🔧 Equinox - Front Brake Pad Replacement

You’ll remove the front wheels, unbolt the brake calipers, swap the pads, and reassemble carefully with proper lubrication and torque. This restores braking performance and stops squealing or grinding.

Difficulty Level: Intermediate | Estimated Time: 1.5–2.5 hours

---

⚠️ Safety & Precautions

• 🛑 Always support your Equinox on jack stands; never work under a car held only by a jack.
• 🔥 Brakes can get extremely hot; let everything cool at least 30–60 minutes after driving.
• 😷 Brake dust can be harmful; avoid blowing with air. Use brake cleaner and a catch pan.
• 🔋 For this job you do not need to disconnect the battery.
• 🚗 Work on one side at a time so you can look at the other side as a reference.
• 🧱 Chock (block) the rear wheels so the car cannot roll.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🧰 Floor jack (rated 3-ton minimum)
• 🧰 Jack stands (rated 3-ton minimum)
• 🧰 Wheel chocks
• 🧰 Breaker bar 1/2"
• 🧰 19mm socket
• 🧰 13mm socket
• 🧰 18mm socket
• 🧰 Ratchet 3/8"
• 🧰 Ratchet 1/2"
• 🧰 Torque wrench 3/8" drive (up to 50 ft-lbs)
• 🧰 Torque wrench 1/2" drive (up to 150 ft-lbs)
• 🧰 C-clamp (6" or larger) or disc brake piston tool
• 🧰 Flathead screwdriver medium
• 🧰 Wire brush small
• 🧰 Bungee cord or strong wire hanger
• 🧰 Brake cleaner spray can
• 🧰 Drain pan or catch tray
• 🧰 Shop towels or clean rags
• 🧰 Nitrile gloves
• 🧰 Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🧱 Front brake pad set - Qty: 1 (replace both sides)
• 🧱 Front brake hardware kit (pad clips/anti-rattle clips) - Qty: 1
• 🧱 High-temperature brake grease - Qty: 1 small tube
• 🧱 Brake cleaner - Qty: 1–2 cans
• 🧱 Front brake caliper bolts (slide pins) – optional new - Qty: 4
• 🧱 Front caliper bracket bolts – optional new - Qty: 4

---

📋 Before You Begin

• 🛞 Park the Equinox on flat, solid ground; put the transmission in Park and set the parking brake.
• 🧱 Place wheel chocks behind at least one rear wheel.
• 📦 Lay out all tools and parts so you are not searching mid-job.
• 🔍 Loosen the front wheel lug nuts slightly before lifting the car.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen front wheel lug nuts

• Use the 19mm socket and breaker bar 1/2" to crack loose (¼ turn) each front wheel lug nut while the car is still on the ground.
• Do not remove the nuts yet.

Step 2: Lift and support the front of the vehicle

• Position the floor jack (rated 3-ton minimum) under the front jacking point or subframe per the owner’s manual.
• Raise the front until both front wheels are off the ground.
• Place jack stands (rated 3-ton minimum) under the proper pinch welds or frame points on both sides, then slowly lower the car onto the stands.
• Gently rock the car by hand to confirm it is stable.

Step 3: Remove front wheels

• Use the 19mm socket and ratchet 1/2" to remove all lug nuts from one front wheel.
• Remove the wheel and set it aside; repeat for the other front wheel.

Step 4: Inspect the brake assembly

• Look at the brake caliper (the clamp-looking part), the rotor (the shiny disc), and the bracket that holds the pads.
• Work on one side at a time for reference.

Step 5: Remove caliper guide pin bolts

• On the first side, locate the two small bolts on the back of the caliper (top and bottom).
• Use the 13mm socket and ratchet 3/8" to remove both caliper guide pin bolts.
• As you remove them, note their position and condition.

Step 6: Lift and support the caliper

• Use a flathead screwdriver medium gently between the old pad and rotor to pry a little if needed to loosen the caliper.
• Lift the caliper off the bracket and pads.
• Support the caliper using a bungee cord or strong wire hanger hooked to the strut spring. Do not let it hang by the rubber brake hose.

Step 7: Remove old brake pads and hardware

• Slide the old pads out of the caliper bracket by hand.
• Remove the old metal pad clips (hardware) from the bracket using your fingers or the flathead screwdriver medium.
• Place the old pads aside so you can compare them to the new pads.

Step 8: Clean the caliper bracket and rotor

• Use the wire brush small to clean the areas on the bracket where the pad clips sit, removing rust and debris.
• Spray brake cleaner on the bracket and rotor, catching runoff in the drain pan or catch tray.
• Wipe dry with shop towels or clean rags.
• Do not touch rotor face with greasy hands.

Step 9: Install new hardware (pad clips)

• Snap the new pad clips from the front brake hardware kit into the caliper bracket where the old ones were.
• Ensure each clip is fully seated and not bent.

Step 10: Compress the caliper piston

• Place one of the old brake pads against the caliper piston face.
• Use the C-clamp (6" or larger) or disc brake piston tool between the old pad and the back of the caliper body.
• Slowly tighten the tool to push the piston fully back into the caliper.
• Watch the brake fluid reservoir under the hood while doing this; if fluid is very full, you may need to remove a little with a clean rag or syringe so it does not overflow.

Step 11: Lubricate slide points

• Remove the caliper slide pins (the bolts you took out in Step 5 often have smooth “pin” sections).
• Wipe them clean with shop towels or clean rags and a bit of brake cleaner if dirty.
• Apply a thin layer of high-temperature brake grease to the smooth parts of the pins.
• Reinsert the pins into the caliper and work them in and out to spread the grease.
• Apply a tiny film of high-temperature brake grease to the areas of the pad clips where the pads will slide. Do not get grease on pad friction material or rotor surface.

Step 12: Install new brake pads

• Match the new pads to the old ones for inner vs outer position (one pad may have a wear indicator tab).
• Slide the new pads into the caliper bracket, making sure they sit flat in the clips.
• Pad friction material must face the rotor.

Step 13: Reinstall the caliper over new pads

• Lower the caliper carefully over the new pads and onto the bracket.
• Align the caliper guide pin holes with the bracket threaded holes.
• Install the caliper guide pin bolts by hand first to avoid cross-threading.
• Use the 13mm socket and ratchet 3/8" to snug them, then use the torque wrench 3/8" drive (up to 50 ft-lbs) to tighten each guide pin bolt to 31 Nm (23 ft-lbs).

Step 14: Repeat on the other front side

• Move to the opposite front wheel and repeat Steps 5–13.
• Always replace pads on both sides of the axle.

Step 15: Reinstall front wheels

• Place the wheel back on the hub and hand-thread all lug nuts.
• Use the 19mm socket and ratchet 1/2" to snug the nuts in a star pattern while the car is still on stands.

Step 16: Lower vehicle and torque lug nuts

• Use the floor jack (rated 3-ton minimum) to raise the Equinox slightly, remove the jack stands (rated 3-ton minimum), then lower the car fully to the ground.
• Use the 19mm socket and torque wrench 1/2" drive (up to 150 ft-lbs) to torque the lug nuts in a star pattern to 190 Nm (140 ft-lbs).

Step 17: Pump the brake pedal

• Sit in the driver’s seat and press the brake pedal slowly several times until it feels firm.
• This seats the pads against the rotors and removes extra clearance.

---

✅ After Repair

• 🧪 Check the brake fluid level in the reservoir and adjust if needed; do not overfill.
• 🚗 Start the engine and gently press the brake pedal; it should feel firm and consistent.
• 🛣 Take a short, low-speed test drive: make several gentle stops from 20–30 km/h, then from 40–50 km/h.
• 🔥 New pads need to “bed in”: for the first 300–500 km, avoid very hard braking unless necessary.
• 👂 Listen for grinding or loud noises; if present, stop and recheck pad installation.

---

💰 DIY vs Shop Cost

Shop Cost: $220–$350 (parts + labor)

DIY Cost: $70–$140 (parts only)

You Save: $150–$210 by doing it yourself!

Shop labor rates vary but typically run $100–$150/hour. This repair takes a shop approximately 1–1.5 hours.

---
