower the vehicle off the jack stands using the floor jack.
• Tighten lug nuts in a star pattern using a torque wrench and 19mm socket.
• Torque to 140 Nm (103 ft-lbs).

---

✅ After Repair

• With the engine off, slowly pump the brake pedal 10-15 times until it feels firm.
• Check the brake fluid reservoir level and top off only if needed with the correct brake fluid listed on the reservoir cap.
• Start the vehicle and hold firm brake pressure for 10 seconds to confirm a solid pedal.
• Do a cautious test drive and confirm no pulling, grinding, or warning lights.
• Pad bed-in: Make 8-10 moderate stops from 30 mph to 5 mph, allowing short cool-down between stops. Avoid hard stops for 200 miles.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $60-$150 (parts only)

You Save: $190-$300 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
