🔧 Expedition - Front Brake Pad Replacement

You’ll be removing the front calipers, swapping the old pads for new ones, and then reinstalling everything with the correct torque. New pads restore stopping power and prevent rotor damage from worn-out friction material.

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours

---

⚠️ Safety & Precautions

• 🛑 Support your Expedition on jack stands; never rely on a jack alone.
• 🧤 Avoid breathing brake dust; use brake cleaner and wear gloves and safety glasses.
• 🔥 Brakes can be extremely hot; let them cool before starting.
• 🚫 Do not press the brake pedal with the caliper removed.
• 🔒 Keep the steering straight and the key off while working.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (30-250 ft-lbs range)
• 13mm socket
• 18mm socket
• Ratchet (3/8" drive)
• 3/8" drive torque wrench (10-100 ft-lbs range)
• Flat-blade screwdriver
• C-clamp (6" minimum) or disc brake piston tool (specialty)
• Bungee cord
• Wire brush
• Brake parts cleaner spray
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware kit (clips/abutments) - Qty: 1
• Silicone brake lubricant - Qty: 1
• Brake cleaner - Qty: 1
• Brake fluid (DOT 4 LV) - Qty: 1 (as needed)

---

📋 Before You Begin

• Park on level ground, shift to Park, and chock the rear wheels.
• Loosen the front lug nuts slightly using a 21mm socket and breaker bar before lifting.
• Open the hood and check the brake fluid level. If it’s near “MAX,” be ready for the level to rise when you push the caliper pistons back in.
• C-clamp squeezes the piston back slowly.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift the front and remove the wheels

• Lift the front using a floor jack (rated 3-ton minimum) at the correct front jacking point, then set the frame on jack stands (rated 3-ton minimum).
• Remove the lug nuts with a 21mm socket and take off both front wheels.

Step 2: Locate the caliper and check pad/rotor condition

• Turn the steering for easier access (left for right side work, right for left side work).
• Look at the rotor surface for deep grooves or heavy rust. If the rotor is badly worn, plan to replace it too.

Step 3: Remove the caliper guide pin bolts

• Remove the two caliper guide pin bolts using a 13mm socket and ratchet.
• Lift the caliper off the bracket.
• Hang the caliper from the suspension with a bungee cord so the brake hose is not stretched.

Step 4: Remove the old pads and hardware

• Pull the old pads out of the bracket by hand. If stuck, gently pry with a flat-blade screwdriver.
• Remove the pad abutment clips (hardware) from the bracket.
• Clean the bracket pad lands with a wire brush and brake parts cleaner spray.

Step 5: Compress the caliper piston

• Place an old pad against the piston face (to spread force evenly).
• Slowly compress the piston using a C-clamp (6" minimum) or disc brake piston tool (specialty) until it bottoms smoothly.
• Check the brake fluid reservoir level again and wipe up any overflow immediately with shop towels.
• Go slow to avoid damaging the seal.

Step 6: Install new hardware and new pads

• Install the new abutment clips from the front brake pad hardware kit into the bracket.
• Apply a thin film of silicone brake lubricant to the pad ears where they contact the clips (do not get lube on friction material).
• Install the new inner and outer pads into the bracket.

Step 7: Reinstall the caliper and torque fasteners

• Slide the caliper over the new pads.
• Install the caliper guide pin bolts by hand first, then tighten using a 13mm socket and 3/8" drive torque wrench.
• Torque to 25 Nm (18 ft-lbs)

Step 8: Reinstall wheels and torque lug nuts

• Reinstall the wheels and hand-thread the lug nuts.
• Lower the Expedition to the ground using the floor jack (rated 3-ton minimum).
• Tighten lug nuts in a star pattern with a 21mm socket and 1/2" drive torque wrench.
• Torque to 203 Nm (150 ft-lbs)

---

✅ After Repair

• With the engine off, pump the brake pedal 10-15 times until it feels firm.
• Check brake fluid level and top off only with DOT 4 LV if needed.
• Start the engine and verify the pedal feels normal (power assist working).
• Do a slow test drive and confirm there are no noises, pulling, or warning lights.
• Pad break-in: make 8-10 moderate stops from 30-40 mph, letting brakes cool 30-60 seconds between stops.

---

💰 DIY vs Shop Cost

Shop Cost: ₹12,000-₹25,000 (parts + labor)

DIY Cost: ₹4,000-₹12,000 (parts only)

You Save: ₹8,000-₹13,000 by doing it yourself!

Shop labor rates vary by area; this job is typically 1.5-3 hours of labor.

---
